基于空间重构视角的老工业区人地关系研究——以沈阳市铁西区为例

doi:10.13249/j.cnki.sgs.2015.07.890

摘要/Abstract

摘要：

以铁西老工业区为例,通过2000年、2005年和2010年的航片及遥感影像数据,结合300 m×300 m网格的5 206栋建筑单体的人工调查,基于GIS及制度理论,从空间重构视角揭示了微观尺度人地系统演化特征,阐明了人地结构变化的动力机制。铁西老工业区空间重构主要表现为级差地租支撑下的企业搬迁：1938~2000年呈南北格局,2000年后快速转化为东西格局。以政府、企业和公众为主要分析对象构建空间重构动力分析模型,结果表明：政策条件对人地系统演化具有直接影响,其作用效力依赖于产业结构类型及其与周边区域经济活动的关联性。

关键词: 人地关系, 老工业区, 空间重构, 土地利用

Abstract:

Understanding human-land relationships is essential for optimizing human activities in order to achieve local and global sustainability. China’s rapid urbanization is attracting much global attention; however, one of the challenges to achieve sustainable urbanization in China is to determine appropriate development mechanisms related to human-land relationships. As one of the typical industrial bases in China, the Tiexi District in Shenyang suffered from serious decline but now is shifting its industrial structure from heavy industries to tertiary ones, along with essential improvement of natural ecosystems and re-structuring of land use. Using Tiexi District as a case study, this article investigates the evolution of the human-land relationships in the context of urban spatial restructuring based on both qualitative and quantitative analysis of temporal and spatial elements. Following the literature review, a database was built, based on interpretations of aerial photographs of Tiexi in 2000 and of the Quickbird Images in 2005 and 2010, combined with a survey on existing buildings. Subsequently, GIS was employed to identify the evolution of both characteristics and driving forces of the human-land relationship changes at both micro and meso scales. The new economic and technical development zone provided opportunities and resources for enterprise redevelopment, especially related to four strategies: entire-move-out, partial-move-out, bankruptcy and redevelopment on original site. Structures and functions have changed markedly during 2000 to 2010. For example, industrial land use was reduced from 1 486 hm² in 2000 to 842 hm² in 2010 while residential land use increased from 1 077 hm² in 2000 to 1 452 hm² in 2010; commercial and service industries land increased from 59 hm² in 2000 to 110 hm² in 2010; and land use for public facilities, transport and roads and welfare remained almost the same level compared to that in 2000 and 2010. In addition, the per-capita living space of the residents has grown from 6.0 m2 in 2000 to 28.6 m2 in 2010; and, per-capita green land jumped to 4.15 m² which was an increase of 39% compared to 2000. Finally, a total of 5206 buildings were investigated by a field-survey, and information was obtained for 3 702 of them regarding the year they were built, and of the land occupied, which was about 1 102 hm². The results show that the land area covered by the buildings built during 2000-2010, 1980-1999 and 1949-1980 is about 743 hm², 304 hm² and 63 hm², respectively. Since 2000 the land use distribution has shifted from a “South-North Pattern” to an “East-West Pattern” which confirms that the external resources and policy tools have had serious affects on the evolution of regional human-land development. Finally, government, public and private firms were identified as the 3 main agents and investigated their roles and interactions.

Key words: human-land relationship, old industrial area, spatial reconstruction, land use

中图分类号:

K901.8

薛冰, 张黎明, 耿涌, 任婉侠, 逯承鹏, 田旭. 基于空间重构视角的老工业区人地关系研究——以沈阳市铁西区为例[J]. 地理科学, 2015, 35(7): 890-897.

Bing XUE, Li-ming ZHANG, Yong GENG, Wan-xia REN, Cheng-peng LU, Xu TIAN. Spatial-restructuring Analysis of Human-land Relationships in An Old Industrial Area: The Case of the Tiexi District, Shenyang[J]. SCIENTIA GEOGRAPHICA SINICA, 2015, 35(7): 890-897.

