基于多尺度的中国环境污染事件时空分布及其影响因素

doi:10.13249/j.cnki.sgs.2019.09.001

摘要/Abstract

摘要：

环境污染事件已成为人类社会发展面临的严峻挑战,严重制约着人类社会的可持续发展,当前急需厘清环境污染事件的时空特征及影响因素,为制定有效的环保政策提供借鉴。利用Theil指数、变异系数、ESDA等方法,分析了2006~2016年中国环境污染事件的时空分布特征,并借助地理探测器识别了不同尺度环境污染事件的影响因素。结果表明：① 2006~2016年省级尺度环境污染事件发生总频次与不同等级环境污染事件发生频次均呈波动下降趋势,其发生频次和区域差异呈“东-中-西”洼地型格局;② 地级市尺度环境污染事件发生频次随城市规模减小有所降低,随经济发展水平降低呈倒U型,同时,环保重点城市污染事件发生频次高于普通城市的特征;而环境污染事件的差异性表现为随城市规模减小有所降低,随经济发展水平降低而递减,及环保重点城市高于普通城市的特征。③ “胡焕庸线”以东地区环境污染事件多发且类型多样,以西地区污染事件少发且类型单一,不同等级环境污染事件的空间分布差异较大;④ 环境污染事件的影响因素存在差异,且随尺度增大,影响因素与环境污染事件的关联性趋于增强。其中,经济发展和环境监管水平对不同尺度环境污染事件均有显著影响,环境监管水平与其他因素的交互作用对不同尺度环境污染事件的解释力较高。

关键词: 环境污染事件, 区域差异, 地理探测器, 中国

Abstract:

Environmental pollution incidents have become a major challenge for human social development, seriously restrict the sustainable development. Therefore, it is urgently necessary to clarify the temporal and spatial characteristics of pollution incidents and its influencing factors, in order to provide references for the formulation of effective environmental protection policies. In this paper, used the Theil index, coefficient of variation, ESDA and other methods to analyze the spatial distribution characteristics of pollution incidents from 2006 to 2016 in China, and the GeoDetector to identify the influencing factors at different scales. The results showed that: 1) At the provincial scales, the occurrence frequencies of environmental pollution incidents and the occurrence of environmental pollution incidents at different levels both showed fluctuating downward trends, and their frequency and regional differences all showed 'East-Central-West' low-lying land patterns. 2)At the prefecture-level cities scale, the frequency of environmental pollution incidents is reduced as the decreases of city scale, and the U-shaped change occurs with the decrease of economic development level, the frequency of pollution incidents in key environmental protection cities is higher than ordinary cities, difference of environmental pollution incidents is reduced as the decreases of city scale and economic development level, and the environmental protection key cities are higher than ordinary cities. 3) The environmental pollution incidents in east of the 'Hu Line' are frequent and diverse, and the western pollution incidents are rare and single, and the spatial distribution of different levels of environmental pollution incidents were quite different. 4) There existed differences in impacting factors at different scales, and as the scale increased, the correlation between impacting factors and environmental pollution incidents also increased. Among them, the level of economic development and the level of environmental supervision all had vital impacts on environmental pollution incidents. The interaction between environmental supervision and other factors had the significant impacts to the environmental pollution incidents.

Key words: environmental pollution incidents, regional differences, GeoDector, China

中图分类号:

X507

赵雪雁, 王蓉, 王晓琪, 刘江华. 基于多尺度的中国环境污染事件时空分布及其影响因素[J]. 地理科学, 2019, 39(9): 1361-1370.

Zhao Xueyan, Wang Rong, Wang Xiaoqi, Liu Jianghua. Spatio-temporal Distribution and Influencing Factors of Environmental Pollution Incidents Based on Multi-scales in China[J]. SCIENTIA GEOGRAPHICA SINICA, 2019, 39(9): 1361-1370.

