厦门市建设用地功能区的热环境分异研究

doi:10.13249/j.cnki.sgs.2022.09.012

摘要/Abstract

摘要：

基于厦门2019年的兴趣面(Area of Interest)数据、Landsat遥感影像等多源数据，应用Logistic回归模型、空间自回归模型、衰减模型，分析各类建设用地功能区热力特征和对城市热岛影响程度及升温效应的分异规律。结果表明：各类功能区均具有高温现象。交通运输区高温现象显著，仓储区、工业区次之，居住区、公共设施区则较弱；各功能区比例均对形成城市热岛效应有正向影响，影响大小依次为：工业区>仓储区>公共管理与服务区>居住区>商业服务业区>交通运输区>公共设施区；各功能区比例均与热岛强度呈正相关关系，且空间溢出效应显著。交通运输区、商业服务业区比例对热岛强度的正向影响较强，仓储区、工业区次之，公共管理与服务区、居住区、公共设施区比例的正向影响较弱；工业区、商业服务业区、仓储区、交通运输区的升温效应比较显著。功能区面积越大，则其升温效应越显著，但大面积功能区的升温效应可能出现“饱和现象”。

关键词: 功能区, 兴趣面(AOI）, 热环境, 城市热岛, 厦门市

Abstract:

In order to reveal spatial variability of urban thermal environment in different functional regions, we identified seven types of functional regions for construction land based on multi-source data such as multi-source data such as the data of area of interest (AOI) in 2019. Landsat 8 OLI_TRIS remote sensing data was used to retrieve the land surface temperature. Logistic regression model and spatial autoregression model were applied to analyze the variability for influence of different functional regions on urban heat island effect. The multi-ring buffer and decay model were used to quantitatively analyze the variability for warming effect of functional regions. The results show the following: 1) The seven types of functional regions all have the phenomenon of high temperature. The phenomenon of high temperature in traffic region is significant, followed by storage region and industrial region, while public administration and service region, residential region and public facilities region are weak. 2) The proportion of seven types of functional regions all have a significant positive impact on the formation of urban heat island. The impact of the proportion of functional regions on the formation of urban heat island from high to low is: Industrial region>storage region>public administration and service region>residential region>commercial and service region>traffic region>public facilities region. 3) There is a positive correlation between urban heat island intensity (UHII) and the proportion of seven types of functional regions, and a spatial spillover effect is obvious. The increase of the proportion for each functional region in the local region may lead to the rise of UHII in the adjacent region. The proportion of traffic region and commercial and service region have significant positive effect on UHII, followed by storage region and industrial region, while the proportion of public administration and service region, residential region and public facilities region have weak positive effect. 4) The warming effect of industrial region, commercial and service region, storage region and traffic region are relatively prominent, while the warming effect of public administration and service region, residential region, public facilities region are inapparent. 5) There is a positively correlation between the area and the warming effect in functional regions. However, the warming effect in large functional region may be “saturated”. The warming effect of industrial region and traffic region may be more sensitive to the change for area, while the warming effect of public administration and service region, residential region and public facilities region are probably less affected by the change for area.The results of this study are conducive to provide a scientific guidance for layout of urban functional regions and the optimization of thermal environment in Xiamen City.

Key words: functional regions, area of interest (AOI), thermal environment, urban heat island, Xiamen City

中图分类号:

TU98/TP79

沈中健. 厦门市建设用地功能区的热环境分异研究[J]. 地理科学, 2022, 42(9): 1627-1637.

Shen Zhongjian. Variability of Urban Thermal Environment for Functional Regions of Construction Land in Xiamen City[J]. SCIENTIA GEOGRAPHICA SINICA, 2022, 42(9): 1627-1637.