图/表 5

参考文献 45

[1]	吴传钧. 论地理学的研究核心——人地关系地域系统[J].经济地理,1991,11(1):1~6.
[2]	吴传钧. 地理学的特殊研究领域和今后任务[J]. 经济地理,1981,1(1):5~10,21.
[3]	陆大道. 向100年来为国家和人类做出贡献的地理学家致敬——纪念中国地理学会成立100周年[J].地理学报, 2009,64(10):1155~1163.
[4]	郑度. 21世纪人地关系研究前瞻[J].地理研究, 2002, 21(1):9~13. doi: 10.3321/j.issn:1000-0585.2002.01.002
[5]	史培军,王静爱,陈婧,等.当代地理学之人地相互作用研究的趋向——全球变化人类行为计划第六届开放会议透视[J].地理学报,2006,61(2):115~126.
[6]	毛汉英. 人地系统与区域可持续发展研究[M].北京:中国科学技术出版社,1995.
[7]	方创琳. 中国人地关系的新进展与展望[J].地理学报,2004,10(59):21~32.
[8]	宋长青,冷疏影.当代地理学特征、发展趋势及中国地理学研究进展[J].地球科学进展,2005,20(6):595~599. doi: 10.3321/j.issn:1001-8166.2005.06.001
[9]	劳爱乐,耿勇.工业生态学和生态工业园[M].北京:化学工业出版社, 2003.
[10]	韩良,宋涛,佟连军.典型生态产业园区发展模式及其借鉴[J].地理科学, 2006, 26(2):237~243. doi: 10.3969/j.issn.1000-0690.2006.02.018
[11]	Côté R, Hall J.Industrial parks as ecosystems[J].Journal of Cleaner Production,1995, 3(1/2): 41-46. doi: 10.1016/0959-6526(95)00041-C
[12]	Ehrenfeld J, Gertler N.Industrial Ecology in Practice: The Evolution of Interdependence at Kalundborg[J].Journal of Industrial Ecology, 1997,1(1):67-79. doi: 10.1162/jiec.1997.1.1.67
[13]	陆大道. 关于地理学的"人-地系统" 理论研究[J].地理研究,2002,21(2):135~145. doi: 10.3321/j.issn:1000-0585.2002.02.001
[14]	方创琳,黄金川.高科技园区与城市协调发展的生态调控[J].地理学报,2003,58(3):390~397. doi: 10.3321/j.issn:0375-5444.2003.03.008
[15]	王黎明,关庆锋,冯仁国,等.全球变化视角下人地系统研究面临的几个问题探讨[J].地理科学,2003,23(4): 391~397. doi: 10.3969/j.issn.1000-0690.2003.04.002
[16]	Young R.The institutional dimensions of environmental change: fit, interplay, and scale [M]. Cambridge: MIT Press, 2002.
[17]	Berkhout F, Hertin J, Gann D M.Learning to adapt:Organizational adaptation to climate change impacts[J].Climatic Change, 2006, 78(1):135-156. doi: 10.1007/s10584-006-9089-3
[18]	姜逢清,朱诚,穆桂金,等. 新疆绿洲当代人地关系紧张情势与缓解途径[J].地理科学, 2003,23(2):157~164. doi: 10.3969/j.issn.1000-0690.2003.02.005
[19]	陈忠祥. 宁夏南部回族社区人地关系及可持续发展研究[J].人文地理,2002,17(1):39~43. doi: 10.3969/j.issn.1003-2398.2002.01.006
[20]	乔家君. 区域人地关系定量研究[J].人文地理,2005,20(1):81~85.
[21]	Liu J, Dietz T, Carpenter S, et al.Complexity of coupled human and natural systems[J]. Science,2007,317(5844): 1513-1516. doi: 10.1126/science.1144004 pmid: 17872436
[22]	顾朝林,甄峰,张京祥.集聚与扩散——城市空间结构新论[M].南京:东南大学出版社,2000.
