湘江流域中下游长沙地区不同水体中δ18O、δD的变化

doi:10.13249/j.cnki.sgs.2014.04.488

地理科学 ›› 2014, Vol. 34 ›› Issue (4): 488-495.doi: 10.13249/j.cnki.sgs.2014.04.488

湘江流域中下游长沙地区不同水体中δ¹⁸O、δD的变化

吴华武^1,²(), 章新平¹(), 李小雁², 李静^3,⁴, 张剑明⁵

1.湖南师范大学资源与环境科学学院,湖南长沙 410081
2.北京师范大学资源学院,北京 100875
3.中国科学院地理科学与资源研究所,北京100101
4.中国科学院大学,北京100049
5.湖南省株洲市气象局,湖南株洲 412000

收稿日期:2013-01-02 修回日期:2013-04-28 出版日期:2014-04-10 发布日期:2014-04-10
作者简介:
作者简介:吴华武(1986-),男,江西九江人,博士研究生,主要从事气候变化与水文同位素方面研究。E-mail:wuhuawu416@163.com
基金资助:
国家自然科学基金项目(41171035)、湖南省十二五重点学科建设项目(2012001)及中央高校基本科研业务费专项资助

The Variations of δ¹⁸O and δD in Different Water Bodies of Changsha Region, Middle-and-Low Reach of the Xiangjiang River

Hua-wu WU^1,²(), Xin-ping ZHANG¹(), Xiao-yan LI², Jing LI^3,⁴, Jian-ming ZHANG⁵

1.College of Resources and Environment Sciences, Hunan Normal University, Changsha, Hunan 410081, China
2.College of Resources Science and Technology, Beijing Normal University, Beijing 100875,China
3.Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China
4.University of Chinese Academy of Sciences, Beijing 100049, China
5.Zhuzhou Meteorological Bureau, Zhuzhou, Hunan 412000, China

Received:2013-01-02 Revised:2013-04-28 Online:2014-04-10 Published:2014-04-10

摘要/Abstract

摘要：

根据2010年在长沙地区所收集的降水、河水、泉水和井水水样资料,分析了取样期间不同水样稳定同位素的变化特征,并结合湘江长沙段水位和相关气象资料,揭示了降水中δ¹⁸O、δD因水汽来源不同而其表现出冬半年高、夏半年低的特点;由于降水降落于地表后,地表对降水滞留作用而使得河水、泉水和井水中δ¹⁸O、δD的波动幅度明显小于降水中δ¹⁸O的波动幅度;在汛期,河水中δ¹⁸O算术平均值大于降水,在枯水期河水中δ¹⁸O比泉水和井水中δ¹⁸O要大;河水线(RWL)的斜率和截距与全球大气水线(GMWL)比较接近,说明该地区位于季风区河流的补给主要来自大气降水,井水线(WWL)的斜率和截距比泉水线(SWL)要小,这表明降水入渗形成井水过程中经历的蒸发作用要比形成泉水要强,井水补给比泉水补给要复杂。这为今后研究该地区地表水-地下水-大气降水之间转换关系提供了科学依据,对掌握“三水”间转换规律和合理开发利用水资源具有重要的意义。

关键词: δ18O, δD, 大气降水, 河水, 泉水, 井水

Abstract:

Based on the collected water samplings of precipitation, river, spring and well water during the whole year of 2010 in Changsha region, the variation characteristics of δ¹⁸O, δD in different water samples were investigated combining with the related meteorological parameters and water-level data of Changsha region, the Xiangjiang River. It revealed that the isotopic compositions (δ¹⁸O and δD) had a high values in winter year and a low values in summer year due to different moist sources. The fluctuations of isotopic compositions (δ¹⁸O and δD) in river, spring, and well water were slower than in precipitation due to retention effect after the precipitation descends to the surface. The arithmetic average δ¹⁸O value in river water was larger than in precipitation during the flood period and in spring and well water during the dry period. The slope and intercept of river water line (RWL) was closely to the global meteoric water line (GMWL), suggesting that the river recharge mainly originating from the precipitation in the monsoon region. The slope and intercept of well water line (WWL) was lower than the spring water line (SWL), indicating that the infiltration process of precipitation into well water had experienced stronger evaporation effect than the process into spring water, which is due to the complex recharge sources between well water and spring water. This may provide a scientific foundation for the future investigation of the conversion correlation among the surface water, groundwater and precipitation in this region. It has vital significance for understanding the three-water conversion correlation pattern and properly exploiting and utilizing water source.

