基于参与式调查与主成分分析的金塔绿洲变化驱动力分析

doi:10.13249/j.cnki.sgs.2016.02.019

摘要/Abstract

摘要：

内陆河流域绿洲变化驱动机制是旱区绿洲学研究的核心内容之一。利用1963~2010年的Keyhole存档相片、KATE-200卫星航片、Landsat遥感影像等多源数据,获取了金塔绿洲空间分布及面积变化信息。在此基础上,结合参与式调查和主成分分析方法定量分析绿洲变化的驱动机制。研究表明：近47 a来金塔绿洲总体呈现增长的趋势,绿洲规模不断扩大,至2010年绿洲面积高达539.47 km²。其主要原因是气候变化、人口增加、水资源的开发利用与科技进步、社会经济发展及政策等因子的相互交织作用。气候变化是背景因子,人文因子是绿洲变化的主成分因素,且在不同历史社会背景下,其主导人文因素也不同。

关键词: 绿洲变化, 参与式调查访谈, 主成分分析, 驱动力, 金塔绿洲

Abstract:

As a unique geographical landscape of arid area, oasis was the main space of human activity in arid area, and its change was the most direct reflection of environmental change. Recently, spatiotemporal change of oasis and its driving forces was one of the hot issues of oasis study. Jinta oasis, a typical artificial and agricultural oasis in the lower reaches of Beida River Basin in arid China, had experienced drastic change in the past 50 years, was selected as a case to study the spatiotemporal change and its driving forces. Based on Keyhole satellite photograph, KATE-200, Landsat MSS, TM and ETM images in 1963-2010, as well as field interviews and governmental socioeconomic statistics data, this study investigated and discussed the driving forces of Jinta oasis change during 1963-2010 by combining with participatory rural appraisal and principal component analysis. The results showed that oasis area and scale expanded gradually, and the area achieved its maximum with 539.47 km² in 2010. Oasis changes had been resulted from the interaction of natural environmental changes and human activities. Human driving factors include population, policy, economic development, the progress of agricultural science and technology, environmental awareness, while the natural environment change was been represented by climatic factors (such as rainfall, air temperature) and runoff. In our study, the first and second main components of driving forces were population growth, water resources development and utilization, technical renovation, economic development and policy, the thirds was annual temperature, suggesting that human driving force played a dominant role. In addition, the main human driving forces behind oasis changes were varied in different historical periods. In 1963-1980, the dominant driving force was population growth and policy, whereas the dominant driving forces in 1980-1990 were the changes in agricultural production ways (such as household contract responsibility system) and population growth. In the period of 1990-2000, all sorts of driving forces interacted and associated mutually. Since 2002, economic benefit and water utilization were the dominant factors.

Key words: oasis change, participatory rural appraisal, principal component analysis, driving mechanism, Jinta Oasis

中图分类号:

F301.21

谢余初, 张影, 钱大文, 巩杰, 颉耀文, 常根应. 基于参与式调查与主成分分析的金塔绿洲变化驱动力分析[J]. 地理科学, 2016, 36(2): 312-320.

Yuchu Xie, Ying Zhang, Dawen Qian, Jie Gong, Yaowen Xie, Genying Chang. Driving Forces of Jinta Oasis Changes Based on Participatory Rural Appraisal and Principal Component Analysis[J]. SCIENTIA GEOGRAPHICA SINICA, 2016, 36(2): 312-320.

