气候变化对中国集中供暖气候指标的影响

doi:10.13249/j.cnki.sgs.2018.10.017

摘要/Abstract

摘要：

应用高空间分辨率的网格逐日气象数据,根据国家集中供暖有关设计规范定义了集中供暖气候指标,分析了气候变暖对中国集中供暖气候指标的影响。结果表明：近55 a来中国集中供暖初日均呈后延趋势,初日特征线年代际南北移动较小。供暖终日均呈提前趋势,终日特征线在110°E以东地区南北移动较大,2000年以来终日特征线较20世纪60年代北抬了200~300 km。供暖期长度均呈减少趋势,东北、华北地区近55 a减少了10~15 d,西北地区减少了15~20 d;东北、华北、西北地区供暖强度分别减少了12%、20%、15%。从1991~2015年冬季气温变化来看,东北地区最冷冬季与最暖冬季的温度相差可达6.2℃,对供暖强度的影响可达28.9%,华北和西北地区冬季气温最大变幅分别为3.7℃、3.3℃,对供暖强度的影响分别为26.8%和17.6%。气候变暖对中国集中供热气候指标产生了显著的影响。供热部门应该根据天气变化来安排供暖,同时还要注意气候变暖背景下极端冷事件的发生,保证集中供暖安全运行。

关键词: 集中供暖, 供暖气候指标, 供暖强度, 气候变暖

Abstract:

The IPCC fifth assessment report (AR5) showed that the global temperature tended to increase in future. Meanwhile, the range of warming in China is higher than that of the global average temperature. It is very significant that understanding the impact of climate change on central heating in China which can provide decision-making advice to supply heating, save energy and reduce air pollution during the supplying heating period. This paper firstly defined the climate index of central heating according to National Central Heating Design Specification, then analyzed the impact of climate warming on climate index of central heating in China based on daily grid meteorological data with high space resolution. The result showed that: 1) The beginning day of central heating tended to delay during the past 55 years in China. The decadal shift of the characteristic line for beginning day from south to north changed very little. 2) The final day of central heating tended to shift to an earlier date. The characteristic line of final day moved obviously from south to north in the east of 110^oE which was 200-300 km higher than that in 1960s since 2000. 3) The length of supplying heating period tended to shorten. The length decreased by 10-15 d in the Northeast and North China and that decreased by 15-20 d in Northwest China. 4) The intensity of suppling heating tended to reduce obviously. The intensity decreased by 12%, 20% and 15% for Northeast, North and Northwest China respectively. The intensity was related to winter average temperature closely. According to the variation of winter temperature from 1991 to 2015, the temperature difference (TD) between the coldest and the warmest winter could reach 6.2℃ in Northeast China which accounted for 28.9% impact on intensity of supplying heating; the TD was 3.7℃ and 3.3℃ for North and Northwest China respectively, which accounted for 26.8% and 17.6% impact on the intensity respectively. Climate warming has a significant impact on the climate index of central heating in China. The relative departments should arrange the supplying heating schedule according to weather variation, meanwhile, pay attention to the occurrence of extreme cold events under the background of climate warming to ensure the central heating operate safely.

Key words: central heating, heating climate index, heating intensity, climate warming

中图分类号:

P467

郭军, 熊明明, 李明财, 何群. 气候变化对中国集中供暖气候指标的影响[J]. 地理科学, 2018, 38(10): 1724-1730.

Jun Guo, Mingming Xiong, Mingcai Li, Qun He. The Impact of Climate Change on the Climate Index of Heating in China[J]. SCIENTIA GEOGRAPHICA SINICA, 2018, 38(10): 1724-1730.

