珠三角公路通达性演化及其对城市潜力的影响

doi:10.13249/j.cnki.sgs.2013.05.513

摘要/Abstract

摘要：

将空间句法模型与GIS结合,基于1990年、2009年公路网数据,定量分析1990年以来珠三角公路网通达性时空演变,进而探讨其对城市潜力变化的影响。结果表明：① 近20 a来,珠三角公路网拓扑连接等级差异趋于缩小、整体通达性显著提高,但核心区内部和外部路网发育差距趋于扩大;② 公路通达性总体上呈“核心-外围”结构,核心区范围不断扩大,至2009年以广-佛核心都市区、深-莞-惠都市区为最高,向外围逐渐递减,并形成了“∧”型高集成度轴线分布带及由此向外放射状延伸的态势;各等级公路轴线分布格局变化空间分异明显,公路网拓扑连接的区域不均衡性更加明显;三大地带公路通达性空间差异明显,中部最高且提高较快,东部次之但与中部差异趋于缩小,西部相对最低且与中、东部的差异进一步扩大;③ 公路网总体布局上智能性、可理解性有较大提高,但核心区外部公路智能度仍普遍较差;④ 公路通达性与城市潜力呈正相关性并得到增强,公路交通对城市潜力变化影响更加显著,但2009年仍属中度相关。

关键词: 空间句法, 路网, 通达性, 城市潜力, 珠三角

Abstract:

Based on the road network data of 1990 and 2009 in the Zhujiang River Delta (ZJRD), this article explores the spatio-temporal evolution of the road network accessibility and quantitatively analyzes its influences on urban potential change of ZJRD region with the support of space syntax model, GIS technology and statistical analysis method. The basic conclusions are obtained as follows: 1) The grade-layer difference of the topological connection of the road network has decreased, and the whole accessibility of the road network have been improved significantly from 1990 to 2009. However, the road network development gap between inner and out the core region of ZJRD has been enlarged. 2) The road network accessibility shows an obvious core-periphery structure as a whole, and the core area has been gradually expanded. In 2009, the road network accessibility of Guangzhou-Foshan metropolitan region and Shenzhen-Dongguan-Huizhou metropolitan region was the highest, gradually decreasing from those two regions to the surroundings, which results in the “∧-shaped” form of high integration axes and spatial pattern of the entire road axes stretching radially. There are obvious differences of the spatial distribution change of different grade road axes, and the imbalance of the topological connection of the road network is more significant. The road accessibility in the middle zone is the highest and has been improved quickly, and the east zone ranks the second highest and the disparity between the eastern zone and the middle zone has decreased. Whereas, the road accessibility in the western zone is the lowest, and the disparity between the western zone and the middle and eastern zones has been on a trend of expanding. 3) The spatial intelligibility of the layout of the road network as a whole has improved significantly, but most roads out the core region have still low spatial intelligibility and poor convenience. 4) There is a positive correlation between the road accessibility and city potential of ZJRD region, and the correlative degree has strengthened, indicating that the influence of road traffic on urban potential change is more significant. But it still remained a moderate correlation in 2009.

Key words: space syntax, road network, accessibility, urban potential, Zhujiang River Delta

中图分类号:

F512.99

梅志雄, 徐颂军, 欧阳军. 珠三角公路通达性演化及其对城市潜力的影响[J]. 地理科学, 2013, 33(5): 513-520.

Zhi-xiong MEI, Song-jun XU, Jun OUYANG. Road Network Accessibility and Its Influence on City Potential in Zhujiang River Delta[J]. SCIENTIA GEOGRAPHICA SINICA, 2013, 33(5): 513-520.

