基于兴趣点（POI）大数据的东北城市空间结构分析

doi:10.13249/j.cnki.sgs.2020.05.003

Abstract

Abstract:

Urban spatial structure is the form of interaction among the urban human-land relationship elements. Taking the Northeast 36 cities as the research area, using the more than 4 million Points of Interest (POI) grouped by industry types, the article used the kernel density estimation method, the diversity index method and the standard deviational ellipse method to analyze the urban spatial structure and the agglomeration characteristics of the various industries. This research found that the urban structure of Northeast China is mainly characterized by concentrated mass, dispersed combination, linear and radial types. Some cities have diversified spatial structure. The second industry and real estate industry in Northeast China show the characteristics of suburbanization, the development direction of each industry is consistent with the economic axis of the Northeast region, and most industries have not yet formed a specialized functional area; The centrifugal development of secondary industry and real estate industry is not strong for the shaping of concentrated block cities, but it contributes greatly to the spatial structure of dispersed group cities. Linear cities usually have a multi-center composite characteristics, the various industries of radial city are still biased towards centripetal aggregation. This research deepens the empirical researches of the big data-driven urban spatial structure as well as industry spatial pattern, and also provides scientific cognitive basis for the rational planning of urban space and the coordinated sustainable development in Northeast China during the revitalization period.

Key words: man-land relationship, urban spatial structure, Points of Interest big data, industry gathering, Northeast China

CLC Number:

K901/X24

Xue Bing, Xiao Xiao, Li Jingzhong, Xie Xiao. Analysis of Spatial Economic Structure of Northeast China Cities Based on Points of Interest Big Data[J].SCIENTIA GEOGRAPHICA SINICA, 2020, 40(5): 691-700.

