松花江区气象水文干旱演变特征

doi:10.13249/j.cnki.sgs.2018.10.018

地理科学 ›› 2018, Vol. 38 ›› Issue (10): 1731-1739.doi: 10.13249/j.cnki.sgs.2018.10.018

• • 上一篇

松花江区气象水文干旱演变特征

吴燕锋^1,²(), 章光新¹()

1.中国科学院东北地理与农业生态研究所,吉林长春 130102
2.中国科学院大学,北京 100049

收稿日期:2017-09-07 修回日期:2017-12-30 出版日期:2018-12-12 发布日期:2018-12-12
作者简介:
作者简介：吴燕锋（1986-）,男,河南沈丘人,博士研究生,主要从事湿地生态水文、水文与水资源方面研究。E-mail: wuyanfeng@iga.ac.cn
基金资助:
中国科学院东北地理与农业生态研究所特色所项目（IGA-135-05）、国家重点研发计划(2017YFC0406003)、水利部公益性行业科研专项经费项目(201401014)资助

Spatio-temporal Patterns of Meteorological and Hydrological Drought in the Songhua River Area from 1961 to 2010

Yanfeng Wu^1,²(), Guangxin Zhang¹()

1. Northeast Institute of Geography and Agroecology, Chinese Academy of Sciences, Changchun 130102, Jilin, China
2. University of Chinese Academy of Sciences, Beijing 100049, China

Received:2017-09-07 Revised:2017-12-30 Online:2018-12-12 Published:2018-12-12
Supported by:
The Featured Institute Project 4, Northeast Institute of Geography and Agroecology, Chinese Academy of Sciences (IGA-135-05), National Key Research and Development Program of China (2017YFC0406003), the Public Welfare Industry Research Funded by China’s Ministry of Water Resources (201401014)

摘要/Abstract

摘要：

采用标准化降水蒸散指数和径流干旱指数分析了1961~2010年研究区水文干旱和气象干旱时空演变特征,并探讨了水文干旱与气象干旱的关系。结果表明：① 1961~2010年松花江区呈总体干旱化且又有明显时段性的特征,其中1967~1983年和1996~2010年气象干旱频发、覆盖范围广、持续时间长且强度大;其它时段气象干旱少有发生。其次,气象干旱空间分布差异明显,东部的平均干旱频次和强度都大于西部地区,中部（嫩江流域中下游）平均干旱持续时间最长;但在嫩江流域和黑龙江上游地区干旱略有减弱趋势。② 松花江流域和挠力河流域水文干旱呈加剧的趋势,尤其是近15 a干旱化趋势明显;挠力河流域干旱频发、强度大且持续时间很长。松花江流域水文干旱程度弱于挠力河流域,但极端水文干旱事件频发。 ③ 松花江区气象干旱与水文干旱密切相关,嫩江流域水文干旱滞后于气象干旱2个月,而第二松花江流域和松花江流域水文干旱滞后于气象干旱3个月;挠力河流域水文干旱与气象干旱无明显的时滞相关性。

关键词: 气象干旱, 水文干旱, 标准化降水蒸散指数, 径流干旱指数, 松花江区

Abstract:

Climate change is likely to lead to an increased frequency and intensity of extreme weather events, including floods and droughts. To investigate spatiotemporal variation of meteorological and hydrological drought as well as the correlation between the two types of droughts, we calculated the standard precipitation evapotranspiration index and streamflow drought index for characterizing variability of drought frequency, coverage, duration and intensity in the Songhua River Area. The results indicate that: 1) Meteorological droughts exhibited an insignificant increasing trend at the annual scale from 1961 to 2010. The meteorological drought experienced higher frequency, wider coverage, longer duration and greater intensity during 1967-1983 and 1996-2010, while occurred rarely in 1961-1967 and 1984-1995. Spatial analysis showed that drought had higher frequency and greater intensity in east region than that in west region, longer duration in central region than other regions. 2) Hydrological drought also showed an increasing trend and have similar temporal-variation characteristics with meteorological droughts. The severity of hydrological drought towards more intensive in the Songhua River Basin and Naoli River Basin during the past fifty years, especially more significant during the past fifteen years. The hydrological drought experienced higher frequency, wider coverage, longer duration and greater intensity in the Naoli River Basin, while less severe in the Songhua River Basin. Therefore, it is necessary to take mitigation measures involving integrated water resources management and regulation to minimize losses caused by the increasing extremely hydrological droughts. 3) Hydrological drought has close relation with meteorological drought, which not only reflected by significant positive correlation but also indicated by 2, 3 and 3 months’ lags response between them in the Nenjiang River Basin, the Songhua River Basin and the Main Stream Basin of the Songhua River, respectively. However, the hydrological drought has no significant correlation with meteorological drought as a result of intensive human activities in the Naoli River Basin.