图/表 11

图1

图2

图3

图4

表1

图5

图6

图7

表2

表3

表4

参考文献 30

[1]	人民网.1956年日本水俣事件.[N/OL]. Japanese Minamata event in 1956. 2004- 12- 2. .
	[ People.cn.Japanese Minamata event in 1956. 2004-12-27. .]
[2]	国际节能环保网.中国近年来最严重的十大环境污染事件[N/OL]. 2017- 06- 15. .
	[ Huanbao. in-en.com. Chinese top ten most serious environmental pollution incidents in recent years. 2017-06-15. .]
[3]	新华网. 2018环保产业创新发展大会[N/OL]. 2018- 06- 07. .
	[ Xinhuanet. Environmental Industry innovation and development conference, 2018. 2018-06-07. . Environmental Industry innovation and development conference, 2018. 2018-06-07. .]
[4]	联合国. 水和环境-可持续发展[N/OL]. 2015 -9-25.
	[ United Nations. Water and the environment-sustainable development. . 2015 -9-25. ]
[5]	Cao G Z, Yang L ,Liu L X et al. Environmental incidents in China: lessons from 2006 to 2015[J]. Science of the Total Environment, 2018,633:1165-1172. doi: 10.1016/j.scitotenv.2018.03.271 pmid: 29758868
[6]	陆大道 .中速增长: 中国经济的可持续发展[J]. 地理科学, 2015,35(10):1207-1219.
	[ Lu Dadao . Moderate-speed growth: sustainable development of China's economy. Scientia Geographica Sinica, 2015,35(10):1207-1219.]
[7]	王敏, 黄滢 . 中国的环境污染与经济增长[J]. 经济学(季刊), 2015,14(2):557-578.
	[ Wang Min, Huang Ying . China's environmental pollution and economic growth. China Economic Quarterly, 2015,14(2):557-578.]
[8]	屈小娥 . 1990~2009年中国省际环境污染综合评价[J]. 中国人口•资源与环境, 2012,22(5):158-163.
	[ Qu Xiao'e . China's provincial environment assessment: An empirical analysis based on the years from 1990 to 2009. China Population, Resources and Environment, 2012,22(5):158-163.]
[9]	李静, 吕永龙, 贺桂珍 , 等. 我国突发性环境污染事故时空格局及影响研究[J]. 环境科学, 2008,29(9):2684-2688.
	[ Li Jing, Lv Yonglong ,He Guizhen,et al.Spatial and temporal changes of emerging environmental pollution accidents and impact factors in China. Environmental Science, 2008,29(9):2684-2688.]
[10]	周侃, 樊杰 . 中国环境污染源的区域差异及其社会经济影响因素:基于339个地级行政单元截面数据的实证分析[J]. 地理学报, 2016,71(11):1911-1925. doi: 10.11821/dlxb201611004
	[ Zhou Kan, Fan Jie . Regional disparity of environmental pollution source and its socio-economic influencing factors: Based on the cross-section data of 339 cities at prefecture level or above in China. Acta Geographica Sinica, 2016,71(11):1911-1925.] doi: 10.11821/dlxb201611004
[11]	Shin I J . Major industrial accidents in Korea: The characteristics and implication of statistics 1996-2011[J]. Process Safety Progress, 2013,32(1):90-95. doi: 10.1002/prs.11551
[12]	Rimayi C, Odusanya D ,Weiss J M et al. Contaminants of emerging concern in the Hartbeespoort Dam catchment and the uMngeni River estuary 2016 pollution incident, South Africa[J]. Science of the Total Environment, 2018,627:1008-1017. doi: 10.1016/j.scitotenv.2018.01.263 pmid: 29426120
[13]	Smith G E, Bawa Z ,Macklin Y et al. Using real-time syndromic surveillance systems to help explore the acute impact of the air pollution incident of March/April 2014 in England[J]. Environmental Research, 2015,136:500-504. doi: 10.1016/j.envres.2014.09.028 pmid: 25460672
[14]	杨娅, 马俊伟, 刘仁志 . 上海市突发环境事件时空格局及影响因素分析[J]. 中国人口·资源与环境, 2012,22(141):105-109.
	[ Yang Ya, Ma Junwei, Liu Renzhi . Temporal and spatial patterns of abrupt environmental incidents and its causative factors in Shanghai.China Population, Resources and Environment, 2012,22(141):105-109.]
[15]	杨洁, 毕军, 张海燕 , 等. 中国环境污染事故发生与经济发展的动态关系[J]. 中国环境科学, 2010,30(4):571-576.
	[ Yang Jie, Bi Jun ,Zhang Haiyan,et al.Evolvement of the relationship between environmental pollution accident and economic growth in China. China Environmental Science, 2010,30(4):571-576.]
[16]	薛鹏丽, 曾维华 . 上海市突发环境污染事故风险区划[J]. 中国环境科学, 2011,31(10):1743-1750.
	[ Xue Pengli, Zeng Weihua . Shanghai environmental accidents risk regionalization. China Environmental Science, 2011,31(10):1743-1750.]