图/表 9

图1

图2

图3

图4

图5

图6

表1

表2

表3

参考文献 17

[1]	《第三次气候变化国家评估报告》编写委员会. 第三次气候变化国家评估报告[M]. 北京: 科学出版社,2015.
	[Editorial Committee of the Third China’s National Assessment Report on Climate Change. The third China’s national assessment report on climate change. Beijing: Science Press, 2015.]
[2]	陈峪,黄朝迎.气候变化对能源需求的影响[J].地理学报,2000,55(增刊),11-19. doi: 10.3321/j.issn:0375-5444.2000.z1.002
	[Chen Yu, Huang Chaoying.Impact of climate change on energy demand. Acta Geographica Sinica, 2000, 55( sup.):11-19.] doi: 10.3321/j.issn:0375-5444.2000.z1.002
[3]	龙惟定. 试论我国暖通空调业的可持续发展[J]. 暖通空调,1999,29(3):25-30.
	[Long Weiding.Sustainable development of China’s HVAC industry. Journal of HV&AC,1999,29(3):25-30.]
[4]	张家诚,高素华,潘亚茹.我国温度变化与冬季采暖气候条件的探讨[J].应用气象学报,1992,3(1):70-75.
	[Zhang Jiacheng, Gao Suhua, Pan Yaru.Investigation on the relationship between temperature change and winter heating in China. Journal of Applied Meteorological Science,1992,3(1):70-75.]
[5]	陈莉, 方修琦, 李帅.气候变暖对中国严寒地区和寒冷地区南界及采暖能耗的影响[J].科学通报,2007,52(10):1195-1198. doi: 10.3321/j.issn:0023-074X.2007.10.017
	[Chen Li, Fang Xiuqi, Li Shuai.Impacts of climate warming on heating energy consumption and southern boundaries of severe cold and cold regions in China. Chinese Science Bulletin,2007,52(20):2854-2858.] doi: 10.3321/j.issn:0023-074X.2007.10.017
[6]	陈莉, 方修睦, 方修琦, 等. 过去20年气候变暖对我国冬季采暖气候条件与能源需求的影响[J]. 自然资源学报, 2006, 21(4):590-597. doi: 10.11849/zrzyxb.2006.04.012
	[Chen Li, Fang Xiumu, Fang Xiuqi et al. Impacts of climate warming on heating climatic conditions and energy requirements over China in the past 20 years. Journal of Natural Resources,2006,21(4):590-597.] doi: 10.11849/zrzyxb.2006.04.012
[7]	周自江. 我国冬季气温变化与采暖分析[J]. 应用气象学报, 2000,11(2):251-252. doi: 10.3969/j.issn.1001-7313.2000.02.017
	[Zhou Zijiang.Changes of winter temperature and heating analysis in China. Journal of Applied Meteorological Science, 2000, 11(2):251-252.] doi: 10.3969/j.issn.1001-7313.2000.02.017
[8]	李喜仓, 白美兰, 杨晶, 等. 气候变暖对呼和浩特地区采暖期能源消耗的影响[J].气候变化研究进展, 2010, 6(1):29-34.
	[Li Xicang, Bai Meilan, Yang Jing et al. Impacts of climate warming on energy consumed in heating period in Hohhot. Advances in Climate Change Research,2010, 6(1):29-34.]
[9]	轩春怡, 高燕虎, 李慧君. 北京市冬季采暖气候条件分析[J]. 气象科技, 2003, 31(6): 373-375.
	[Xuan Chunyi, Gao Yanhu, Li Huijun.Analysis of heating climatic condition in winter in Beijing. Meteorological Science and Technology, 2003, 31(6):373-375.]
[10]	刘彩红,苏文将. 气候变暖对青海高原采暖能耗的影响及预估[J]. 南京信息工程大学学报:自然科学版,2013,5(6):494-500. doi: 10.3969/j.issn.1674-7070.2013.06.003
	[Liu Caihong, Su Wenjiang.Study and prediction of climate warming impact on heating energy consumption in Qinghai plateau. Journal of Nanjing University of Information Science and Technology: Natural Science Edition,2013,5(6):494-500.] doi: 10.3969/j.issn.1674-7070.2013.06.003
[11]	庞文保, 刘宇, 张海东.气候变暖与西安市冬季供暖的能源消耗分析[J]. 气候变化研究进展, 2007, 3(4):220-223. doi: 10.3969/j.issn.1673-1719.2007.04.006
	[Pang Wenbao, Liu Yu, Zhang Haidong.Climate warming and energy consumed for winter heating in Xi’an. Advances in Climat Change Reserch, 2007,3(4):220-223.] doi: 10.3969/j.issn.1673-1719.2007.04.006
[12]	陈莉,李帅, 方修琦, 等.中国严寒和寒冷地区城镇住宅采暖耗能影响因素分析[J]. 地理科学, 2009, 29(2):212-216.
	[Chen Li, Li Shuai, Fang Xiuqi et al. Influence factor analysis of urban residential heating energy consumption in severe cold and cold regions in China. Scientia Geographica Sinica,2009,29(2):212-216.]
[13]	张强, 熊安元, 阮新. 我国地面气温格点化数据集的研制[J].中国科技资源导刊, 2008,40(3):12-20. doi: 10.3772/j.issn.1674-1544.2008.03.003
	[Zhang Qiang, Xiong Anyuan, Ruan Xin.Research and development of the grid-base surfer air temperature in China. China Science&Technology Resources Review, 2008,40(3):12-20.] doi: 10.3772/j.issn.1674-1544.2008.03.003
[14]	国家气象信息中心. 中国地面降水0. 5°×0.5°格点数据集(V2. 0)评估报告. 北京: 国家气象信息中心, 2012.
	[National Meteorological Information Center. Assessment report of China's ground precipitation 0.5°×0.5° gridded dataset (V2.0).Beijing: National Meteorological Information Center, 2012.]
[15]	中华人民共和国建设部.民用建筑供暖通风与空气调节设计规范(GB50736-2012)[S]. 北京:中国建筑工业出版社, 2012.
	[Ministry of Construction of People’s Repubic of China. Design code for heating ventilation and air conditioning of civil buildings(GB50736-2012) . Beijing: China Building Industry Press, 2012.]
[16]	Jones P D, Hulme M B.Calculating regional climatic time series for temperature and precipitation: Methods and Illustrations[J]. InternationalJournalof Climatology, 1996,16:361-377.
[17]	魏凤英. 现代气候统计诊断与预测技术[M]. 北京: 气象出版社, 2007.
	[Wei Fengying.Modern diagnosis of climate statistics and its prediction. Beijing: China Meteorological Press, 2007.]