图/表 7

表1

图1

表2

图2

图3

图4

图5

参考文献 22

[1]	吴健生,王政,张理卿,等.景观格局变化驱动力研究进展[J].地理科学进展,2012,31(12):1739-1746. doi: 10.11820/dlkxjz.2012.12.021
	[Wu Jiansheng, Wang Zheng, Zhang Liqing, et al.Research progresses on driving forces of the changes of landscape pattern.Progress in Geography,2012,31(12):1739-1746.] doi: 10.11820/dlkxjz.2012.12.021
[2]	Lambin E F, Geist H J.Land-use and Land Cover Change: Local processes and global impacts[M].Berlin: Springer,2006.
[3]	Jia Baoquan, Zhang Zhiqiang, Ci Jongjun, et al.Oasis land-use dynamics and its influence on the oasis environment in Xinjiang, China[J].Journal of Arid Environments,2004,56(1):11-26. doi: 10.1016/S0140-1963(03)00002-8
[4]	Xie Yuchu, Gong Jie, Sun Peng, et al.Oasis dynamics change and its influence on landscape pattern on Jinta oasis in arid China from 1963a to 2010a: Integration of multi-source satellite images[J].International Journal of Applied Earth Observation and Geoinformation, 2014, 33:181-191. doi: 10.1016/j.jag.2014.05.008
[5]	陈隆亨. 荒漠绿洲的形成条件和过程[J].干旱区资源与环境,1995,9(3):49-57.
	[Chen Longheng.Formation conditions and processes of desert oases. Journal of Arid Land Resources and Environment, 1995,9(3):49-57.]
[6]	樊自立,穆桂金,马英杰,等.天山北麓灌溉绿洲的形成和发展[J].地理科学,2002,22(2):184-189. doi: 10.3969/j.issn.1000-0690.2002.02.010
	[Fan Zili, Mu Guijin, Ma Yingjie, et al.Formation and development of the artificially irrigated oases in the northern piedmont of the Tianshan mountains.Scientia Geographica Sinica,2002,22(2):184-189.] doi: 10.3969/j.issn.1000-0690.2002.02.010
[7]	Li Xiaoyu, Xiao Duning, He Xingyuan, et al.Factors associated with farmland area changes in arid regions: a case study of the Shiyang River basin, northwestern China[J].Frontiers in Ecology and the Environment, 2007,5(3): 139-144. doi: 10.1890/1540-9295(2007)5[139:FAWFAC]2.0.CO;2
[8]	Luo Gegeng, Zhou Chenghu, Chen Xi, et al.A methodology of characterizing status and trend of land changes in oases: A case study of Sangong river watershed, Xinjiang, China[J].Journal of Environmental Management, 2008, 88(4):775-783. doi: 10.1016/j.jenvman.2007.04.003
[9]	张勃,毛彦成,柳景峰.黑河中游土地利用/覆盖变化驱动力的定量分析[J].干旱区地理,2006,29(5):726-730. doi: 10.3321/j.issn:1000-6060.2006.05.018
	[Zhang Bo, Mao Yancheng, Liu Jingfeng.Analysis driving forces of LUCC in Heihe middle reaches.Arid Land Geography,2006,29(5):726-730.] doi: 10.3321/j.issn:1000-6060.2006.05.018
[10]	巩杰,谢余初,孙朋,等.乡镇尺度金塔绿洲时空格局变化[J].生态学报,2013,33(11):3470-3479. doi: 10.5846/stxb201203300445
	[Gong Jie, Xie Yuchu, Sun Peng, et al.Spatio-temporal change on township scale of Jinta oasis in the latest 20 years. Acta Ecologica Sinica, 2013,33(11):3470-3479.] doi: 10.5846/stxb201203300445
[11]	Zhao Ruifeng, Chen Yaning, Shi Peiji, et al.Land use and land cover change and driving mechanism in the arid inland river basin: a case study of Tarim River, Xinjiang, China[J].Environmental Earth Sciences, 2013,68(2):591-604. doi: 10.1007/s12665-012-1763-3
[12]	常跟应,李国敬,颉耀文,等.近60年来民乐县农业绿洲扩张的人文驱动机制[J].兰州大学学报:自然科学版, 2013,49(2):221-225.
	[Chang Genying, Li Guojing, Xie Yaowen, et al.Human driving forces behind agricultural oasis expansion in Minle County, Gansu Province in the past 60 years. Journal of Lanzhou University (Natural Sciences), 2013, 49(2):221-225.]
[13]	田文婷,颉耀文,陈云海.甘肃省高台县绿洲变化的人文驱动力[J].兰州大学学报:自然科学版,2014,50(2): 180-185. doi: 10.3969/j.issn.0455-2059.2014.02.006
	[Tian Wenting, Xie Yaowen, Chen Yunhai.Human driving forces behind oasis changes in Gaotai County, Gansu Province. Journal of Lanzhou University (Natural Sciences), 2014,50(2): 180-185.] doi: 10.3969/j.issn.0455-2059.2014.02.006
[14]	Wang Yang, Chen Yaning, Ding Jianli, et al. Land-use conversion and its attribution in the Kaidu-Kongqi River Basin, China[J]. Quaternary International,2015, 380-381: 216-223.
[15]	康相武,潘伯荣,周华荣.干旱区廊道景观及其研究之管见[J].干旱区研究,2000,17(3):64-70.
	[Kang Xiangwu, Pan Borong, Zhou Huarong.Some viewpoints on corridor landscape in arid zone and research on it.Arid Zone Research,2000,17(3):64-70.]
[16]	巩杰,谢余初,高彦净,等.1963-2009年金塔绿洲变化对绿洲景观格局的影响[J].生态学报,2015,33(3):603-612. doi: 10.5846/stxb201304080639
	[Gong Jie, Xie Yuchu, Gao Yanjing, et al.Spatio-temporal change and its effects on landscape pattern of Jinta Oasis in Arid China from 1963 to 2009[J]. Acta Ecologica Sinica, 2015,35(3):603-612.] doi: 10.5846/stxb201304080639
[17]	赵杰,赵士洞.利用PRA方法研究小尺度区域土地利用变化——以科尔沁沙地尧勒甸子村为例[J].地域研究与开发, 2004,23(1):73-76. doi: 10.3969/j.issn.1003-2363.2004.01.018
	[Zhao Jie, Zhao Shidong.Apply the participatory rural appraisal method to the research of land use change in local scale: A case study of village Yaoledianzi of Korqin sands.Areal Research and Development, 2004,23(1):73-76.] doi: 10.3969/j.issn.1003-2363.2004.01.018
[18]	朱慧,张新焕,焦广辉,等.基于PRA的新疆三工河流域农户土地利用差异研究[J].干旱区资源与环境,2012, 26(6):90-95.
	[Zhu Hui, Zhang Xinhuan, Jiao Guanghui, et al.Research on farm household’s choice of land use type over the Sangong River Basin in Xinjiang based on PRA.Journal of Arid Land Resources and Environment,2012, 26(6):90-95.]
[19]	吴美琼,陈秀贵.基于主成分分析法的钦州市耕地面积变化及其驱动力分析[J].地理科学,2014,33(1): 54-59.
	[Wu Meiqiong, Chen Xiugui.Changes in arable land area in Qinzhou city and its driving force based on the principle component analysis.Scientia Geographica Sinica,2014,33(1):54-59.]
[20]	Hersperger A M, Gennaio M, Verburg P H, et al.Linking land change with driving forces and actors: four conceptual models[J].Ecology and Society, 2010,15(4):1-17. doi: 10.1016/j.proche.2011.08.038
[21]	Lambin E F, Turner B L, Geist H J, et al.The causes of land-use and land- cover change: Moving beyond the myths[J]. Global Environmental Change, 2001,11(4):261-269.
[22]	Bürgi M, Hersperger A M, Schneeberger N.Driving forces of landscape change: Current and new directions[J].Landscape Ecology, 2004,19(8):857-868. doi: 10.1007/s10980-005-0245-3

