中原城市群城市空间联系网络格局分析——基于综合交通信息流

doi:10.13249/j.cnki.sgs.2019.12.011

地理科学 ›› 2019, Vol. 39 ›› Issue (12): 1929-1937.doi: 10.13249/j.cnki.sgs.2019.12.011

中原城市群城市空间联系网络格局分析——基于综合交通信息流

安俞静^1,^2,³, 刘静玉³(), 乔墩墩³

1. 中国科学院南京地理与湖泊研究所, 江苏南京 210008
2. 中国科学院大学, 北京 100049
3. 河南大学环境与规划学院/区域发展与规划研究中心/黄河中下游数字地理技术教育部重点实验室, 河南开封 475000

收稿日期:2018-11-10 修回日期:2019-04-17 出版日期:2019-12-10 发布日期:2020-03-01
通讯作者: 刘静玉 E-mail:liujy@henu.edu.cn
作者简介:安俞静（1994-）,女,河南周口人,博士研究生,主要从事人文地理学、城市发展与区域规划研究。E-mail: yujing_1912@163.com
基金资助:
国家自然科学基金项目资助(41701130)

Urban Spatial Connection and Network Structure in Zhongyuan Urban Agglomeration: A Study Based on Integrated Traffic and Information Flow

An Yujing^1,^2,³, Liu Jingyu³(), Qiao Dundun³

1. Nanjing Institute of Geography & Limnology, Chinese Academy of Sciences, Nanjing 210008, Jiangsu, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. College of Environment and Planning/Centre for Regional Development and Regional Planning/Key Laboratory of Geospatial Technology for the Middle and Lower Yellow River Regions, Henan University, Kaifeng 475000, Henan, China

Received:2018-11-10 Revised:2019-04-17 Online:2019-12-10 Published:2020-03-01
Contact: Liu Jingyu E-mail:liujy@henu.edu.cn
Supported by:
National Natural Science Foundation of China(41701130)

摘要/Abstract

摘要：

基于中原城市群30个省辖市间的公路、普速、高速列车客运班次和百度指数数据,利用层次分析法、空间可视化和社会网络分析,从多元要素流视角对中原城市群城市空间联系及网络格局进行研究。结果表明:① 交通网络中晋皖地区被边缘化特征明显,信息网络呈现多维度钻石型关联格局,首位联系受省界制约且具有明显指向性。② 综合联系网络呈现“一横两纵”格局,具有低密度、单中心和“富人俱乐部”的基本特征,整体空间上“行政区”掣肘现象依然明显。③ 城市综合实力、基础设施、行政效应与政策导向能够较好的反映城市空间联系及网络格局的形成。

关键词: 城市网络, 联系强度, 空间组织, 中原城市群

Abstract:

With the rapid development of globalization, informatization and urbanization, time-space compression has led to the considerable consolidation of linkages among cities, which show characteristics of network. Therefore, studies on urban network based on space flows have become one of the most important issues of human geography in the era of big date. This article focuses on the identification and spatial structure of multiple elementary flows as well as their synthesis effects for regional development. The data of space flows with highway buses, ordinary trains, high-speed trains and Baidu index information between provincial cities in Zhongyuan urban agglomeration are collected for analyses. Using hierarchy process, spatial variation and social network analytical methods, we explore characteristics of urban spatial connection and network structure from various aspects. Our results indicate that: 1) Traffic flows based urban network displays characteristics of the axis bands, cities with high value of external relations are distributed along the main traffic arteries, while Shanxi and Anhui are marginalized in the regional connection. In contrast, the information network shows a relatively complete, orderly, and coordinated state of connection, and generally presents a multi-dimensional diamone-shaped correlation pattern. The dominant flow is restricted by provincial boundaries and has obvious directivity, which is mostly the one-way flow from low-grade city to higher-grade city. 2) The comprehensive linkage network of traffic and information flow reflects a “one horizontal and two vertical” pattern with the basic characteristics of low density, single center and “rich club”. The connectivity ability among nodes varies significantly. Zhengzhou, Luoyang, Shangqiu and Anyang, in the core development area, have relatively stronger control over the connection network. 3) There is an outstanding phenomenon of subgroups agglomeration in this region, according to the comprehensive linkage network. Moreover, the urban distribution in each subgroup conforms to the principle of spatial proximity. “Axial and radial extension-grouped partition” is the main pattern of spatial organization in Zhongyuan urban agglomeration. 4) At last, the urban size, comprehensive development strength, infrastructure construction, administrative effects and policy orientation could explain the formation of urban spatial relationships and network structure.

