河谷地形下兰州市城市热岛效应的时空演变研究

doi:10.13249/j.cnki.sgs.2012.012.1530

Abstract

Abstract:

With the progress of urbanization, Urban Heat Island (UHI) has been becoming a key factor in deteriorating the urban ecological environment. Studying spatial-temporal evolution and its cause of typical area′s UHI and quantitatively evaluating effect from rapid urbanization on urban heat environment will provide theoretical foundation for relieving UHI effect and also have some useful reference value for ecological environment planning of urban planning. Based on LandsatETM+ and TM images of Lanzhou in 1999 and 2010, with the aid of GIS and RS, this article has retrieved the land surface temperature (LST) of Lanzhou City by Qin’s mono-window algorithm, and then analyzed spatial-temporal pattern and evolution characters of UHI in Lanzhou City in this decade, and the results show that: 1) The spatial pattern and stretch of UHI are consistent with distribution of built district in Lanzhou City. With the expansion of built district, UHI area constantly expanded and the area of less medium temperature and medium temperature had a large reduction, accordingly, the area of less high temperature and high temperature had a large increase, and consequently UHI intension obviously enhanced. Also, as building density of urban area has been increasing gradually, besides land use/covers type, low temperature belt caused by the Yellow River has been becoming a key factor in affecting the spatial pattern of UHI, and within a certain distance, it has the trend that LST tends to go down from the Yellow River to both sides. 2) From 1999 to 2010, average LST of each land use/cover type had a increase, and LST of different land use/cover type had obvious difference. LST of urban construction land and unused land was the highest, and they had the largest contribution to UHI effect, that is to say, they are the main contribution factor, on the contrary, green land and waterbody can reduce LST significantly, therefore, rational planning can effectively relieve the UHI effect. 3) This article has achieved 37 profiles from southeast to northwest of basin valley and calculated their land use index values (NDVI、MNDWI、NDBI and NDBaI) and LST, the results show that there existed significant correlation and corresponding relations between LST and the four land use indices.

Key words: basin valley, Urban Heat Island (UHI), spatial-temporal evolution, Lanzhou City

CLC Number:

TP79

Jian-ming ZHANG, Peng-long WANG, Ning MA, Chao ZHANG. Spatial-temporal Evolution of Urban Heat Island Effect in Basin Valley —A Case Study of Lanzhou City[J].SCIENTIA GEOGRAPHICA SINICA, 2012, 32(12): 1530-1537.