[17]	丁镭, 黄亚林, 刘云浪 , 等. 1995-2012年中国突发性环境污染事件时空演化特征及影响因素[J]. 地理科学进展, 2015,34(6):749-760. doi: 10.18306/dlkxjz.2015.06.010
	[ Ding Lei, Huang Yalin ,Liu Yunlang,et al.Spatio-temporal variability of sudden environmental pollution incidents and influencing factors in China, 1995-2012. Progress in Geography, 2015,34(6):749-760.] doi: 10.18306/dlkxjz.2015.06.010
[18]	国家统计局, 环境保护部. 中国环境统计年鉴[M]. 北京: 中国统计出版社,2007- 2017.
	[ National Bureau of Statistics , Ministry of Environmental Protection of China. China Statistical yearbook on environment. Beijing: China Statistics Press, 2007- 2017.]
[19]	国家统计局. 中国统计年鉴[M]. 北京: 中国统计出版社, 2007- 2017.
	[ National Bureau of Statistics . China statistical yearbook. Beijing: China Statistics Press, 2007- 2017.]
[20]	中国环境年鉴编辑委员会. 中国环境年鉴[M]. 北京: 中国环境科学出版社, 2007-2017.
	[ China Environmental Yearbook Editorial Board. China environment yearbook. Beijing: China Environmental Science Press,2007- 2017.]
[21]	国家统计局城市社会经济调查司. 中国城市统计年鉴[M]. 北京: 中国统计出版社, 2017.
	[ Department of Urban Social Economic Survey of the National Bureau of Statistics. China city statistical yearbook. Beijing: China Statistics Press, 2017.]
[22]	赵雪雁, 王伟军, 万文玉 . 中国居民健康水平的区域差异:2003-2013[J]. 地理学报, 2017,72(4):685-698. doi: 10.11821/dlxb201704010
	[ Zhao Xueyan, Wang Weijun, Wan Wenyu . Regional inequalities of residents' health level in China: 2003-2013. Acta Geographica Sinica, 2017,72(4):685-698.] doi: 10.11821/dlxb201704010
[23]	Wang J F, Zhang T L, Fu B J . A measure of spatial stratified heterogeneity[J]. Ecological Indicators, 2017,67:250-256. doi: 10.1371/journal.pone.0219695 pmid: 31348778
[24]	张杰, 唐根年 . 浙江省制造业空间分异格局及其影响因素[J]. 地理科学, 2018,38(7):1107-1117. doi: 10.13249/j.cnki.sgs.2018.07.012
	[ Zhang Jie, Tang Gennian . Spatial differentiation pattern of manufacturing industry in Zhejiang and its influencing factors. Scientia Geographica Sinica, 2018,38(7):1107-1117.] doi: 10.13249/j.cnki.sgs.2018.07.012
[25]	席强敏 . 城市效率与城市规模关系的实证分析:基于2001-2009年我国城市面板数据[J].经济问题, 2012(10):37-41.
	[ Xi Qiangmin . Emprical research on the relationship between city efficiency and city size: Based on city panel data from 2001 to 2009 in China. On Economic Problems, 2012 ( 10):37-41.]
[26]	李晶晶, 苗长虹 . 长江经济带人口流动对区域经济差异的影响[J]. 地理学报, 2017,72(2):197-212. doi: 10.11821/dlxb201702002
	[ Li Jingjing, Miao Changhong . Impact of population flow on regional economic disparities in the Yangtze River economic belt. Acta Geographica Sinica, 2017,72(2):197-212.] doi: 10.11821/dlxb201702002
[27]	李名升, 张建辉, 张殷俊 , 等. 近10年中国大气PM₁₀污染时空格局演变[J]. 地理学报, 2013,68(11):1504-1512. doi: 10.11821/dlxb201311006
	[ Li Mingsheng, Zhang Jianhui ,Zhang Yinjun,et al.Spatio-temporal pattern changes of ambient air PM₁₀ pollution in China from 2002 to 2012. Acta Geographica Sinica, 2013,68(11):1504-1512.] doi: 10.11821/dlxb201311006
[28]	胡志强, 苗健铭, 苗长虹 . 中国地市工业集聚与污染排放的空间特征及计量检验[J]. 地理科学, 2018,38(2):168-176. doi: 10.13249/j.cnki.sgs.2018.02.002
	[ Hu Zhiqiang, Miao Jianming, Miao Changhong . Spatial characteristics and econometric test of industrial agglomeration and pollutant emissions in China. Scientia Geographica Sinica, 2018,38(2):168-176.] doi: 10.13249/j.cnki.sgs.2018.02.002
[29]	周侃 . 中国环境污染的时空差异与集聚特征[J]. 地理科学, 2016,36(7):989-997. doi: 10.13249/j.cnki.sgs.2016.07.004
	[ Zhou Kan . Spatial-temporal differences and cluster features of environmental pollution in China. Scientia Geographica Sinica, 2016,36(7):989-997.] doi: 10.13249/j.cnki.sgs.2016.07.004
[30]	王增利, 刘学军, 陆娟 . 入室盗窃多尺度地理因子分析[J]. 地理学报, 2017,72(2):329-340. doi: 10.11821/dlxb201702012
	[ Wang Zengli, Liu Xuejun, Lu Juan . Multiscale geographic analysis of burglary. Acta Geographica Sinica, 2017,72(2):329-340.] doi: 10.11821/dlxb201702012