Key words: urban network, connection intensity, spatial organization, Zhongyuan urban agglomeration

中图分类号:

K901

安俞静, 刘静玉, 乔墩墩. 中原城市群城市空间联系网络格局分析——基于综合交通信息流[J]. 地理科学, 2019, 39(12): 1929-1937.

An Yujing, Liu Jingyu, Qiao Dundun. Urban Spatial Connection and Network Structure in Zhongyuan Urban Agglomeration: A Study Based on Integrated Traffic and Information Flow[J]. SCIENTIA GEOGRAPHICA SINICA, 2019, 39(12): 1929-1937.

图/表 6

图1

表1

城市对间首位联系强度统计"

	强联系（ $>$ 0.6）（个）	次强联系（0.3~0.6）（个）	弱联系（<0.3）（个）	耦合联系（互为首位联系）（个）	平均首位度
公路	1	14	9	0	0.22
普速铁路	1	7	15	2	0.37
高速铁路	1	7	8	1	0.52
百度信息	2	10	14	1	0.26

表1

图2

图3

表2

表3

中原城市群各城市可达性水平"

城市名称	$A i$ （h）	$A i'$	城市名称	$A i$ （h）	$A i'$	城市名称	$A i$ （h）	$A i'$
郑州	2.70	0.58	鹤壁	4.42	0.94	晋城	5.04	1.08
开封	3.03	0.65	济源	4.50	0.97	濮阳	5.22	1.12
新乡	3.11	0.67	平顶山	4.53	0.98	聊城	5.53	1.19
许昌	3.26	0.70	菏泽	4.60	0.99	宿州	5.56	1.20
焦作	3.40	0.73	周口	4.64	0.99	阜阳	5.62	1.21
安阳	3.60	0.77	邢台	4.65	1.00	南阳	5.69	1.22
洛阳	3.69	0.79	驻马店	4.67	1.01	淮北	5.86	1.26
漯河	3.91	0.84	三门峡	4.95	1.06	长治	6.17	1.33
商丘	4.00	0.86	信阳	5.01	1.08	蚌埠	6.61	1.42
邯郸	4.06	0.87	亳州	5.02	1.08	运城	6.91	1.49