[23]	石崧. 城市空间结构演变的动力机制分析[J].城市规划汇刊,2004,(1):50~55. doi: 10.3969/j.issn.1000-3363.2004.01.012
[24]	许学强,周素红.20世纪80年代以来我国城市地理学研究的回顾与展望[J].经济地理,2003,23(4):433~440. doi: 10.3969/j.issn.1000-8462.2003.04.001
[25]	张庭伟. 1990年代中国城市空间结构的变化及其动力机制[J].城市规划,2001,25(71):7~14. doi: 10.3321/j.issn:1002-1329.2001.07.002
[26]	赵云伟. 当代全球城市的城市空间重构[J].国外城市规划,2000,(5): 2~7. doi: 10.3969/j.issn.1673-9493.2001.05.002
[27]	房艳刚,刘鸽,刘继生.城市空间结构的复杂性研究进展[J].地理科学,2005,25(6):754~761. doi: 10.3969/j.issn.1000-0690.2005.06.018
[28]	刁琳琳. 中国城市空间重构对经济增长的效应机制分析[J].中国人口资源与环境,2010,20(5):87~94. doi: 10.3969/j.issn.1002-2104.2010.05.015
[29]	潘海啸. 面向低碳的城市空间结构:城市交通与土地使用的新模式[J].城市发展研究,2010,17(1):40~45. doi: 10.3969/j.issn.1006-3862.2010.01.007
[30]	Garcia-Lopez M.Urban spatial structure, suburbanization and transportation in Barcelona[J].Journal of Urban Economics,2012,72(2-3):176-190. doi: 10.1016/j.jue.2012.05.003
[31]	马学广. 城市空间的社会生产与土地利用冲突研究——以广州市海珠区为例[D].广州:中山大学,2008.
[32]	马学广,王爱民,闫小培.城市空间重构进程中的土地利用冲突研究——以广州市为例[J].人文地理,2010,25(3):72~77.
[33]	李东生. 大城市老工业区工业用地的调整与更新——上海市杨浦区改造实例[M].上海:同济大学出版社,2005.
[34]	Liu J, Liu M, Zhuang D.Study on spatial pattern of land-use change in China during 1995-2000[J].Science in China Series D: Earth Sciences, 2003,46(4):69-75. doi: 10.1360/03yd9033
[35]	顾丽娜. 铁西今昔[J].兰台世界,2002,(7):41.
[36]	庞红. 建国前沈阳铁西工业区的形成[J].兰台世界,2005,(7):137~138.
[37]	王伟强. 和谐城市的塑造——关于城市空间形态演变的政治经济学实证分析[M].北京:中国建筑工业出版社,2005.
[38]	徐勇,马国霞,沈洪泉.北京丰台区土地利用变化及其经济驱动力分析[J].地理研究,2005,24(6):860~869. doi: 10.3321/j.issn:1000-0585.2005.06.005
[39]	Ren W, Xue B, Geng Y, et al.Inventorying heavy metal pollution in redeveloped brownfield and its policy contribution: case study from Tiexi district, China[J]. Land Use Policy,2014,38:138~146.
[40]	鲁春阳,文枫,杨庆媛. 城市土地利用结构影响因素的通径分析——以重庆市为例[J].地理科学,2012,32(8):936~943.
[41]	薛冰. 区域循环经济发展机制研究[D].兰州:兰州大学,2009.
[42]	吴丰林,方创琳,赵雅萍.城市产业集聚动力机制与模式研究的PAF模型[J].地理研究,2011,30(1):71~82. doi: 10.11821/yj2011010007
[43]	袁丽丽,黄绿筠.城市土地空间结构演变及其驱动机制分析[J].城市发展研究,2005,12(1):64~69. doi: 10.3969/j.issn.1006-3862.2005.01.017
[44]	王新涛. 城市空间结构演变的动力系统分析[J].北方经济,2009,(11):33~35.
[45]	王颖. 信息网络革命影响下的城市——城市功能的变迁与城市结构的重构.城市规划[J],1999,23(8):24~27. doi: 10.1088/0256-307X/16/9/020