Key words: meteorological drought, hydrological drought, standardized precipitation evapotranspiration index, strean flow drought index, the Songhua River Area

中图分类号:

P333

吴燕锋, 章光新. 松花江区气象水文干旱演变特征[J]. 地理科学, 2018, 38(10): 1731-1739.

Yanfeng Wu, Guangxin Zhang. Spatio-temporal Patterns of Meteorological and Hydrological Drought in the Songhua River Area from 1961 to 2010[J]. SCIENTIA GEOGRAPHICA SINICA, 2018, 38(10): 1731-1739.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 24

[1]	Schwalm C R, Anderegg W R L, Michalak A M et al. Lobal patterns of drought recovery[J].Nature,2017,548(7666):202-205.
[2]	Taufik M,Torfs P J J F, ijlenhoet R et al. Amplification of wildfire area burnt by hydrological drought in the humid tropics[J].Nature Climate Change, 2017,7:428-431.
[3]	Prudhomme C, Iuntoli I, Robinson E L et al. Hydrological droughts in the 21st century, hotspots and uncertainties from a global multimodel ensemble experiment[J]. Proceedings of the National Academy of Sciences of the United States of America, 2014,111(9): 3262-3267.
[4]	He X, Wada Y, Wanders N et al. Intensification of hydrological drought in California by human water management[J]. Geophysical Research Letters, 2017,44(4): 1777-1785.
[5]	Vicente-Serrano S M, eguería S, López-Moreno J I. Multiscalar drought index sensitive to global warming: the standardized precipitation evapotranspiration index[J]. Journal of Climate, 2010, 23(7): 1696-1718.
[6]	Dai A.Drought under global warming: a review[J].Wiley Interdisciplinary Reviews: Climate Change, 2011,2(1):45-65.
[7]	吴杰峰,陈兴伟,高路.水文干旱对气象干旱的响应及其临界条件[J].灾害学,2017,32(1):199-204.
	[Wu Jiefeng, Chen Xingwei, Gao Lu.Response of hydrological drought to meteorological drought and its critical conditions.Journal of Catastrophology,2017,32(1):199-204.]
[8]	何福力,胡彩虹,王纪军,等. 基于标准化降水、径流指数的黄河流域近 50 年气象水文干旱演变分析[J].地理与地理信息科学,2015,31(3):69-75.
	[He Fuli, Hu Caihong, Wang Jijun et al. Analysis of meteorological and hydrological drought in the Yellow River Basin,during the past 50 years based on SPI and SDI.Geography and Geo-Information Sciences,2015,31(3):69-75.]
[9]	张建龙,王龙,杨蕊,等. 盘江流域水文干旱对气象干旱的响应特征[J].南水北调与水利科技,2014,12(3):29-32.
	[Zhang Jianlong,Wang Long,Yang Rui et al. Response characteristics of hydrological drought to meteorological drought in Nanpan River Basin.South-to North Water Transfers and Water Sciences＆Technology, 2014,12(3):29-32.]
[10]	蒋忆文, 张喜风, 杨礼箫,等. 黑河上游气象与水文干旱指数时空变化特征对比分析[J].资源科学,2014,36(9):1842-1851.
	[Jiang Yiwen, Zhang Xifeng,Yang Lixiao et al. Analysis and comparison of spatial and temporal patterns of meteorological and hydrological drought indices in the Upper Reach of the Heihe River Watershed, Northwest China. Resources Science, 2014, 36(9):1842-1851.]
[11]	章光新.北粮食主产区水安全与湿地生态安全保障的对策[J]. 中国水利, 2012(15):9-11.
	[Zhang Guangxin.Measures for securing water safety of main grain production base and wetland ecological safety in Northeast China.China Water Resources,2012(15):9-11.