表3

参考文献 33

[1]	王姣娥, 景悦 . 中国城市网络等级结构特征及组织模式——基于铁路和航空流的比较[J]. 地理学报, 2017,72(8):1508-1519.
	[ Wang Jiao’e, Jing Yue . Comparison of spatial structure and organization mode of inter-city networks from the perspective of railway and air passenger flow. Acta Geographica Sinica, 2017,72(8):1508-1519.]
[2]	陈伟, 刘卫东, 柯文前 , 等. 基于公路客流的中国城市网络结构与空间组织模式[J]. 地理学报, 2017,72(2):224-241.
	[ Chen Wei, Liu Weidong, Ke Wenqian et al. The spatial structures and organization patterns of China’s city networks based on the highway passenger flows. Acta Geographica Sinica, 2017,72(2):224-241.]
[3]	Castells M . The informational city: Information technology, economic restructuring and the urban-regional progress[M]. Oxford UK & Cambridge USA: Blackwell, 1989.
[4]	Taylor P J . The new geography of global civil society: NGOs in the world city network[J]. Globalizations, 2004,1(2):265-277.
[5]	Alderson A S, Beckfield J, Jessica S J . Intercity relations and globalization: The evolution of the global urban hierarchy, 1981-2007[J]. Urban Studies, 2010,47(9):1899-1923.
[6]	王茂军, 柴箐 . 北京市产业网络结构特征与调节效应[J]. 地理研究, 2013,32(3):543-555.
	[ Wang Maojun, Chai Qing . Beijing industrial network structural features and moderating effect. Geographical Research, 2013,32(3):543-555.]
[7]	庄德林, 杨羊, 晋盛武 , 等. 基于战略性新兴产业的长江三角洲城市网络结构演变研究[J]. 地理科学, 2017,37(4):546-553.
	[ Zhuang Delin, Yang Yang, Jin Shengwu et al. Evolution of the Yangtze River Delta’s city network based on the strategic emerging industries. Scientia Geographica Sinica, 2017,37(4):546-553.]
[8]	盛科荣, 张红霞, 佀丹丹 . 中国城市网络中心性的空间格局及影响因素[J]. 地理科学, 2018,38(8):1256-1265.
	[ Sheng Kerong, Zhang Hongxia, Si Dandan . The spatial pattern and influential factors of urban network centrality in China. Scientia Geographica Sinica, 2018,38(8):1256-1265.]
[9]	季菲菲, 陈雯, 魏也华 , 等. 长三角一体化下的金融流动格局变动及驱动机理——基于上市企业金融交易数据的分析[J]. 地理学报, 2014,69(6):823-837.
	[ Ji Feifei, Chen Wen, Wei Yehua et al. Changing financial flow patterns and driving mechanisms of financial flows under the integration of the Yangtze River Delta: An analysis of the financial transaction data of listed companies. Acta Geographica Sinica, 2014,69(6):823-837.]
[10]	Derudder B, Witlox F . Mapping world city networks through airline flows: Context, relevance, and problems[J]. Journal of Transport Geography, 2008,16(5):305-312.
[11]	Mahutga M C, Ma X, Smith D A et al. Economic globalization and the structure of the world city system: The case of airline passenger data[J]. Urban Studies, 2010,47(9):1925-1947.
[12]	金凤君, 王成金 . 轴-辐侍服理念下的中国航空网络模式构筑[J]. 地理研究, 2005,24(5):774-784.
	[ Jin Fengjun, Wang Chengjin . Hub and spoke system and China aviation network organization. Geographical Research, 2005,24(5):774-784.]
[13]	王海江, 苗长虹 . 中国航空联系的网络结构与区域差异[J]. 地理科学, 2015,35(10):1220-1229.
	[ Wang Haijiang, Miao Changhong . Network structure and regional difference of aviation links in China. Scientia Geographica Sinica, 2015,35(10):1220-1229.]
[14]	冯兴华, 修春亮, 刘志敏 , 等. 东北地区城市网络层级演变特征分析——基于铁路客运流视角[J]. 地理科学, 2018,38(9):1430-1438.
	[ Feng Xinghua, Xiu Chunliang, Liu Zhimin et al. Characteristics of urban network hierarchy evolution based on the perspective of railway passenger transport in northeast China. Scientia Geographica Sinica, 2018,38(9):1430-1438.]
[15]	高鑫, 修春亮, 魏冶 . 基于高速公路货流数据的重庆市区县关联网络格局研究[J]. 人文地理, 2016,31(1):73-80.
	[ Gao Xin, Xiu Chunliang, Wei Ye . Study on the network of districts and counties in Chongqing based on the data of the highway cargo flows. Human Geography, 2016,31(1):73-80.]
[16]	王姣娥, 焦敬娟, 金凤君 . 高速铁路对中国城市空间相互作用强度的影响[J]. 地理学报, 2014,69(12):1833-1846.
	[ Wang Jiao’e, Jiao Jingjuan, Jin Fengjun . Spatial effects of high-speed rails on interurban economic linkages in China. Acta Geographica Sinica, 2014,69(12):1833-1846.]
[17]	孙阳, 姚士谋, 张落成 . 中国沿海三大城市群城市空间网络拓展分析——以综合交通信息网络为例[J]. 地理科学, 2018,38(6):827-837.
	[ Sun Yang, Yao Shimou, Zhang Luocheng . Spatial expansion of urban network for the three coastal agglomerations of China: A study based on integrated traffic information network. Scientia Geographica Sinica, 2018,38(6):827-837.]
[18]	叶磊, 段学军, 欧向军 . 基于交通信息流的江苏省流空间网络结构研究[J]. 地理科学, 2015,35(10):1230-1237.
