滹沱河上游山区近50年蒸散变化及主要影响因子分析

doi:10.13249/j.cnki.sgs.2012.05.628

摘要/Abstract

摘要：

准确估计流域蒸散,掌握其变化趋势和主要影响因子,对科学认识流域水文循环规律以及管理流域水资源具有重要意义。利用傅抱璞年蒸散量公式计算滹沱河上游山区及其子流域1958~2007年逐年蒸散量,并利用Mann-Kendall-Sneyers等方法分析了流域蒸散趋势和突变特征,及其主要影响因子。结果表明在滹沱河流域傅抱璞公式能够较好的拟合蒸散。50 a来全流域及各子流域年均蒸散呈下降趋势。降水对蒸散起控制作用,相对湿度在流域部分地区显著影响蒸散（α=0.05）。

关键词: 流域蒸散, 影响因子, 趋势分析, 滹沱河

Abstract:

It is important for both understanding the hydrological rules and managing the water resources to estimate the evapotranspiration accurately in a basin as well as master the trends of both itself and the principal influence factors. This paper calculated the annual evapotranspiration in the upstream mountain areas of Hutuo River Basin in North China during 1958-2007 by Fu Baopu formula, and analyzed the trend, the abruption and the principal influence factors of the evapotranspiration. The result shows that the Fu Baopu formula can estimate the evapotranspiration satisfactorily. In the past 50 years, the evapotranspiration in Hutuo River basin had a decreasing trend (α=0.05). Precipitation influenced the evapotranspiration strongly, while the potential evapotranspiration has little effect on it. In some of the researched area, relatively humidity also had significant influence (α=0.05). The averaged trends of the studied factors are: annual potential evapotranspiration, annual-averaged daily wind speed, hours of sunshine, relative humidity, and atmospheric pressure decreased significantly, annual precipitation decreased non-significantly, annual-averaged daily maximal, mean, minimal temperature increased significantly (α=0.05). The factors and the difference between their multi-year averaged values before and after significant abruptions are: annual potential evapotranspiration decreased 70.30mm. Daily wind speed and hours of sunshine decreased 0.53 m/s and 0.52 h/d, respectively. Daily maximal, mean, minimal temperature increased 1.09、0.95、1.14℃, respectively. Evapotranspiration and precipitation had no abruptions. The sub-basin averaged geological locations, elevations, land cover, and NDVI do not influence the evapotranspiration significantly within the whole basin.

Key words: evapotranspiration, influence factors, trend analysis, Hutuo River

中图分类号:

TV213.9

张瑞钢, 莫兴国, 林忠辉. 滹沱河上游山区近50年蒸散变化及主要影响因子分析[J]. 地理科学, 2012, 32(5): 628-634.

Rui-gang ZHANG, Xing-guo MO, Zhong-hui LIN. The Trend and the Principal Influence Factors of Evapotranspiration in Hutuo River Basin During Last 50 Years[J]. SCIENTIA GEOGRAPHICA SINICA, 2012, 32(5): 628-634.