Figures/Tables 7

Fig.1

Fig.2

Fig.3

Table 1

Table 2

Table 3

Fig.4

References 41

[1]	徐祥德,汤绪.城市化环境气象学引论[M].北京:气象出版社,2002 .
[2]	Howard L. The Climate of London, Deduced from Meteorological Observations[M]: London:Joseph Rickerby, Printer, 1833.
[3]	周淑贞,束炯.城市气候学[M].北京:气象出版社, 1994.
[4]	徐永明,覃志豪,朱焱.基于遥感数据的苏州市热岛效应时空变化特征分析[J].地理科学, 2009, 29(4):529~534.
[5]	赵云升,杜嘉,宋开山,等. 基于卫星遥感的夏季长春市城区热场分析[J]. 地理科学, 2006,26(1): 70~74. doi: 10.3969/j.issn.1000-0690.2006.01.012
[6]	Priyadarsini R, Hien W K, Wai David C K. Microclimatic modeling of the urban thermal environment of Singapore to mitigate urban heat island[J]. Solar Energy, 2008, 82(8): 727-745. doi: 10.1016/j.solener.2008.02.008
[7]	宫阿都,徐捷,赵静,等.城市热岛研究方法概述[J].自然资源灾害学报,2008,17(6):96~99. doi: 10.3969/j.issn.1004-4574.2008.06.020
[8]	林学椿,于淑秋.北京地区气温的年代际变化和热岛效应[J].地球物理学报, 2005, 48(1): 39~45.
[9]	Morris C J G, Simmonds I, Plummer N. Quantification of the influences of wind and cloud on the nocturnal urban heat island of a large city[J]. Journal Applied Meteorology,2001, 40(2):169-182. doi: 10.1175/1520-0450(2001)040<0169:QOTIOW>2.0.CO;2
[10]	张玲,徐宗学,阮本清.北京城市热岛效应对气温和降水量的影响[J].自然资源学报,2006, 21(5): 746~755. doi: 10.11849/zrzyxb.2006.05.008
[11]	Zhang X X, Wu P F, Chen B.Relationship between vegetation greenness and urban heat island effect in Beijing City of China[J]. Procedia Environmental Sciences,2010, 2:1438-1450 doi: 10.1016/j.proenv.2010.10.157
[12]	Li J J, Wang X R, Wang X J, et al.Remote sensing evaluation of urban heat island and its spatial pattern of the Shanghai metropolitan area, China[J]. Ecological Complexity,2009, 6:413-420. doi: 10.1016/j.ecocom.2009.02.002
[13]	张瑜. 基于Landsat5 TM 数据的西安市城市化进程与热岛效应关系研究[D]. 西安:西北大学, 2009:34~47.
[14]	夏佳,但尚铭,陈刚毅.成都市热岛效应演变趋势与城市变化关系研究[J].成都信息工程学院学报, 2007,22( S1):6~11. doi: 10.3969/j.issn.1671-1742.2007.z1.002
[15]	白虎志,任国玉,方锋.兰州城市热岛效应特征及其影响因子研究[J].气象科技,2005,33(6): 492~496. doi: 10.3969/j.issn.1671-6345.2005.06.003
[16]	马玉霞,王式功,魏海茹.兰州市近50年城市热岛强度变化特征[J].气象科技,2009,37(6): 660~664. doi: 10.3969/j.issn.1671-6345.2009.06.005
[17]	李国栋,王乃昂,张俊华,等.兰州市城区夏季热场分布与热岛效应研究[J].地理科学,2008,28(5):709~714.
[18]	潘竟虎,冯兆东,相得年,等.河谷型城市土地利用类型及格局的热环境效应遥感分析——以兰州市为例[J].遥感技术与应用,2008,23(2):202~207.
[19]	国家统计局.中国城市统计年鉴[M].北京:中国统计出版社,2000,2010.
[20]	Chander G, Markham B L, Helder D L.Summary of current radiometric calibration coefficients for LandsatMSS, TM, ETM+, and EO-1 ALI sensors[J]. Remote Sensing of Environment,2009, 113:893-903. doi: 10.1016/j.rse.2009.01.007
[21]	Sugita M, Brutsaert W.Comparison of land surface temperatures derived from satellite observations with ground truth during FIFE[J]. International Journal of Remote Sensing,1993, 14:1659-1676. doi: 10.1080/01431169308953993
[22]	覃志豪,LI W J,ZHANG M H,等.单窗算法的基本大气参数估计方法[J].国土资源遥感,2003,56(2):37~43.
[23]	Sobrino J A, Jimenez J C, Paolini L.Land surface temperature retrieval from LANDSAT TM 5[J]. Remote Sensing of Environment,2004, 90:434-446. doi: 10.1016/j.rse.2004.02.003
[24]	Qin Z, Karnieli A, Berliner P.A mono-window algorithm for retrieving land surface temperature from Landsat TM data and its application to the Israel-Egypt border region[J]. International Journal of Remote Sensing,2001, 22:3719-3746.
[25]	杨景梅,邱金桓.我国可降水量同地面水汽压关系的经验表达式[J].大气科学,1996,20(5): 620~626. doi: 10.3878/j.issn.1006-9895.1996.05.14
[26]	贾仰文,王浩,倪广恒,等.分布式流域水文模型原理与实践[M].北京:中国水利水电出版社,2005.
[27]	覃志豪,李文娟,徐斌,等.利用LANDSAT TM6反演地表温度所需地表辐射率参数的估计方法[J].海洋科学进展,2004,22(Sl):129~137. doi: 10.3969/j.issn.1671-6647.2004.z1.022
[28]	Van De Griend A A,Owe M. On the relationship between thermal emissivity and the normalized difference vegetation index for natural surfaces[J].International Journal of Remote Sensing,1993, 14:1119-1131. doi: 10.1080/01431169308904400
[29]	Valor E, Caslles V.Mapping land surface emissivity from NDVI application to European, African, and South American areas[J]. Remote Sensing of Environment,1996, 57(3):167-184.
[30]	Carlson T N, Ripley D A.On the relation between NDVI,fractional vegetation cover,and leaf area index[J]. Remote Sensing of Environment,1997, 62:241-252. doi: 10.1016/S0034-4257(97)00104-1
[31]	Purevdorj T, Tateishi R, Ishiyama T, et al.Relationships between percent vegetation cover and vegetation indices[J]. International Journal of Remote Sensing 1998, 19:3519-3535.
[32]	徐涵秋. 利用改进的归一化差异水体指数(MNDWI)提取水体信息的研究[J].遥感学报,2005,9(5):589~595. doi: 10.11834/jrs.20050586
[33]	查勇,倪绍祥,杨山.一种利用TM 图像自动提取城镇用地信息的有效方法[J].遥感学报,2003, 7(1):37~40. doi: 10.11834/jrs.20030107
[34]	Zhao H M, Chen X L.Use of normalized difference bareness index in quickly mapping bare areas from TM/ETM+ imagery[C].IEEE,2005,(3):1666-1668.
[35]	徐涵秋,陈本清.不同时相的遥感热红外图像在研究城市热岛变化中的处理方法[J].遥感技术与应用,2003,18(3):129~33.
[36]	Chen X, Zhao H, Li P, et al.Remote sensing image-based analysis of the relationship between urban heat island and land use/cover changes[J]. Remote Sensing of Environment,2006, 104:133-146. doi: 10.1016/j.rse.2005.11.016
[37]	Carlson T N, Gillies R R, Perry E M.A method to make use of thermal infrared temperature and NDVI measurements to infer surface soil water content and fractional vegetation cover[J]. Remote Sensing Reviews,1994, 9:161-173. doi: 10.1080/02757259409532220
[38]	Sandholt I, Rasmussen K, Andersen J.A simple interpretation of the surface temperature /vegetation index space for assessment of surface moisture status[J].Remote Sensing of Environment,2002,79:213-24.
[39]	历华,柳钦火,邹杰.基于MODIS数据的长株潭地区NDBI和NDVI与地表温度的关系研究[J]. 地理科学, 2009, 29(02): 262~267. doi: 10.3969/j.issn.1000-0690.2009.02.019
[40]	历华,曾永年,柳钦火.基于遥感的长沙市城市热岛与土地利用/覆盖变化研究[J].国土资源遥感,2008,(4):47~52. doi: 10.6046/gtzyyg.2008.04.12
[41]	岳文泽,徐建华,徐丽华.基于遥感影像的城市土地利用生态环境效应研究——以城市热环境和植被指数为例[J].生态学报,2006,26(5):1450~1460.