Key words: δ18O, δD, precipitation, river water, spring water, well water

中图分类号:

P339

吴华武, 章新平, 李小雁, 李静, 张剑明. 湘江流域中下游长沙地区不同水体中δ¹⁸O、δD的变化[J]. 地理科学, 2014, 34(4): 488-495.

Hua-wu WU, Xin-ping ZHANG, Xiao-yan LI, Jing LI, Jian-ming ZHANG. The Variations of δ¹⁸O and δD in Different Water Bodies of Changsha Region, Middle-and-Low Reach of the Xiangjiang River[J]. SCIENTIA GEOGRAPHICA SINICA, 2014, 34(4): 488-495.

图/表 6

图1

图2

表1

图3

图4

图5

参考文献 33

[1]	Eric S. Posmentier,Xiahong Feng,Meixun Zhao. Seasonal variations of precipitation δ18O in eastern Asia[J].Journal of Geophysical Research, 2004, 109(D23),doi:10.1029/2004JD004510.
[2]	Yurtever Y.Worldwide survey of stable isotopes in precipitation[R].Report of the Isotope Hydrology Section,Vienna:International Atomic Energy Agency,1975,1-40.
[3]	Dansgaard W.Stable isotopes in precipitation[J].Tellus, 1964, 16(4):436-468.
[4]	Yamanaka T, Tsujimura M, Oyunbaatar D, et al.Isotopic variation of precipitation over eastern Mongolia and its implication for the atmospheric water cycle[J]. Journal of Hydrology,2007,333(1):21-34.
[5]	Zhang X P, Liu J M, Tian L D, et al.Variations of d18O in precipitation along vapor transport paths[J]. Advance in Atmospheric Science,2004,21(4): 562-572.
[6]	Dutton A, Wilkinson B H,Welker J M, et al.Spatial distribution and seasonal variation in 18O/16O of modern precipitation and river water across the conterminous USA[J]. Hydrological Processes, 2005,19(20):4121-4146.
[7]	Turner J V,Macpherson D K,Stokes R A.The mechanisms of catchment flow processes using natural variations in deuterium and oxygen-18[J]. Journal of Hydrology,1987,94(1):143-162.
[8]	McDonnell J J, Stewart M K,Owens I F.Effect of catchment-scale subsurface mixing on stream isotopic response[J].Water Resource Reseach, 1991, 27(12):3065-3073.
[9]	Buttle J M.Isotope hydrograph separations and rapid delivery of pre-event water from drainage basins[J]. Progress in Physical Geography,1994, 18(1):16-41.
[10]	McCarthy K A, McFarland W D, Wilkinson J M,et al. The dynamic relationship between ground water and the Columbia River: using deuterium and oxygen-18 as tracers[J]. Journal of Hydrology, 1992, 135(1):1-12.
[11]	Song X, Kayane I,Tanaka T, et al.A study of the groundwater cycle in Sri Lanka using stable isotopes[J]. Hydrological Processes, 1999,13(10):1479-1496.