[12]	Li Fengping, Zhang Guangxin, Xu Yijun.Spatiotemporal variability of climate and streamflow in the Songhua River Basin, Northeast China[J]. Journal of Hydrology, 2014,514:53-64.
[13]	卢洪健, 莫兴国, 孟德娟, 等.气候变化背景下东北地区气象干旱的时空演变特征[J].地理科学, 2015, 35(8):1051-1059.
	[Lu Hongjian, Mo Xingguo, Meng Dejuan et al. Analyzing spatiotemporal patterns of meteorological drought and its responses to climate change across Northeast China. Scientia Geographica Sinica, 2015, 35(8):1051-1059.]
[14]	冯波,章光新,李峰平. 花江区季节性气象干旱特征及风险区划研究[J].地理科学,2016,36(3):466-474.
	[Feng Bo,Zhang Guangxin,Li fengping. Characteristics of seasonal meteorological drought characteristics of seasonal meteorological drought and risk regionalization in Songhua River Basin.Scientia Geographica Sinica, 2016, 36(3): 466-474.]
[15]	冯波,闫佰忠,章光新.松花江区水文干旱联合概率分布特征研究[J].节水灌溉, 2014(5):38-42.
	[Feng Bo, Yan Baizhong, Zhang Guangxin.Joint probability distribution characteristics of hydrological drought in Songhua River Basin, Northeast of China.Water Saving Irrigation,2014(5):38-42.]
[16]	章光新, 郭跃东. 嫩江中下游湿地生态水文功能及其退化机制与对策研究[J]. 干旱区资源与环境, 2008, 22(1):122-128.
	[Zhang Guangxin,Guo Yuedong.Study on the wetland ecological and hydrological function and their degradation mechnisms and countermeasures in the middle and lower reaches of Nenjiang River. Journal of Arid Land Resources and Environment,2008,22(1):122-128.]
[17]	何杰, 张士锋, 李九一. 粮食增产背景下松花江区农业水资源承载力优化配置研究[J].资源科学, 2014, 36(9):1780-1788.
	[He Jie, Zhang Shifeng, Li Jiuyi.The optimal allocation of agricultural water resources carrying capacity under grain production increases in Songhuajiang. Resources Science, 2014,36(9):1780-1788.]
[18]	沈国强, 郑海峰, 雷振锋. SPEI 指数在中国东北地区干旱研究中的适用性分析[J].生态学报, 2017, 37(11) :3787-3795.
	[Shen Guoqiang, Zheng Haifeng, Lei Zhenfeng.Applicability analysis of SPEI for drought research in Northeast China. Acta Ecologica Sinica, 2017, 37(11):3787-3795.]
[19]	Fleig A K, Tallaksen L M, Hisdal H et al. A global evaluation of streamflow drought characteristics[J]. Hydrology and Earth System Sciences, 2006, 10(4):535-552.
[20]	Yevjevich V M.An objective approach to definitions and investigations of continental hydrologic droughts[J]. Hydrology Papers (Colorado State University); 1967, 23: 25.
[21]	裴源生, 蒋桂芹, 翟家齐. 干旱演变驱动机制理论框架及其关键问题[J]. 水科学进展, 2013, 24(3):449-456.
	[Pei Yuansheng, Jiang Guiqin, Zhai Jiaqi.Theoretical framework of drought evolution driving mechanism and the key problems. Advances in Water Science, 2013, 24(3):449-456.]
[22]	Acreman M, Holden J.How wetlands affect floods[J].Wetlands,2013,33(5):773-786.
[23]	董李勤, 章光新. 嫩江流域沼泽湿地景观变化及其水文驱动因素分析[J].水科学进展, 2013, 24(2): 177-183.
	[Dong Liqin, Zhang Guangxin.The dynamic evolvement and hydrological driving factors of marsh in Nenjiang River basin. Advance in Water Science, 2013, 24(2):177-183.]
[24]	Yao Y L, Wang L, Lv X et al. Changes in stream peak flow and regulation in Naoli river watershed as a result of wetland loss[J].The Scientific World Journal, 2014, 209547.