Figures/Tables 7

Table 1

Fig.1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

References 33

[1]	Gallion A B. The urban pattern[M]. Van Nostrand: Van Nostrand Reinhold Company, 1983.
[2]	顾朝林, 甄峰, 张京祥. 集聚与扩散: 城市空间结构新论[M]. 南京: 东南大学出版社, 2000.
	[ Gu Chaolin, Zhen Feng, Zhang Jingxiang. Jiju yu kuosan: Chengshi kongjian jiegou xinlun. Nanjing: Southeast University Press, 2000.]
[3]	薛冰, 张黎明, 耿涌, 等. 基于空间重构视角的老工业区人地关系研究: 以沈阳市铁西区为例[J]. 地理科学, 2015,35(7):890-897.
	[ Xue Bing, Zhang Liming, Geng Yong, et al. Spatial-restructuring analysis of human-land relationships in an old industrial area: The case of the Tiexi District, Shenyang. Scientia Geographica Sinica, 2015,35(7):890-897.]
[4]	Carter H. The study of urban geography(4th ed.)[M]. London, UK: Edward Arnold, 1995.
[5]	李琬, 孙斌栋, 刘倩倩, 等. 中国市域空间结构的特征及其影响因素[J]. 地理科学, 2018,38(5):672-680. doi: 10.13249/j.cnki.sgs.2018.05.004
	[ Li Wan, Sun bindong, Liu Qianqian et al. The features and determinants of spatial structurein Chinese prefecture-level city regions. Scientia Geographica Sinica, 2018,38(5):672-680.]
[6]	李小建, 李国平, 曾刚, 等. 经济地理学(第三版)[M]. 北京: 高等教育出版社, 2018.
	[ Li Xiaojian, Li Guoping, Zeng Gang, et al. Economic geography (3). Beijing: Higher Education Press, 2018.]
[7]	吴启焰, 朱喜钢. 城市空间结构研究的回顾与展望[J]. 地理学与国土研究, 2001(2):46-50.
	[ Wu Qiyan, Zhu Xigang. Review and prospect of the research on urban spatial structure. Geography and Territorial Research, 2001(2):46-50.]
[8]	许学强, 周一星, 宁越敏, 等. 城市地理学[M]. 北京: 高等教育出版社, 2011.
	[ Xu Xueqiang, Zhou Yixing, Ning Yuemin, et al. Urban geography. Beijing: Higher Education Press, 2011.]
[9]	Marshall J U. The structure of urban systems[M]. Toronto, Canada: University of Toronto Press, 1989.
[10]	王开泳, 肖玲. 城市空间结构演变的动力机制分析[J]. 华南师范大学学报(自然科学版), 2005(1):116-122. doi: 10.6054/j.jscnun.2005.02.023
	[ Wang Kaiyong, Xiao Ling. The analysis of dynamic mechanism about urban spatial structure evolution. Journal of Capital Normal University (Natural Science Edition), 2005(1):116-122.]
[11]	朱锡金. 城市结构的活性[J]. 城市规划汇刊, 1987(5):7-13.
	[ Zhu Xijin. The activity of urban structure. Urban Planning Forum, 1987(5):7-13.]
[12]	胡俊. 中国城市:模式与演进[M]. 北京: 中国建筑工业出版社, 1995: 3-7.
	[ Hu Jun. Cities in China: Patterns and evolution. Beijing: China Architecture & Building Press, 1995: 3-7.]
[13]	宋敏. 从“扇叶城市”到“紧凑城市”[D]. 南京: 东南大学, 2017.
	[ Song Min. From “fan city” to “compact city”—On the development of urban spatial morphology of Hefei. Nanjing: Southeast University, 2017.]
[14]	湛东升, 张文忠, 孟斌, 等. 北京城市居住和就业空间类型区分析[J]. 地理科学, 2017,37(3):356-366. doi: 10.13249/j.cnki.sgs.2017.03.005
	[ Zhan Dongsheng, Zhang Wenzhong, Meng Bin, et al. Spatial structure of urban residence and employment in Beijing. Scientia Geographica Sinica, 2017,37(3):356-366.]
[15]	李琬, 孙斌栋, 刘倩倩, 等. 中国市域空间结构的特征及其影响因素[J]. 地理科学, 2018,38(5):672-680. doi: 10.13249/j.cnki.sgs.2018.05.004
	[ Li Wan, Sun Bindong, Liu Qianqian et al. The features and determinants of spatial structure in Chinese prefecture-level city regions. Scientia Geographica Sinica, 2018,38(5):672-680.]
[16]	Kunze C, Hecht R. Semantic enrichment of building data with volunteered geographic information to improve mappings of dwelling units and population[J]. Computers Environment and Urban Systems, 2015,53:4-18. doi: 10.1016/j.compenvurbsys.2015.04.002
[17]	钮心毅, 丁亮, 宋小冬. 基于手机数据识别上海中心城的城市空间结构[J]. 城市规划学刊, 2014(6):61-67.
	[ Niu Xinyi, Ding Liang, Song Xiaodong. Understanding urban spatial structure of Shanghai central city based on mobile phone data. Urban Planning Forum, 2014(6):61-67.]
[18]	吴志强, 叶锺楠. 基于百度地图热力图的城市空间结构研究: 以上海中心城区为例[J]. 城市规划, 2016,40(4):33-40.
	[ Wu Zhiqiang, Ye Zhongnan. Research on urban spatial structure based on baidu heat map: A case study on the central city of Shanghai. City Planning Review, 2016,40(4):33-40.]
[19]	薛冰, 肖骁, 李京忠, 等. 基于POI大数据的城市沈阳市住宅与零售业空间关联分析[J]. 地理科学, 2019,39(3):442-449. doi: 10.13249/j.cnki.sgs.2019.03.010