土地类型	1999年		2010年
土地类型	实际（℃）	正归化	实际（℃）	正归化
建设用地	28.81±2.69	0.53±0.09	30.16±2.02	0.65±0.08
未利用地	26.55±2.32	0.45±0.07	27.97±5.97	0.57±0.23
绿地	24.99±1.79	0.40±0.06	26.48±2.53	0.51±0.10
水体	18.23±3.14	0.16±0.11	18.79±3.13	0.17±0.12

1999年	2010年				1999年合计
1999年	建设用地	未利用地	绿地	水域	1999年合计
建设用地	105.45	4.84	4.22	0.34	114.85
未利用地	5.06	4.57	0.52	0.02	10.17
绿地	35.72	27.42	33.07	0.30	96.51
水域	1.77	0.31	2.39	9.30	13.77
2010年合计	148.00	37.14	40.20	9.96
变化比例/%	28.86	265.19	-58.35	-27.67

土地类型	低温区		次中温区		中温区		次高温区		高温区
土地类型	1999年	2010年	1999年	2010年	1999年	2010年	1999年	2010年	1999年	2010年
建设用地	3.76	1.79	13.18	12.69	61.20	45.46	97.88	79.02	98.69	71.74
未利用地	0.33	0.99	3.11	2.77	5.85	9.96	1.12	15.32	0.79	26.77
绿地	4.21	3.81	79.09	57.21	32.55	44.09	0.93	5.61	0.22	1.32
水域	91.70	93.41	4.62	27.34	0.40	0.49	0.07	0.05	0.30	0.17