[12]	Neil L.Ingraham, Bruce E,et al.Light stable isotope systematics of large-Scale hydrologic regimes in California and Nevada[J]. Water Resource Reseach, 1991, 27(1):77-90.
[13]	张应华,仵彦卿.黑河流域不同水体中δ18O的变化[J].水科学进展,2007,18(6):864~870.
[14]	章新平,姚檀栋,田立德,等.乌鲁木齐河流域不同水体中的氧稳定同位素[J].水科学进展,2003,14(1): 50~56.
[15]	杨淇越,吴锦奎,丁永建,等.锡林河流域地表水和浅层地下水的稳定同位素研究[J].冰川冻土,2009,31(5):850~856.
[16]	高晶,田立德,刘勇勤,等.青藏高原南部羊卓雍错流域稳定同位素水文循环研究[J].科学通报,2009,54(15):2153~2159.
[17]	田立德,姚檀栋,沈永平,等.青藏高原那曲河流域降水及河流水体中氧稳定同位素研究[J].水科学进展,2002,13(2):206~210.
[18]	宋献方,李发东,于静洁,等.基于氢氧同位素与水化学的潮白河流域地下水水循环特征[J].地理研究,2007,26(1):11~21.
[19]	于静洁, 宋献方,刘湘超,等. 基于δD和δ18O及水化学的永定河流域地下水循环特征解析[J].自然资源学报,2007,22(3):415~423.
[20]	薛积彬,钟巍,赵引娟.广州大气降水中δ18O与气象要素及季风活动之间的关系[J].冰川冻土,2008,30(5):761~768.
[21]	章新平,刘晶淼,孙维贞,等.中国西南地区降水中氧稳定同位素比率与相关气象要素之间关系的研究[J].中国科学(D),2006,36(9):850~859.
[22]	涂林玲,王华,冯玉梅.桂林地区大气降水的D与18O同位素研究[J].中国岩溶,2004,23(4):304~309.
[23]	Risi C, Bony S,Vimeux F.Influence of convective processes on the isotopic composition (δ18O and δD) of precipitation and water vapor in the tropics: 2. Physical interpretation of the amount effect[J]. Journal of Geophysical Research, 2008,113(D19306),doi:10.1029/2008JD009943.
[24]	章新平,刘晶淼,中尾正义,等.我国西南地区降水中过量氘指示水汽来源[J].冰川冻土,2009,31(4):613~619.
[25]	顾慰祖. 集水区降雨径流晌应的环境同位素实验研究[J]. 水科学进展,1992,3(4):247~254.
[26]	Craig H.Isotopic variations with meteoric water[J]. Science, 1961, 133:1702-1703.
[27]	Gonfiantini R.Environmental isotopes in lake studies[M].Handbook of Environmental Isotope Geochemistry,The Terrestrial Environment.Amsterdam:Elsevier, 1986,2:113-168.
[28]	Gibson J J, Edwards T W D, Birks S J, et al. Progress in isotope tracer hydrology in Canada[J]. Hydrological Processes, 2005, 19(1):303-327.
[29]	章新平,姚檀栋,田立德,等.湿度效应及其对降水中δ18O季节分布的影响[J].冰川冻土,2004,26(4):420~425.
[30]	章新平,姚檀栋.我国降水中δ18O的分布特点[J].地理学报,1998,54(3): 356~364.
[31]	武亚遵,万军伟,林云.湖北宜昌西陵峡地区大气降水氢氧稳定同位素特征分析[J].地质科学情报,2011,20(3): 93~97.
[32]	田日昌,陈洪松,宋献方,等.湘西北红壤丘陵区土壤水运移的稳定性同位素特征[J].环境科学,2009,30(9): 2747~2754.
[33]	Kendall, C, Coplen, T B.Distribution of oxygen-18 and deuterium in river waters across the United States[J]. Hydrological processes,2001,15(7):1363-1393.

	平均		夏半年		冬半年		季节差
	δ¹⁸O(‰)	δD(‰)	δ¹⁸O(‰)	δD(‰)	δ¹⁸O(‰)	δD(‰)	Δδ¹⁸O(‰)	ΔδD(‰)
降水(*)	-6.43	-53.3	-8.35	-54.5	-5.42	-26.5	-2.93	-28
河水	-5.56	-36	-6.03	-37.1	-5.73	-35.2	-0.3	-1.9
泉水	-6.43	-35.4	-6.32	-34.4	-6.5	-36.2	0.18	1.8
井水	-6.56	-38.3	-6.85	-39.8	-6.32	-37.1	-0.53	-2.7
