汉江上游现代大洪水滞流沉积物的粒度分布特征研究

doi:10.13249/j.cnki.sgs.2014.011.1369

摘要/Abstract

摘要：

对汉江上游现代大洪水高水位滞流沉积物（SWD）系统地采样测试分析,结果表明：汉江上游现代大洪水SWD沉积物性质是沙质粘土或粘土质沙、沙质粉沙或粉沙质沙。其分布特征大致分为两大类：安康段以上基本是以粉沙质沙或沙质粉沙为主,安康段以下基本是沙质粘土或粘土质沙。粒度成分和粒度参数都反映现代洪水SWD经过充分的分选,但是受多种因素影响,其粒径组成具有明显的空间变化。水库或大坝对大洪水SWD的粒度自然分布频率单峰曲线尖窄的形状没有明显的影响,而更多与其沉积的微地貌环境和水动力条件有关。

关键词: 现代大洪水, 滞流沉积物, 粒度, 空间分布, 汉江上游

Abstract:

Modern large flood events were marked clearly by grayish slackwater deposits of silty fine sand on the channel side. The most recent large floods in the upper Hanjiang River occurred on 19 July, 2010 with a peak discharge 21 400 m³/s and 19 September, 2011 with a peak discharge 21 000 m³/s as measured in the Baihe gauge station in the upper Hanjiang River basin. Modern flood slackwater deposits (SWD) were systematically investigated and sampled from upstream to downstream along the upper Hanjiang River in 2010-2012. These results showed that modern flood SWD is sandy clay, clay sand, sandy silt and silty sand in the upper Hanjiang River. There are two parts for the distribution of modern flood SWD. Sediment properties of modern flood SWD in the upstream of Ankang section are sandy silt and silty sand, but they are sandy clay and clayey sand in the downstream of Ankang section. The average clay (< 2 μm) content (5.9%) in the upper stream of Ankang section (LSC site) is higher than that in the down stream (clay content 2.1%). The average fine silt (2-16 μm) content (24.7%) in the upper stream of Ankang section (LSC site) is higher than that (17.0%) in the down stream. The average coarse silt (16-63 μm) content of modern flood SWD is 36.4% in the upper Hanjiang River. Clay and fine silt present high values in the upstream of LSC site and low values in the down stream of LSC site. On the contrary, sand (>63 μm) content shows that the low values (33.3%) in the upper stream of LSC site, whereas high values (44.2%) present in the down stream of LSC site. Mean size and medium size of modern flood SWD in the upstream of Ankang section are finer than that in the downstream. Mean size is larger than medium size of modern flood SWD along the upper Hanjiang River. Both sorting and skewness gradually decrease, but kurtosis gradually increases along the upper Hanjiang River. These results reflect that modern flood SWD are suspend deposits during highly energetic flood flows and deposited at long-term preservation. Grain size distribution of modern flood SWD presents obvious spatial variation along the upper Hanjiang River. Grain-size distributions of modern flood SWD are not only controlled by the lithology, topography, geomorphology and hydrology of the upper Hanjiang River, but also affected by the flood SWD sources, hydrologic conditions and micro-geomorphology of the SWD sedimentary environment. The shapes of particle-size distribution frequency curves in the modern flood SWD are more related to the micro-geomorphology environment and hydrodynamic conditions during flood periods, and reservoirs and dams have week influence on the shapes of modern flood SWD in the upper Hanjiang River. The shape of particle-size distribution frequency curve of modern flood SWD is an important proxy for identifying the palaeoflood SWD. These results provide a basic reference to mitigate flood disasters, palaeoflood science, and soil and water conservation in the upper Hanjiang River.

Key words: modern flood, slackwater deposits, grain size, spatial variation, the upper Hanjiang River

中图分类号:

P954

郭永强, 黄春长, 庞奖励, 尚瑞清, 周亚利. 汉江上游现代大洪水滞流沉积物的粒度分布特征研究[J]. 地理科学, 2014, 34(11): 1369-1376.