图/表 10

表1

表2

图1

图2

表3

表4

表5

表6

表7

表8

参考文献 36

[1]	孟凡超, 郭军, 李明财, 等. 天津市单次极端低温过程中城市热岛对建筑负荷的影响[J]. 地理科学, 2020, 40(10) 1753-1762. doi: 10.13249/j.cnki.sgs.2020.10.019
	Meng Fanchao, Guo Jun, Li Mingcai et al. Impacts of urban heat island on building loads during a single extreme low-temperature process in Tianjin City. Scientia Geographica Sinica, 2020, 40(10) 1753-1762. doi: 10.13249/j.cnki.sgs.2020.10.019
[2]	沈中健, 曾坚. 闽南三市城镇发展与地表温度的空间关系[J]. 地理学报, 2021, 76(3) 566-583. doi: 10.11821/dlxb202103006
	Shen Zhongjian, Zeng Jian. Spatial relationship of urban development to land surface temperature in three cities of southern Fujian. Acta Geographica Sinica, 2021, 76(3) 566-583. doi: 10.11821/dlxb202103006
[3]	Yu Zhaowu, Zhang Jinguang, Yang Gaoyuan et al. Reverse thinking: A new method from the graph perspective for evaluating and mitigating regional surface heat islands[J]. Remote Sensing, 2021, 13(6) 1127 doi: 10.3390/rs13061127
[4]	Huang Huanchun, Yang Hailin, Chen Yilun et al. Urban green space optimization based on a climate health risk appraisal: A case study of Beijing City, China[J]. Urban Forestry & Urban Greening, 2021, 62: 127154
[5]	闫广华, 苏俊如, 管敦颐. 大连市中山区城市建筑垂直特征对城市热环境效应的影响[J]. 地理科学, 2019, 39(1) 125-130. doi: 10.13249/j.cnki.sgs.2019.01.014
	Yan Guanghua, Su Junru, Guan Dunyi. The impact of urban architectural vertical characteristics on urban thermal environment in Zhongshan district, Dalian. Scientia Geographica Sinica, 2019, 39(1) 125-130. doi: 10.13249/j.cnki.sgs.2019.01.014
[6]	沈中健, 曾坚. 厦门市热岛强度与相关地表因素的空间关系研究[J]. 地理科学, 2020, 40(5) 842-852. doi: 10.13249/j.cnki.sgs.2020.05.019
	Shen Zhongjian, Zeng Jian. Spatial relationship of heat island intensity to correlated land surface factors in Xiamen City. Scientia Geographica Sinica, 2020, 40(5) 842-852. doi: 10.13249/j.cnki.sgs.2020.05.019
[7]	尹梦晗, 艾东, 叶菁. 长江经济带中部大都市气候变化与土地利用响应——以武汉市为例[J]. 中国农业大学学报, 2021, 26(6) 126-140. doi: 10.11841/j.issn.1007-4333.2021.06.13
	Yin Menghan, Ai Dong, Ye Jing. Climate change and land use response of metropolis of the Yangtze River Economic Belt: A case study of Wuhan. Journal of China Agricultural University, 2021, 26(6) 126-140. doi: 10.11841/j.issn.1007-4333.2021.06.13
[8]	杨智威, 陈颖彪, 吴志峰, 等. 基于自然区块的城市热环境空间分异性研究[J]. 地理科学进展, 2019, 38(12) 1944-1956. doi: 10.18306/dlkxjz.2019.12.010
	Yang Zhiwei, Chen Yingbiao, Wu Zhifeng et al. Spatial variability of urban thermal environment based on natural blocks. Progress in Geography, 2019, 38(12) 1944-1956. doi: 10.18306/dlkxjz.2019.12.010
[9]	武蓉蓉, 谢苗苗, 刘琦, 等. 大都市功能区块视角下的热岛影响因素空间分异[J]. 资源科学, 2020, 42(12) 2463-2474. doi: 10.18402/resci.2020.12.16
	Wu Rongrong, Xie Miaomiao, Liu Qi et al. Spatial variability of causative factors of heat islands from the perspective of metropolitan functional blocks. Resources Science, 2020, 42(12) 2463-2474. doi: 10.18402/resci.2020.12.16
[10]	刘丽香, 杨凯, 叶家慧, 等. 雄安新区城市热岛效应的空间异质性[J]. 环境工程技术学报, 2021, 11(3) 546-553. doi: 10.12153/j.issn.1674-991X.20200194
	Liu Lixiang, Yang Kai, Ye Jiahui et al. Spatial variation of urban heat island effect in Xiong’ an New Area. Journal of Environmental Engineering Technology, 2021, 11(3) 546-553. doi: 10.12153/j.issn.1674-991X.20200194
[11]	刘嘉慧, 赵小锋, 林剑艺. 基于地表能量平衡的厦门岛城市功能区人为热排放分析[J]. 地球信息科学学报, 2018, 20(7) 1026-1036. doi: 10.12082/dqxxkx.2018.170450