差异性	城市规模				城市经济发展水平				环保城市和普通城市
差异性	特大城市	大城市	中等城市	小城市	发达城市	较发达城市	欠发达城市	不发达城市	环保重点城市	普通城市
污染事件比重（%）	29.71	25.88	19.41	25.00	28.82	30.29	32.35	8.53	56.76	43.24
变异系数	3.44	1.69	1.08	1.56	2.72	2.28	1.35	1.18	2.64	1.25
Theil指数	0.50	0.26	0.13	0.27	0.42	0.38	0.27	0.08	0.82	0.34

探测指标	省级			地级市
探测指标	2006年	2011年	2016年	2016年
年末人口数（x₁）	0.59^***	0.35	0.32	0.09^**
GDP（x₂）	0.38^*	0.46^**	0.55^**	0.13^***
城镇化率（x₃）	0.20	0.28	0.17	0.06
工业增加值占GDP比重（x₄）	0.40^*	0.11	0.41	0.02
工业企业数（x₅）	0.50^**	0.23	0.28	0.06
环保人员数（x₆）	0.40^*	0.60^***	0.46^*	0.08^*
环保机构数（x₇）	0.35	0.32	0.37	0.09^**
环境污染治理投资占GDP比重（x₈）	0.21	0.38^**	0.07	0.02

2006年		2011年		2016年
交互因子	作用值	交互因子	作用值	交互因子	作用值
x₁∩x₂	0.86	x₁∩x₃	0.90	x₁∩x₂	0.83
x₂∩x₃	0.73	x₂∩x₃	0.87	x₂∩x₃	0.89
x₁∩x₄	0.86	x₃∩x₄	0.89	x₃∩x₅	0.62
x₂∩x₄	0.80	x₃∩x₅	0.80	x₄∩x₂	0.93
x₃∩x₄	0.83	x₆∩x₂	0.86	x₄∩x₃	0.85
x₃∩x₅	0.90	x₆∩x₃	0.86	x₅∩x₁	0.84
x₆∩x₄	0.88	x₆∩x₄	0.87	x₅∩x₂	0.94
x₆∩x₅	0.88	x₆∩x₇	0.84	x₆∩x₄	0.80
x₇∩x₁	0.89	x₇∩x₈	0.83	x₇∩x₄	0.87
x₇∩x₂	0.98	x₈∩x₂	0.86	x₇∩x₅	0.85
x₇∩x₃	0.85	x₈∩x₃	0.85	x₈∩x₄	0.89
x₇∩x₄	0.88	x₈∩x₅	0.83	x₈∩x₅	0.91
x₈∩x₆	0.76	x₈∩x₆	0.94	x₈∩x₆	0.89

	x₁	x₂	x₃	x₄	x₅	x₆	x₇
x₂	0.26
x₃	0.33	0.31
x₄	0.26	0.30	0.33
x₅	0.26	0.24	0.23	0.28
x₆	0.16	0.29	0.36	0.24	0.23
x₇	0.17	0.29	0.31	0.30	0.25	0.23
x₈	0.28	0.31	0.26	0.20	0.30	0.29	0.36