Yong-qiang GUO, Chun-chang HUANG, Jiang-li PANG, Rui-qing SHANG, Ya-li ZHOU. Grain Size Characteristics of Modern Flood Slackwater Deposits Along the Upper Hanjiang River[J]. SCIENTIA GEOGRAPHICA SINICA, 2014, 34(11): 1369-1376.

图/表 6

参考文献 40

[1]	Knox J C.Large increases in flood magnitude in response to modest changes in climate[J].Nature,1991,361:410-437.
[2]	Walling D E,He Q.The spatial variability of overbank sedimentation on river floodplains[J].Geomorphology,1998,24:209-223.
[3]	Beuselinck L,Steegen A,Govers G,et al.Characteristics of sediment deposits formed by intense rainfall events in small catchments in the Belgian Loam Belt[J].Geomorphology,2000,32:69-82.
[4]	周华,廖富强,徐明星,等.连云港藤花落遗址土壤粒度及重金属累积特征[J].地理科学,2013,33(3):349~355.
[5]	Haritashya U K,Kumar A,Singh P.Particle size characteristics of suspended sediment transported in meltwater from the Gangotri Glacier,central Himalaya—An indicator of subglacial sediment evacuation[J].Geomorphology,2010,122:140-152.
[6]	沈玉昌. 汉水河谷的地貌及其发育史[J].地理学报,1956,22(4):295~323.
[7]	李庆宝. 汉江上游十大洪水气象特征分析[J].灾害学,1991,6(2):39~44.
[8]	杨永德,邹宁,郭希望,等.汉江上游水文特性的初步分析[J].水文,1997,2:54~56.
[9]	张楷. 汉江上游暴雨洪水特性研究[J].灾害学,2006,21(3):98~102.
[10]	周建华. 汉江上游梯级水电开发模式研究[D].西安理工大学博士论文,2002.
[11]	Huang Chun Chang,Pang Jiangli,Zha Xiaochun,et al.Extraordinary hydro-climatic events during the period A D 200-300 recorded by slackwater deposits in the upper Hanjiang River valley,China[J].Palaeogeography Palaeoclimatology Palaeoecology,2013,374:274-283.
[12]	Zhang Yuzhu,Huang Chun Chang,Pang Jiangli,et al.Holocene paleo floods related to climatic events in the upper reaches of the Hanjiang River valley,middle Yangtze River basin,China[J].Geomorphology,2013,195:1-12.
[13]	王龙升,黄春长,庞奖励,等.旬阳东段汉江全新世古洪水研究[J].地理科学进展,2012,31(9):1141~1148.
[14]	李晓刚,黄春长,庞奖励,等.汉江上游白河段万年尺度洪水水文学研究[J].地理科学,2012,32(8):971~978.
[15]	查小春,黄春长,庞奖励,等.汉江上游郧西段全新世古洪水事件研究[J].地理学报,2012,67(5):671~680.
[16]	乔晶,庞奖励,黄春长,等.汉江上游郧县前坊段全新世古洪水水文学研究[J].长江流域资源与环境,2012,21(5):533~539.
[17]	虎亚伟,庞奖励,黄春长,等.汉江上游郧西段全新世古洪水水文学研究[J].自然灾害学报,2012,21(5):55~62.
[18]	许洁,黄春长,庞奖励,等.汉江上游安康东段全新世古洪水沉积学与水文学研究[J].湖泊科学,2013,25(3):445~454.
[19]	刘建芳,查小春,黄春长,等.汉江上游郧县尚家河段全新世古洪水水文学研究[J].水土保持学报, 2013,27(2):90~94.
[20]	Huang Chun Chang,Pang Jiangli,Su Hongxia,et al.Impact of monsoonal climatic change on Holocene overbank flooding along Sushui River,middle reach of the Yellow River,China[J].Quaternary Science Reviews,2007,26:2247-2264.