	Liu Jiahui, Zhao Xiaofeng, Lin Jianyi. Analysis of anthropogenic heat discharge of urban functional regions based on surface energy balance in Xiamen Island. Journal of Geo-information Science, 2018, 20(7) 1026-1036. doi: 10.12082/dqxxkx.2018.170450
[12]	Yao Lei, Xu Ying, Zhang Baolei. Effect of urban function and landscape structure on the urban heat island phenomenon in Beijing, China[J]. Landscape and Ecological Engineering, 2019, 15(4) 379-390. doi: 10.1007/s11355-019-00388-5
[13]	Min Min, Lin Chen, Duan Xuejiun et al. Spatial distribution and driving force analysis of urban heat island effect based on raster data: A case study of the Nanjing Metropolitan Area, China[J]. Sustainable Cities and Society, 2019, 50: 101637 doi: 10.1016/j.scs.2019.101637
[14]	Li Tong, Xu Ying, Yao Lei. Detecting urban landscape factors controlling seasonal land surface temperature: From the perspective of urban function zones[J]. Environmental Science and Pollution Research, 2021,DOI: 10.1007/s11356-021-13695-y.
[15]	张景奇, 史文宝, 修春亮. POI 数据在中国城市研究中的应用[J]. 地理科学, 2021, 41(1) 140-148.
	Zhang Jingqi, Shi Wenbao, Xiu Chunliang. Urban research using points of interest data in China. Scientia Geographica Sinica, 2021, 41(1) 140-148.
[16]	Zhang Chengkun, Xu Liuchang, Yan Zhen et al. A glove-based POI type embedding model for extracting and identifying urban functional regions[J]. ISPRS International Journal of GEO-Information, 2021, 10(6) 372 doi: 10.3390/ijgi10060372
[17]	Zhang Yaotao, Li Qingquan, Tu Wei et al. Functional urban land use recognition integrating multi-source geospatial data and cross-correlations[J]. Computers Environment and Urban Systems, 2019, 78: 101374 doi: 10.1016/j.compenvurbsys.2019.101374
[18]	Cao Rui, Zhu Jiasong, Tu Wei et al. Integrating aerial and street view images for urban land use classification[J]. Remote Sensing, 2018, 10(10) 1553 doi: 10.3390/rs10101553
[19]	Chen Yang, Yang Jun, Yang Ruixin et al. Contribution of urban functional zones to the spatial distribution of urban thermal environment[J]. Building and Environment, 2022, 216: 109000 doi: 10.1016/j.buildenv.2022.109000
[20]	Li Xiaoting, Hu Tengyun, Gong Peng et al. Mapping essential urban land use categories in Beijing with a fast area of interest (AOI)-based method[J]. Remote Sensing, 2021, 13(3) 477 doi: 10.3390/rs13030477
[21]	Liu Yunzhe, Singleton Alex, Arribas-bel Daniel et al. Identifying and understanding road-constrained areas of interest (AOIs) through spatiotemporal taxi GPS data: A case study in New York City[J]. Computers Environment and Urban Systems, 2021, 86: 101592 doi: 10.1016/j.compenvurbsys.2020.101592
[22]	Jiang Yue, Lin Wenpeng. A comparative analysis of retrieval algorithms of land surface temperature from Landsat-8 data: A case study of Shanghai, China[J]. International Journal of Environmental Research and Public Health, 2021, 18(11) 5659 doi: 10.3390/ijerph18115659
[23]	Zhang Youshui, Balzter Heiko, Li Yu. Influence of impervious surface area and fractional vegetation cover on seasonal urban surface heating/cooling rates[J]. Remote Sensing, 2021, 13(7) 1263 doi: 10.3390/rs13071263
[24]	Peng Yu, Wang Qinghui, Bai Lan. Identification of the key landscape metrics indicating regional temperature at different spatial scales and vegetation transpiration[J]. Ecological Indicators, 2020, 111: 106066 doi: 10.1016/j.ecolind.2020.106066