图/表 6

图1

表1

表2

图2

图3

图4

参考文献 37

[12]	Li S M, Shum Y.Impacts of the national trunk highway system on accessibility in China[J]. Journal of Transport Geography,2001, 9(1):39-48.
[13]	曹小曙,薛德升,阎小培.中国干线公路网络联结的城市通达性[J].地理学报,2005,60(6):903-910.
[14]	刘俊,陆玉麒.江苏省公路交通网络可达性评价研究[J].南京师大学报(自然科学版),2008,31(3):129-134.
[15]	Bowen J.Airline hubs in Southeast Asia: national economic development and nodal accessibility[J].Journal of Transport Geography,2000, 8:25-41.
[16]	姜海宁,谷人旭,陆玉麒,等.江苏省民用机场可达性及其服务能力评价[J].地理科学,2010,30(4):521-528.
[17]	张莉,陆玉麒.基于陆路交通网的区域可达性评价:以长江三角洲为例[J].地理学报,2006,61(12):1235-1246.
[18]	曹小曙,阎小培.经济发达地区交通网络演化对通达性空间格局的影响:以广东东莞市为例[J].地理研究,2003,22(3):305-312.
[19]	Roger V.Location, accessibility and regional development: The appraisal of trans-European networks[J].Transport Policy,1995,2(4):225-234.
[20]	Chi G Q.The impacts of transport accessibility on population change across rural, suburban and urban areas: A case study of Wisconsin at sub-county levels[J].Urban studies,2012,49(3):1-21.
[21]	刘海隆,包安明,陈曦,等.新疆交通可达性对区域经济的影响分析[J].地理学报,2008,63(4):428-436.
[22]	朱兵,张小雷,桂东伟,等.新疆城镇发展与交通可达性相互影响[J].地理科学进展,2010,29(10):1239-1248.
[23]	钟业喜,陆玉麒.基于空间联系的城市腹地范围划分——以江苏省为例[J].地理科学,2012,32(5):536-543.
[24]	王振波,徐建刚,朱传耿,等.中国县域可达性区域划分及其与人口分布的关系[J].地理学报,2010,65(4):416-426.
[25]	梅志雄,徐颂军,欧阳军,等.近20年珠三角城市群城市空间相互作用时空演变[J].地理科学,2012,32(6):694-701.
[26]	Hillier B.Space is the machine: a configurational theory of architecture[M].New York:Cambridge University Press,1996.
[27]	Hillier B.The common language of space:a way of looking at the social,economic and environmental functioning of cities on a common basis[J]. Journal of Environmental Sciences,1999,11(3):343-349.
[28]	Batty M.Exploring isovist fields:space and shape in architectural and urban morphology[J].Environment and Planning B,2001,(28):123-150.
[29]	Song Y,Gee G C,Fan Y.Do physical neighborhood characteristics matter in predicting traffic stress and health outcomes?[J].Transportation Research Part F,2007,(10):164-176.
[30]	Jiang B,Liu C K.Street-based topological representations and analyses for predicting traffic flow in GIS[J].International Journal of Geogra-phical Information Science,2009,23(9):1119-1137.
[1]	刘承良,余瑞林,曾菊新,等.武汉城市圈城乡道路网的空间结构复杂性[J].地理科学,2012,32(4):426-433.
[2]	刘承良,余瑞林,熊剑平,等.武汉都市圈路网空间通达性分析[J].地理学报,2009,64(12):1488-1498.
[31]	程昌秀,张文尝,陈洁,等.基于空间句法的地铁可达性评价分析:以2008年北京地铁规划图为例[J].地球信息科学,2007,9(6):31-35.
[32]	陈明星,沈非,查良松.基于空间句法的城市交通网络特征研究——以安徽省芜湖市为例[J].地理与地理信息科学,2005,21(2):39-42.
[3]	李涛,曹小曙,黄晓燕.珠江三角洲交通通达性空间格局与人口变化关系[J].地理研究,2012,31(9):1661-1672.
[4]	孟德友,陆玉麒.基于铁路客运网络的省际可达性及经济联系格局[J].地理研究,2012,31(1):107-122.
[33]	陈垚森,陈文成.基于空间句法的泉州城区道路网形态研究[J].热带地理,2011,31(6):604-608.
[34]	樊文平,石忆邵,车建仁,等.基于GIS与空间句法的道路网结构对城市商业中心布局的影响[J].中山大学学报(自然科学版),2011,50(3):112-117.
[5]	Hansen W G.How accessibility shapes land-use[J]. Journal of the American Institute of Planners,1959,25(2):73-76.
[6]	陈松林,陈进栋,韦素琼.福建省综合交通可达性格局及其与制造业空间分布的关系分析[J].地理科学,2012,32(7):807-815.
[35]	广东省地图出版社.珠江三角洲公路交通图[M].广州: 广东省地图出版社,2009.
[36]	广东省地图出版社.广东省交通旅行图[M].广州: 广东省地图出版社,1990.
[7]	Gutiérrez J.Location,economic potential and daily accessibility:An analysis of the accessibility impact of the high-speed line Madrid-Barcelona-French border[J].Journal of Transport Geography,2001,9(4):229-242.
[8]	金凤君,王娇娥.20世纪中国铁路网扩展及其空间通达性[J].地理学报,2004,59(2):293-302.
[9]	孟德友,陆玉麒.高速铁路对河南沿线城市可达性及经济联系的影响[J].地理科学,2011,31(5):537-543.
[10]	Dupuy G, Stransky V.Cities and highway network in Europe[J]. Journal of Transport Geography,1996,4(2):107-121.
[11]	Linneker B, Spence N.Road transport infrastructure and regional economic development: the regional development effects of the M25 London orbital motorway[J].Journal of Transport Geography,1996,4(2):77-92.
[37]	江斌,黄波,陆锋.GIS环境下的空间分析和地学视觉化[M].北京:高等教育出版社,2002.

变量	连接值	控制值	三步深度值	集成度
1990年	3.264	1	17.440	1.918
2009年	4.550	1	34.309	2.505

等级	1990年			2009年
等级	连接值	控制值	三步深度值	连接值	控制值	三步深度值
第一等级	0.55%	6.59%	0.00%	8.49%	7.30%	14.43%
第二等级	19.23%	32.42%	8.24%	31.75%	35.31%	32.94%
第三等级	80.22%	60.99%	91.76%	59.76%	57.39%	52.63%