	[ Ye Lei, Duan Xuejun, Ou Xiangjun . The urban network structure of Jiangsu province based on the traffic and information flow. Scientia Geographica Sinica, 2015,35(10):1230-1237.]
[19]	陈伟, 修春亮, 柯文前 , 等. 多元交通流视角下的中国城市网络层级特征[J]. 地理研究, 2015,34(11):2073-2083.
	[ Chen Wei, Xiu Chunliang, Ke Wenqian et al. Hierarchical structures of China's city network from the perspective of multiple traffic flows. Geographical Research, 2015,34(11):2073-2083.]
[20]	甄峰, 王波, 陈映雪 . 基于网络社会空间的中国城市网络特征——以新浪微博为例[J]. 地理学报, 2012,67(8):1031-1043.
	[ Zhen Feng, Wang Bo, Chen Yingxue . China’s city network characteristics based on social network space: An empirical of sina micro-blog. Acta Geographica Sinica, 2012,67(8):1031-1043.]
[21]	黎智枫, 赵渺希 . 赛博空间视角下中国三大城市群网络特征——基于豆瓣跨城活动数据[J]. 人文地理, 2016,31(6):102-107.
	[ Li Zhifeng, Zhao Miaoxi . City network in cyberspace: Using Douban-event to measure the cross-city activities in urban agglomeration of China. Human Geography, 2016,31(6):102-107.]
[22]	邓楚雄, 宋雄伟, 谢炳庚 , 等. 基于百度贴吧数据的长江中游城市群城市网络联系分析[J]. 地理研究, 2018,37(6):1181-1192.
	[ Deng Chuxiong, Song Xiongwei, Xie Binggeng et al. City network link analysis of urban agglomeration in the middle Yangtze River basin based on the Baidu Post Bar data. Geographical Research, 2018,37(6):1181-1192.]
[23]	王垚, 钮心毅, 宋小冬 , 等. 人流联系和经济联系视角下区域城市关联比较——基于手机信令数据和企业关联数据的研究[J]. 人文地理, 2018,33(2):84-91.
	[ Wang Yao, Niu Xinyi, Song Xiaodong et al. The comparison of regional urban relations between people flow and capital flow. Human Geography, 2018,33(2):84-91.]
[24]	王波, 甄峰, 张浩 . 基于签到数据的城市活动时空间动态变化及区划研究[J]. 地理科学, 2015,35(2):151-160.
	[ Wang Bo, Zhen Feng, Zhang Hao . The dynamic changes of urban space-time activity and activity zoning based on check-in data in sina web. Scientia Geographica Sinica, 2015,35(2):151-160.]
[25]	Taylor P J . New political geographies: Global civil society and global governance through world city networks[J]. Political Geography, 2005,24(6):703-730.
[26]	魏冶, 修春亮, 刘志敏 , 等. 春运人口流动透视的转型期中国城市网络结构[J]. 地理科学, 2016,36(11):1654-1660.
	[ Wei Ye, Xiu Chunliang, Liu Zhimin et al. Spatial pattern of city network in transitional China based on the population flows in ‘chunyun’ period. Scientia Geographica Sinica, 2016,36(11):1654-1660.]
[27]	李丹丹, 汪涛, 魏也华 , 等. 中国城市尺度科学知识网络与技术知识网络结构的时空复杂性[J]. 地理研究, 2015,34(3):525-540.
	[ Li Dandan, Wang Tao, Wei Yehua et al. Spatial and temporal complexity of scientific knowledge network and technological knowledge network on China's urban scale. Geographical Research, 2015,34(3):525-540.]
[28]	马海涛 . 基于人才流动的城市网络关系构建[J]. 地理研究, 2017,36(1):161-170.
	[ Ma Haitao . Triangle model of Chinese returnees: A tentative method for city networks based on talent flows. Geographical Research, 2017,36(1):161-170.]
[29]	国家统计局城市社会经济调查司. 中国城市统计年鉴[M]. 北京: 中国统计出版社, 2017.
	[ National Bureau of Statistics the city Social and Economic Investigation Department. China city statistical yearbook. Beijing: China Statistics Press, 2017.]
[30]	刘军 . 整体网分析讲义:UCINET软件实用指南[M]. 上海: 上海人民出版社, 2009.
	[ Liu Jun. Lecture on whole network approach: A Practical Guide to UCINET. Shanghai: Truth and Wisdom Press, 2009.]
[31]	何胜, 唐承丽, 周国华 . 长江中游城市群空间相互作用研究[J]. 经济地理, 2014,34(4):46-53.
	[ He Sheng, Tang Chengli, Zhou Guohua . Research on spatial interaction of the urban agglomeration in the middle reaches of the Yangtze River. Economic Geography, 2014,34(4):46-53.]
[32]	王姣娥, 金凤君, 孙炜 , 等. 中国机场体系的空间格局及其服务水平[J]. 地理学报, 2006,61(8):829-838.
	[ Wang Jiao’e, Jin Fengjun, Sun Wei et al. Research on spatial distribution and service level of Chinese airport system. Acta Geographica Sinica, 2006,61(8):829-838.]
[33]	孟德友, 冯兴华, 文玉钊 . 铁路客运视角下东北地区城市网络结构演变及组织模式探讨[J]. 地理研究, 2017,36(7):1339-1352.
	[ Meng Deyou, Feng Xinghua, Wen Yuzhao . Urban networks structure evolution and organization pattern in Northeast China from the perspective of railway passenger transport. Geographical Research, 2017,36(7):1339-1352.]

	1	2	3	4	5	6	7	8
1	1.00	1.00	1.00	0.92	0.56	0.50	0.67	0.44
2	0.91	0.85	0.36	0.25	0.06	0.09	0.09	0.21
3	0.83	0.46	0.10	0.50	0.00	0.00	0.00	0.00
4	1.00	0.16	0.50	0.58	0.08	0.50	0.00	0.00
5	0.56	0.06	0.00	0.00	1.00	0.00	0.00	0.00
6	0.67	0.18	0.25	0.37	0.00	1.00	0.00	0.50
7	0.17	0.00	0.00	0.00	0.00	0.00	0.50	0.67
8	0.22	0.06	0.00	0.00	0.00	0.00	1.00	0.67