图/表 9

图1

表1

图2

表2

图3

图4

表3

图5

图6

参考文献 31

[1]	Chahine M T.The Hydrological Cycle and Its Influence on Climate[J]. Nature,1992,359(6394): 373-380.
[2]	Liang Liqiao,Li Lijuan,et al.Temporal variation of reference evapotranspiration during 1961-2005 in the Taoer River basin of Northeast China[J]. Agricultural and Forest Meteorology,2010,150(2): 298-306.
[3]	高歌,陈德亮,任国玉,等.1956~2000年中国潜在蒸散量变化趋势[J].地理研究, 2006,25(03): 378~387.
[4]	郭军,任国玉.黄淮海流域蒸发量的变化及其原因分析[J].水科学进展, 2005,16(05): 666~672.
[5]	姚玉璧,王润元,杨金虎,等.黄土高原陆地表层作物生长季最大可能蒸散量的变化特征[J]. 地理科学,2011,31(8):889~995.
[6]	Gao Ge, Chen Deliang, Xu Chongyu.Trend of estimated actual evapotranspiration over China during 1960-2002[J]. Journal of Geophysical Research, 2007,112(D11): p. D11120.
[7]	王艳君,姜彤,刘波.长江流域实际蒸发量的变化趋势[J]. 地理学报, 2010, 65(9): 1079~1088.
[8]	谢平,陈晓宏,王兆礼,等.东江流域实际蒸发量与蒸发皿蒸发量的对比分析[J].地理学报,2009,64(3): 270~277.
[9]	刘健,张奇,许崇育,等. 近50 年鄱阳湖流域实际蒸发量的变化及影响因素[J]. 长江流域资源与环境,2010, 19(2): 139~145.
[10]	Penman H L.Evaporation: an introductory survey[J].Netherland Journal Agricultural Science,1956,(4):9-29.
[11]	Bouchet R.Evapotranspiration reelle at potentielle, signification climatique[J]. IAHS Publication, 1963, 62:134-142.
[12]	Mo Xingguo, Liu Suxia.Simulating evapotranspiration and photosynthesis of winter wheat over the growing season[J]. Agricultural and Forest Meteorology, 2001, 109(3): 203-222.
[13]	刘三超,张万昌,高懋芳,等.分布式水文模型结合遥感研究地表蒸散发[J].地理科学,2007, 27(3): 354~358.
[14]	傅抱璞. 论陆面蒸发的计算[J]. 大气科学, 1981,5(01):23~30.
[15]	张小磊,杨梅学. 基于GAME-Tibet IOP的青藏高原蒸散研究[J].地理科学,2010, 30(6): 929~935
[16]	Zhang L, Hickel K, Dawes WR, et al.A rational function approach for estimating mean annual evapotranspiration[J]. Water Resources Research, 2004,40(2): W02502.
[17]	Yang D W, Sun F B, Liu Z T, et al.Interpreting the complementary relationship in non-humid environments based on the Budyko and Penman hypotheses[J]. Geophysical Research Letters, 2006,33:L18402
[18]	Yang D W, Sun F B, Liu Z Y, et al.Analyzing spatial and temporal variability of annual water-energy balance in nonhumid regions of China using the Budyko hypothesis[J]. Water Resources Research, 2007, 43(4): W04426.
[19]	杨汉波,杨大文,雷志栋,等. 蒸发互补关系在不同时间尺度上的变化规律及其机理[J].中国科学(E 辑: 技术科学),2009, 39(2): 333~340.
[20]	Milly P C D. Climate, Soil-Water Storage, and the Average Annual Water-Balance[J]. Water Resources Research, 1994, 30(7): 2143-2156.
[21]	崔炳玉. 气候变化和人类活动对滹沱河区水资源变化的影响[D]. 南京,河海大学,2004.
[22]	吴绍洪,尹云鹤,郑度,等.近30年中国陆地表层干湿状况研究[J]. 中国科学(D辑), 2005, 35(3): 276~283.
[23]	Li-Juan Li, Lu Zhang, Hao Wang et al. Assessing the impact of climate variability and human activities on streamflow from the Wuding River basin in China[J]. Hydrological processes, 2007, 21(25):3485-3494.
[24]	李子君,李秀彬.近45年来降水变化和人类活动对潮河流域年径流量的影响[J].地理科学,2008,28(6): 809~813.
[25]	符淙斌,王强.气候突变的定义和检测方法[J].大气科学, 1992,16(04):482~493.
[26]	姜德娟,李志,王昆. 1961~2008年山东省极端降水事件的变化趋势分析[J].地理科学,2011,31(9) :1118~1124.
[27]	刘贵花,栾兆擎,阎百兴,等. 三江平原挠力河上游径流演变趋势及其驱动因素[J].地理科学,2011,31(8) :952~957.
[28]	Fu G B, Chen S L, Liu C M, et al.Hydro-climatic trends of the Yellow River basin for the last 50 years[J]. Climatic Change, 2004, 65(1): 149-178.
[29]	丁一汇,张莉.青藏高原与中国其他地区气候突变时间的比较[J]. 大气科学,2008,4(04): 794~805.
[30]	曹丽青,余锦华,葛朝霞.华北地区大气水分气候变化及其对水资源的影响[J]. 河海大学学报(自然科学版), 2004,32(05):504`507.
[31]	任国玉,郭军,徐铭志,等.近50年中国地面气候变化基本特征[J].气象学报, 2005,63(06): 942~956.

流域	面积(km²)	ω	MB(%)	MAE(mm)	RMSE(mm)	NSE
全流域	15915	2.45	0.32/1.02	20.71/24.28	24.97/28.97	0.86/0.79
芦庄	729	2.1	0.48/4.92	20.13/27.34	23.68/38.59	0.82/0.65
豆罗桥	714	2.35	1.61/-2.04	30.04/27.53	36.54/34.24	0.71/0.74
会里	477	2.45	-0.28/3.85	21.15/22.32	27.4/32.6	0.83/0.56
南坡	2255	2.35	0.59/4.90	12.6/30.74	27.4/36.03	0.93/0.61
王家会	334	2.05	-0.36/-3.38	27.67/30.66	34.65/36.99	0.55/0.53

	E	E₀	P	T_m	T_mx	T_mn	Sun	U_m
突变点年份（年）	无	1979	无	1996	1994	2001	1987	1983
平均变幅(β)	-0.93	-1.16	-1.24	0.0225	0.0271	0.0205	-0.0191	-0.0159
趋势转折点年份	无	1979	1960	1994	1990	1998	1976	1983
阶段趋势	降	无,降	升,降	降,升	降,升	降,升	升,降	升,降
显著点(0.05),年份	1962	无,1989	无	1971,2001	无,2001	1972,2004	无,1989	无,1987

因子	全流域	豆罗桥	芦庄	会里	南坡	王家会
P	1.02	1.025	0.995	1.033	0.996	0.994
Rh	-0.038	-0.041	-	-0.056	-	-