	东北地区		华北地区		西北地区
指标	月平均气温	冬季平均气温	月平均气温	冬季平均气温	月平均气温	冬季平均气温
供暖初日	0.63	0.37	0.53	0.38	0.78	0.42
供暖终日	-0.75	-0.28	-0.60	-0.17	-0.75	-0.15
供暖强度	/	-0.90	/	-0.93	/	-0.87

指标	东北地区	华北地区	西北地区
供暖初日	Y=1.8T₁₀+278.2	Y=1.4T₁₁+301.7	Y=2.6T₁₀+273.2
供暖终日	Y=-1.9T₄+122	Y=-1.5T₃+97.7	Y=-2.0T₄+123.5
供暖强度	Y=-133.6T_DJF+ 583.7	Y=-110.3T_DJF+ 629.8	Y=-120.6T_DJF+ 932.0

	最高平均气温					最低平均气温
地区	10月	11月	冬季	3月	4月	10月	11月	冬季	3月	4月
东北地区	6.5	-4.2	-13.6	-0.7	8.2	1.9	-11.2	-19.8	-9.2	1.8
华北地区	11.6	2.0	-5.3	4.3	12.5	6.5	-3.3	-9.0	-0.5	6.0
西北地区	5.8	-1.7	-9.0	1.7	7.6	2.1	-5.9	-12.3	-4.3	3.9