[25]	Zabor Emily C, Reddy Chandana A, Tendulkar Rahul D et al. Logistic regression in clinical studies[J]. International Journal of Radiation Oncology Biology Physics, 2022, 112(2) 271-277. doi: 10.1016/j.ijrobp.2021.08.007
[26]	熊俊楠, 李进, 程维明, 等. 西南地区山洪灾害时空分布特征及其影响因素[J]. 地理学报, 2019, 74(7) 1374-1391. doi: 10.11821/dlxb201907008
	Xiong Junnan, Li Jin, Cheng Weiming et al. Spatial-temporal distribution and the influencing factors of mountain flood disaster in southwest China. Acta Geographica Sinica, 2019, 74(7) 1374-1391. doi: 10.11821/dlxb201907008
[27]	沈中健, 曾坚, 梁晨. 闽南三市绿地景观格局与地表温度的空间关系[J]. 生态学杂志, 2020, 39(4) 1309-1317. doi: 10.13292/j.1000-4890.202004.026
	Shen Zhongjian, Zeng Jian, Liang Chen. Spatial relationship of greenspace landscape pattern with land surface temperature in three cities of southern Fujian. Chinese Journal of Ecology, 2020, 39(4) 1309-1317. doi: 10.13292/j.1000-4890.202004.026
[28]	Zhou Decheng, Xiao Jingfeng, Frolking Steve et al. Urbanization contributes little to global warming but substantially intensifies local and regional land surface warming[J]. Earths Future, 2022, 10(5) e2021EF002401
[29]	Monteiro Madalena Vaz, Doick Kieron J, Handley Phillip et al. The impact of greenspace size on the extent of local nocturnal air temperature cooling in London[J]. Urban Forestry & Urban Greening, 2016, 16: 160-169.
[30]	仇宽彪, 张慧, 高吉喜, 等. 上海城市林地斑块冷岛效应的城乡梯度变化[J]. 生态学杂志, 2021, 40(5) 1409-1418. doi: 10.13292/j.1000-4890.202105.018
	Qiu Kuanbiao, Zhang Hui, Gao Jixi et al. Variation of cool island effect for urban forest patches across an urban-rural gradient in Shanghai. Chinese Journal of Ecology, 2021, 40(5) 1409-1418. doi: 10.13292/j.1000-4890.202105.018
[31]	匡文慧. 城市土地利用/覆盖变化与热环境生态调控研究进展与展望[J]. 地理科学, 2018, 38(10) 1643-1652. doi: 10.13249/j.cnki.sgs.2018.10.008
	Kuang Wenhui. Advance and future prospects of urban land use/cover change and ecological regulation of thermal environment. Scientia Geographica Sinica, 2018, 38(10) 1643-1652. doi: 10.13249/j.cnki.sgs.2018.10.008
[32]	Zhang Xinmin, Estoque Ronald, Murayama Yuji et al. Capturing urban heat island formation in a subtropical city of China based on landsat images: Implications for sustainable urban development[J]. Environmental Monitoring and Assessment, 2021, 193(3) 130 doi: 10.1007/s10661-021-08890-w
[33]	Gao Sihang, Zhan Qingming, Yang Chen et al. The diversified impacts of urban morphology on land surface temperature among urban functional zones[J]. International Journal of Environmental Research and Public Health, 2020, 17(24) 9578 doi: 10.3390/ijerph17249578
[34]	Rao Yongheng, Xu Yang, Zhang Jianjun et al. Does subclassified industrial land have a characteristic impact on land surface temperatures? Evidence for and implications of coal and steel processing industries in a Chinese mining city[J]. Ecological Indicators, 2018, 89: 22-34. doi: 10.1016/j.ecolind.2018.01.058
[35]	Ma Yuling, Zhang Shaohua, Yang Kun et al. Influence of spatiotemporal pattern changes of impervious surface of urban megaregion on thermal environment: A case study of the Guangdong-Hong Kong-Macao Greater Bay Area of China[J]. Ecological Indicators, 2021, 121: 107106 doi: 10.1016/j.ecolind.2020.107106
[36]	黄亚平, 卢有朋, 单卓然, 等. 武汉市主城区热岛空间格局及其影响因素研究[J]. 城市规划, 2019, 43(4) 41-47+52.
	Huang Yaping, Lu Youpeng, Shan Zhuoran et al. Study on spatial layout and influencing factors of heat island in the main urban area of Wuhan. City Planning Review, 2019, 43(4) 41-47+52.

