基于空间句法和LBS大数据的合肥市人口分布空间格局研究

doi:10.13249/j.cnki.sgs.2018.11.008

Abstract

Abstract:

The space pattern of urban population distribution is a classical research topic of urban science and urban planning. In terms of the current research situation of urban population distribution, the LBS big data technology which is considered as a new method and tool to observe the urban spatial and temporal characteristics is introduced into the research of urban population distribution based on the traditional space syntax model. Then, a new idea of urban population distribution research with the integration of theoretical distribution and actual distribution is established. The case study in the central urban area of Hefei City shows that: the spatial clustering areas obtained respectively by space syntax model and LBS big data analyses are different in space. According to the comprehensive comparison of space syntax model and LBS big data analysis, the central urban area of Hefei City is divided into 3 types of population distribution including high density, medium density and low density. The high density zoning consists of the old town, Shushan district and Baohe district. The medium density zoning includes Binhu district, Luyang district and High-tech area. Meanwhile, the low density zoning consists of economic developing area and Yaohai district. Finally, the suggestions of population distribution development in different density partitions are proposed. The research shows that the timely and dynamic characteristics of LBS big data can make up for the shortcomings of traditional data and greatly broaden the source and timeliness of basic data. Obviously, this will enhance the accuracy of the study. And, more importantly, it will provide more accurate and efficient tools and methods combined with the classical space syntax model for the study of urban population distribution. In addition, it is hoped that this research can make some exploration and reference for expanding the practical application field of LBS big data.

Key words: space syntax, LBS big data, urban population distribution, Hefei city

CLC Number:

K901

Xiaorui Zhang, Qian Hua, Zhigang Cheng. Space Pattern of Urban Population Distribution Based on Space Syntax and LBS Big Data[J].SCIENTIA GEOGRAPHICA SINICA, 2018, 38(11): 1809-1816.