	[ Xue Bing, Xiao Xiao, Li Jingzhong et al. POI-based spatial correlation analysis of the residences and retail industry in Shenyang. Scientia Geographica Sinica, 2019,39(3):442-449. ]
[20]	Ivan I, Singleton A, Horák J, et al. The rise of Big Spatial Data[M]. United Kingdom: Springer International Publishing, 2016.
[21]	Mckenzie G, Janowicz K, Gao S, et al. How where is when? On the regional variability and resolution of geosocial temporal signatures for points of interest[J]. Computers Environment and Urban Systems, 2015,54:336-346. doi: 10.1016/j.compenvurbsys.2015.10.002
[22]	高翯, 王士君, 谭亮. 东北振兴以来吉林省区域经济差异的时空演变研究[J]. 地理科学, 2017,37(11):1712-1719. doi: 10.13249/j.cnki.sgs.2017.11.013
	[ Gao He, Wang Shijun, Tan Liang. Regional economic disparities and spatio-temporal evolution in Jilin Province since 2003. Scientia Geographica Sinica, 2017,37(11):1712-1719.]
[23]	郐艳丽. 东北地区古代城市空间形态发展背景与进程[J]. 地理科学, 2010,30(1):8-14.
	[ Gui Yanli. The background and development of the space form of ancient city in Northeast China. Scientia Geographica Sinica, 2010,30(1):8-14.]
[24]	王士君, 宋飏. 中国东北地区城市地理基本框架[J]. 地理学报, 2006,61(6):574-584.
	[ Wang Shijun, Song Yang. Basic frame of the urban geography of Northeast China. Acta Geographica Sinica, 2006,61(6):574-584.]
[25]	宋飏, 王士君, 杨艳茹, 等. 东北地区城市内部空间结构研究[J]. 地域研究与开发, 2009,28(4):18-23.
	[ Song Yang, Wang Shijun J, Yang Yanru, et al. Study on the urban internal spatial structure in Northeast China. Areal Research and Development, 2009,28(4):18-23.]
[26]	肖骁, 穆治霖, 赵雪雁, 等. 基于RS/GIS的东北地区森林生态系统服务功能价值评估[J]. 生态学杂志, 2017,36(11):3298-3304.
	[ Xiao Xiao, Mu Zhilin, Zhao Xueyan et al. RS/GIS-based evaluation of forest ecosystem service value in Northeast China. Chinese Journal of Ecology, 2017,36(11):3298-3304.]
[27]	薛冰, 肖骁, 李京忠, 等. 基于POI大数据的城市零售业空间热点分析——以辽宁省沈阳市为例[J]. 经济地理, 2018,38(5):36-43.
	[ Xue Bing, Xiao Xiao, Li Jingzhong et al. POI-based analysis on retail’s spatial hot blocks at a city level: A case study of Shenyang, China. Economic Geography, 2018,38(5):36-43.]
[28]	中华人民共和国国家统计局. 2017年国民经济行业分类(GB/T 4754-2017)[S]. 北京: 中国标准出版社, 2017.
	[ National Bureau of Statistics of the People’S Republic of China. Industrial classification for National ecomoic activities(GB/T 4754-2017). Beijing: Standards Press of China, 2017.]
[29]	徐冬, 黄震方, 吕龙, 等. 基于POI挖掘的城市休闲旅游空间特征研究——以南京为例[J]. 地理与地理信息科学, 2018, 34(1): 59-64+70+3.
	[ Xu Dong, Huang Zhenfang, Lyu Long et al. Research on spatial characteristics of urban leisure tourism based on POI mining: A case study of Nanjing City. Geography and Geo-Information Science, 2018, 34(1): 59-64+70+3.]
[30]	Silverman B W. Density estimation for statistics and data analysis[M]. New York: Chapman and Hall, 1986.
[31]	Robert S Y. The standard deviational ellipse: An updated tool for spatial description[J]. Geografiska Annaler, Series B, Human Geography, 1971 ( 1):28-39.
[32]	浩飞龙, 施响, 白雪, 等. 多样性视角下的城市复合功能特征及成因探测——以长春市为例[J]. 地理研究, 2019,38(2):247-258. doi: 10.11821/dlyj020170705
	[ Hao Feilong, Shi Xiang, Bai Xue et al. Geographic detection and multifunctional land use from the perspective of urban diversity: A case study of Changchun. Geographical Research, 2019,38(2):247-258.]
[33]	张婷麟, 孙斌栋. 都市区空间结构与经济发展的互动关系研究[J]. 地理科学, 2017,37(4):512-518. doi: 10.13249/j.cnki.sgs.2017.04.004
	[ Zhang Tinglin, Sun Bingdong. The interaction between urban spatial structure and economic development. Scientia Geographica Sinica, 2017,37(4):512-518.]

产业类型	编号	行业分类	POI数据类型
第一产业	11	农、林、牧、渔业	农林牧渔基地
第二产业	21	采矿、制造、建筑业	工厂、矿产公司、机械电子、医药公司、冶金化工、建筑公司、广告装饰
第三产业	31	批发和零售业	购物服务、汽车销售、摩托车销售、商业贸易
	32	住宿和餐饮业	住宿服务、餐饮服务
	33	信息传输、软件和信息技术服务业	网络科技、信息公司
	34	金融业	金融保险服务
	35	房地产业	商务住宅
	36	科教和文化服务业	科教文化服务
	37	卫生	医疗保健服务
	38	体育和娱乐业	体育休闲服务
	39	交通运输业	交通设施服务
	310	居民服务业、修理业	生活服务、汽车维修、汽车服务、摩托车维修
	311	公共管理、社会保障和社会组织	政府机构及社会团体