地表热环境等级	分类标准
注：LST_i为研究区域中像元i的LST数值，M为LST的平均值，S为LST的标准差。
极低温区	LST_i<M−2.5×S
低温区	M−2.5×S≤LST_i≤M−1.5×S
次低温区	M−1.5×S<LST_i≤M−0.5×S
中温区	M−0.5×S<LST_i≤M+0.5×S
次高温区	M+0.5×S<LST_i≤M+1.5×S
高温区	M+1.5×S<LST_i≤M+2.5×S
极高温区	LST_i>M+2.5×S

模型类型	模型参数	模型含义
一阶空间自回归模型	ρ≠0，θ=λ=0	空间中因变量的观测值仅受邻近区域因变量的影响
普通线性回归模型	θ≠0，ρ=λ=0	空间中因变量的观测值仅受对应自变量的影响
空间滞后模型	ρ≠0，λ=0	空间中因变量之间存在空间效应，因变量的观测值既受对应自变量的影响，也受邻近区域因变量的影响
空间误差模型	ρ=0，λ≠0	空间中因变量之间不存在空间相关性，仅考虑自变量的空间自相关性，空间中因变量的观测值同时受对应的自变量、邻近区域的自变量及因变量的影响

功能区	地表热环境等级面积比例 /%							热岛强度/℃
功能区	极低温区	低温区	次低温区	中温区	次高温区	高温区	极高温区	热岛强度/℃
居住区	0.000	0.000	0.665	14.721	47.334	35.393	1.886	3.231
公共管理与服务区	0.000	0.000	0.477	5.568	30.060	48.746	15.149	4.628
商业服务业区	0.000	0.000	0.881	9.900	38.116	43.675	7.429	3.791
工业区	0.013	0.056	0.961	7.731	23.834	42.882	24.522	4.994
仓储区	0.000	0.000	0.470	4.701	21.301	50.043	23.485	5.092
交通运输区	0.000	0.000	0.233	4.715	11.700	45.672	37.680	5.737
公共设施区	0.000	0.376	5.772	17.278	35.493	33.075	8.006	3.283

实际是否形成城市热岛	Logistic模型预测
	是否形成城市热岛		正确率/%
	0	1	正确率/%
注：—为无此项。
0	2101	117	94.725
1	1053	1434	57.660
总体百分比	—	—	75.133

变量	β	S.E.	sig.	Exp(β)
居住区比例	1.028	0.101	0.000	2.795
公共管理与服务区比例	1.115	0.146	0.000	3.048
商业服务业区比例	0.833	0.163	0.000	2.300
工业区比例	1.891	0.279	0.000	6.625
仓储区比例	1.359	0.258	0.000	3.891
交通运输区比例	0.503	0.165	0.002	1.654
公共设施区比例	0.364	0.093	0.000	1.439
常数	−0.605	0.037	0.000	0.546