[21]	Huang Chun Chang,Pang Jiangli,Su Hongxia,et al.Holocene environmental change inferred from the loess-palaeosol sequences adjacent to the floodplain of the Yellow River,China[J].Quaternary Science Reviews,2009,28:2633-2646.
[22]	Huang Chun Chang,Pang Jiangli,Zha Xiaochun,et al.Extraordinary Floods of 4 100-4 000 a B.P.recorded at the Late Neolithic Ruins in the Jinghe River Gorges,Middle Reach of the Yellow River,China[J].Palaeogeography,Palaeoclimatology,Palaeoecology,2010,28:1-9.
[23]	Huang Chun Chang,Pang Jiangli,Zha Xiaochun,et al.Extraordinary floods related to the climatic event at 4 200 a B.P. on the Qishuihe River,middle reaches of the Yellow River,China[J].Quaternary Science Reviews,2011,30:460-468.
[24]	庞奖励,乔晶,黄春长,等.前处理过程对汉江上游谷地“古土壤”粒度测试结果的影响研究[J].地理科学,2013,33(6):748~753.
[25]	詹道江,谢悦波.古洪水研究[M].北京:中国水利水电出版社,2001:17~21.
[26]	张晓华,潘贤娣,李勇,等.黄河中游干流泥沙组成规律[J].泥沙研究,1998,(4):70~74.
[27]	周娜,张春来,刘永刚.雅鲁藏布江米林宽谷段新月形沙丘粒度分异研究[J].地理科学,2011,31(8):958~963.
[28]	王丰年,李保生,王江龙,等.萨拉乌苏河流域MGS2层段粒度与CaCO3记录的千年尺度气候变化[J].地理科学,2012,32(5):596~602.
[29]	Vandenberghe J,Moor J J W,Spanjaard G.Natural change and human impact in a present-day fluvial catchment:The Geul River,Southern Netherlands[J].Geomorphology,2012,160:1-14.
[30]	刘爱霞,卢金发.黄河中游悬移质泥沙粒径与流域环境关系[J].地理学报,2002,57(2):232~237.
[31]	许炯心. 黄河中游支流悬移质粒度与含沙量、流量间的复杂关系[J].地理研究,2003, 22(1):39~48.
[32]	刘新有,何大明.怒江流域悬移质输沙时空分布特征及变化趋势[J].地理学报,2013,68(3):365~371.
[33]	Nicola Surian.Downstream variation in grain size along an Alpine river: analysis of controls and processes[J].Geomorphology,2002,43:137-149.
[34]	Erik W H,Erin R K,Jacob O S,et al.Climatic and geomorphic interactions on alluvial fans in the Atacama Desert,Chile[J].Geomorphology,2010,121:184-196.
[35]	Michael M B.Controls on overbank deposition in the Upper Mississippi River[J].Geomorphology,2003,56:271-290.
[36]	Zhang Yuzhu,Huang Chun Chang,Pang Jiangli,et al.Comparative study of the modern flood slackwater deposits in the upper reaches of Hanjiang and Weihe River Valleys,China[J].Quaternary International,2012,282:184-191.
[37]	沈泽昊,张全发,岳超,等.南水北调中线水源区土地利用/土地覆被的空间格局[J].地理学报,2006,61(6):633~644.
[38]	黄宁波,王义民,苏保林.汉江上游洪水特性复杂度分析[J].南水北调与水利科技,2012,10(1):45~48.
[39]	Wang Zhao Yin,Wu Baosheng,Wang Guangqian.Fluvial processes and morphological response in the Yellow and Weihe Rivers to closure and operation of Sanmenxia Dam[J].Geomorphology,2007,91:65-79.
[40]	Wenhao Yuan,Daowei Yin,Brian Finlayson,et al.Assessing the potential for change in the middle Yangtze River channel following impoundment of the Three Gorges Dam[J].Geomorphology,2012,148:27-34.