调查内容	调查提纲
人口生计	①20世纪50年代以来,村社户数和人口变化情况（发生变化的年份、原因及对农业的影响等）;②移民迁入或迁出状况（人数、年份、地点以及从事职业、对耕地面积的影响等）;③耕地变化状况（面积、分布、垦荒情况、发生年份、原因、弃耕现象等）;④家畜家禽饲养（种类、数量、饲养方式、畜牧业在家庭总收入中所占比重的变化等）。
经济发展	①资产投资、产业结构、产值及家庭经济收入变化情况;②农产品产量与价格变化、家禽畜牧产品价格变化。
科技进步	①农作物类型和品种、种植结构及经营方式的变化情况;②灌溉水利（灌溉用水来源、灌溉方式、次数,水利设施建设状况）;③农业用水政策、灌溉用水分配状况、水费价格变化等;④农药、化肥、农膜、农机、农电等投入与使用情况。
政策方面	①三农政策（土地改革、农业学大寨、备战备荒、河西商品粮基地建设、家庭联产承包责任制、基本农田保护政策、扶贫与移民政策、免除农业税、合村并社、新农村建设、限制开荒打井等）;②生态环境政策（三北防护林政策、天然林保护工程、公益林保护、自然保护区、退耕还林还草政策、沙漠化治理等）;③分水政策（黑河分水方案、水权管理等）;④其他政策（如计划生育政策）。
观念意识	①当地居民受教育程度、就业方式;②环境意识、政策认知程度等。

主成分	特征值	贡献率（%）	累积贡献率（%）
1	11.84	74.01	74.01
2	1.99	12.48	86.49
3	1.07	6.70	93.20