Figures/Tables 9

Fig. 1

Table 1

Fig. 2

Table 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Table 3

References 21

[1]	Champion A G.A changing demographic regime and evolving polycentric urban regions: Consequences for the composition and distribution of city populations[J]. Urban Studies, 2001, 38(4):657-677. doi: 10.1080/00420980120035277
[2]	曾文,张小林,向梨丽,等.2000~2010年南京都市区人口空间变动特征研究[J].地理科学,2016,36(1):81-89. doi: 10.1329/j.cnki.sgs.2016.01.010
	[Zeng Wen, Zhang Xiaolin, Xiang Lil. et al. The features of population redistribution of Nanjing metropolitan area in 2000-2010. Scientia Geographica Sinica, 2016, 36(1):81-89.] doi: 10.1329/j.cnki.sgs.2016.01.010
[3]	Clark C.Urban population densities[J].Journal of the Royal Statistical Society (Series A),1951,114(4):490-496. doi: 10.2307/2981088
[4]	Newling B E.The spatial variation of urban population densities[J]. Geographical Review, 1969, 59(2): 242-252. doi: 10.2307/213456
[5]	Anderson J E.Cubic spline urban density functions[J].Journal of Urban Economics,1982, 12(2):155-167. doi: 10.1016/0094-1190(82)90012-2
[6]	Berry B J L, Kim H M. Challenges to the monocentric model[J].Geographical Analysis, 1993, 25(1):1-4. doi: 10.1111/j.1538-4632.1993.tb00275.x
[7]	刘睿文, 封志明, 杨艳昭, 等. 基于人口集聚度的中国人口集疏格局[J]. 地理科学进展, 2010, 29(10): 1171-1177. doi: 10.11820/dlkxjz.2010.10.003
	[Liu Ruiwen, Feng Zhiming, Yang Yanzhao. et al. Research on the spatial pattern of population agglomeration and dispersion in China. Progress in Geography, 2010, 29(10): 1171-1177.] doi: 10.11820/dlkxjz.2010.10.003
[8]	李莎, 刘卫东. 俄罗斯人口分布及其空间格局演化[J]. 经济地理, 2014, 34(2): 42-49. doi: 10.3969/j.issn.1000-8462.2014.02.007
	[Li Sha, Liu Weidong.Spatial distribution of population in Russia and its evolution. Economic Geography, 2014, 34(2): 42-49.] doi: 10.3969/j.issn.1000-8462.2014.02.007
[9]	于婷婷,宋玉祥,浩飞龙,等.东北三省人口分布空间格局演化及其驱动因素研究[J].地理科学,2017,37(5):709-717.
	[Yu Tingting, Song Yuxiang, Hao Feilong. et al. Space pattern evolution of population distribution and the driving factors in northeast China. Scientia Geographica Sinica, 2017, 37(5):709-717.]
[10]	冯健. 杭州市人口密度空间分布及其演化的模型研究[J]. 地理研究, 2002, 21(5): 635-646. doi: 10.3321/j.issn:1000-0585.2002.05.013
	[Feng Jian.Modeling the spatial distribution of urban population density and its evolution in Hangzhou. Geographical Research, 2002, 21(5): 635-646.] doi: 10.3321/j.issn:1000-0585.2002.05.013
[11]	Luo Jun, Wei Yehua.Population distribution and spatial structure in transitional Chinese cities: A study of Nanjing[J]. Eurasian Geography and Economics, 2006, 47(5):585-603. doi: 10.2747/1538-7216.47.5.585
[12]	梁昊光,刘彦随. 北京市人口时空变化与情景预测研究[J]. 地理学报,2014,69(10):1487-1495. doi: 10.11821/dlxb201410008
	[Liang Haoguang, Liu Yansui.Study on spatio-temporal change and simulation of population in Beijing based on census data. Acta Geographica Sinica, 2014, 69(10):1487-1495.] doi: 10.11821/dlxb201410008
[13]	柴彦威,赵莹.时间地理学研究最新进展[J].地理科学,2009,29(4):593-600. doi: 10.3969/j.issn.1000-0690.2009.04.022
	[Chai Yanwei, Zhao Ying.Recent development in time geography. Scientia Geographica Sinica, 2009, 29(4):593-600.] doi: 10.3969/j.issn.1000-0690.2009.04.022
[14]	王波,甄峰,张浩. 基于签到数据的城市活动时空间动态变化及区划研究[J]. 地理科学,2015,35(2):151-160.
	[Wang Bo, Zhen Feng, Zhang Hao.The dynamic changes of urban space-time activity and activity zoning based on check-in data in sina web. Scientia Geographica Sinica, 2015, 35(2):151-160.]
[15]	Hiller B,Hanson J.The Social Logic of Space [M]. London: Cambridge University Press, 1984.
[16]	张晓瑞,程志刚,白艳. 空间句法研究进展与展望[J]. 地理与地理信息科学,2014,30(3):82-87. doi: 10.3969/j.issn.1672-0504.2014.03.018
	[Zhang Xiaorui, Cheng Zhigang, Bai Yan.Review and prospect of space syntax. Geography and Geo-information Science, 2014,30(3):82-87.] doi: 10.3969/j.issn.1672-0504.2014.03.018
[17]	江斌,黄波,陆峰. GIS环境下的空间分析和地学视觉化[M].北京:高等教育出版社,2002.
	[Jiang Bin,Huang Bo,Lu Feng.Spatial analysis and geoscience visualization in GIS environment. Beijing: Higher Education Press, 2002.]
[18]	Gang S, Dan L, Hui L. et al. L2P2: A location-label based approach for privacy preserving in LBS[J]. Future Generation Computer Systems, 2016, 74(9):375-384. doi: 10.1016/j.future.2016.08.023
[19]	宁博, 裴晓霞, 李玉居, 等. LBS大数据中基于固定网格划分四叉树索引的查询验证[J]. 清华大学学报(自然科学版), 2016,56(7): 785-792.
	[Ning Bo, Pei Xiaoxia, Li Yuju. et al. Query authentications based on a fixed grid partitioning quad-tree index in LBS big data. Journal of Tsinghua University(Science and Technology), 2016,56(7): 785-792.]
[20]	徐军,李大军. 基于实景地图的LBS服务[J]. 地理空间信息,2012,10(5):157-160.
	[Xu Jun, Li Dajun.LBS services based on live maps. Geospatial Information, 2012,10(5):157-160.]
[21]	陈晨,李浩然. 基于LBS大数据的南京市综合客运枢纽影响范围研究[J]. 现代交通技术,2017,14(2):63-66.
	[Chen Chen, Li Haoran.Study on the influence scope of Nanjing comprehensive passenger transport hubs based on LBS big data. Modern Transportation Technology, 2017, 14(2):63-66.]

全局集成度	平均值			最小值			最大值			标准差
全局集成度	基期	末期		基期	末期		基期	末期		基期	末期
数值	1.0172	1.0877		0.5209	0.4073		1.7955	1.8461		0.2051	0.2240

全局集成度	平均值			最小值			最大值			标准差
全局集成度	基期	末期		基期	末期		基期	末期		基期	末期
数值	1.7846	1.9939		0.3313	0.3729		3.8136	4.2083		0.5809	0.6778

空间句法分析	LBS大数据分析	所属分区（是否吻合）
徽州大道区域	长江中路区域	老城区（吻合）
黄山路区域合作化路区域	五里墩立交桥区域潜山路立交桥区域	蜀山区（吻合）
黄山路区域太湖路区域徽州大道区域	金屯立交桥区域合工大南区地铁站出入口区域朱岗地铁站出入口区域	包河区（吻合）
徽州大道区域	滨湖世纪城区域	滨湖分区（吻合）
北一环路区域	----	庐阳区（不吻合）
黄山路区域	----	高新区（不吻合）
