高铁站区产业空间分布及集聚特征——以沪宁城际高铁南京站为例

doi:10.13249/j.cnki.sgs.2012.03.301

地理科学 ›› 2012, Vol. 32 ›› Issue (3): 301-307.doi: 10.13249/j.cnki.sgs.2012.03.301

高铁站区产业空间分布及集聚特征——以沪宁城际高铁南京站为例

王丽¹(), 曹有挥¹(), 刘可文^1,², 王聪^1,²

1. 中国科学院南京地理与湖泊研究所,江苏南京 210008
2. 中国科学院研究生院,北京 100049

收稿日期:2011-09-05 修回日期:2012-02-15 出版日期:2012-03-25 发布日期:2012-03-25
作者简介:
作者简介：王丽（1979-）,女,江苏徐州人,博士研究生,主要从事区域发展和规划方面研究。E-mail:xinwei_001@yahoo.com.cn
基金资助:
国家自然科学基金重点项目（41130750）、国家自然科学基金项目（40871070）资助

Spatial Distribution and Clusters of Industry Nearby High-speed Rail Station: The case of Nanjing Station, Shanghai-Nanjing Motor Train

Li WANG^1,²(), You-hui CAO¹(), Ke-wen LIU^1,², Cong WANG^1,²

1.Nanjing Institute of Geography and Limnology, Chinese Academy of Sciences 210008, China
2. Graduate University of Chinese Academy of Sciences, Beijing 100049, China

Received:2011-09-05 Revised:2012-02-15 Online:2012-03-25 Published:2012-03-25

摘要/Abstract

摘要：

分析沪宁城铁南京站乘客的出行距离特性,初步确定高铁站区圈层范围为3 000 m。以南京站周边3 000 m范围内6 145个企业的地址、行业隶属、成立时间等为研究数据,运用空间分析方法,探讨高铁站区产业的分布与空间集聚特征。 ① 从总体看,高铁站区产业的空间分布具有明显的圈层结构,以车站为中心,以500 m为缓冲半径,在1 500~2 000 m范围企业密度最大,2 000 m以外企业密度陡然降低。② 各行业空间集聚趋势类似,随着距离增大集聚程度降低。但空间尺度上存在差异,交通运输业和房地产业集聚现象更为明显,交通指向性显著;批发和零售业集聚峰值相对最大,在大范围上有分散分布的趋势。③ 各行业空间分异特征显著,整体呈现“东低西高”,空间分异特征大致存在以下三种模式,即“小分散、大集聚”、 “大分散、大集聚”、“大分散、小集聚”。

关键词: 高铁站区, 产业分布, 集聚, 空间分析, 沪宁城铁, 南京

Abstract:

The questionnaires are surveyed including the passengers’ travel destination, traffic mode choice and the travel distance, etc., in the Nanjing Station of Shanghai-Nanjing Intercity high-speed railway. Collecting the address, industry category, set-up time of 6 145 companies surrounding station within 3 000 m as the study samples, using spatial analysis methods, this article analyzes the distribution of industries and spatial clusters by high-speed railway station. The resluts are as follows. 1) Generally speaking, industry location has obvious circle structure around high-speed station. The company density shows a circle structure with the Nanjing Station as the center and 500 m as the buffer radius. The company density ascends to the top at 1 500-2 000 m, and has break in the point of 2 000 m far from the Nanjing Station. The wholesale and retail industry has the largest number, business service industry in second, science and technology service industry in third. Comparing industry proportion in each circle, we come to the conclution that business service industry, accommodation and catering industry increase gradually at 0-1 500 m, reduce significantly at 2 000 m, which confirms the high-speed railway passengers on business service industry and accommodation and catering industry needs a 1 500 m-radius concentration. 2) The trend of spatial industrial concentration is similar, decreasing with the distance. Owing to the different spatial scales, the location of wholesale and retail industry has most options; transportation industry and real estate industry tend to have a significant traffic location. The accommodation and catering industry, computer service industry, science and technology service industry as well as the resident service industry show homogeneous distribution based on the cluster distribution. 3) There is a significant difference in the spatial distribution of the industry, featured by “higher in the west and lower in the east”. The spatial distribution patterns are generally identified in three modes of concentration. The transportation industry and real estate industry have a "small scatter, large cluster" mode, that is, the spatial distribution of companies show relative concentration and form a single hotspot. The resident service industry, wholesale and retail industry as well as accommodation and catering industry present a “large scatter, large cluster” mode. Business service industry, science and technology service industry and computer service industry have a “large scatter, small cluster” mode. The results above confirm the Ripley' s K function analysis.

Key words: high-speed railway station, industrial distribution, cluster, spatial analysis, Shanghai-Nanjing intercity high-speed railway, Nanjing

中图分类号:

F062.9

王丽, 曹有挥, 刘可文, 王聪. 高铁站区产业空间分布及集聚特征——以沪宁城际高铁南京站为例[J]. 地理科学, 2012, 32(3): 301-307.

Li WANG, You-hui CAO, Ke-wen LIU, Cong WANG. Spatial Distribution and Clusters of Industry Nearby High-speed Rail Station: The case of Nanjing Station, Shanghai-Nanjing Motor Train[J]. SCIENTIA GEOGRAPHICA SINICA, 2012, 32(3): 301-307.

图/表 6

图1

图2

图3

图4

图5

图6

参考文献 24

[1]	舒慧琴,石小法.东京都市圈轨道交通系统对城市空间结构发展的影响[J].国际城市规划,2008,(3):15~22.
[2]	Ureña M José, Philippe Menerault, Maddi Garmendia.The high-speed rail challenge for big intermediate cities: a national, regional and local perspective[J].Cities,2009,(26): 266-279.
[3]	Blum U, Havnes K E, Karlsson C.Introduction to the special issue, the regional and urban effects of high-speed trains[J].The Annals of Regional Science,1997,31(1):1-20.
[4]	FrÖidh Oskar.Market effects of regional high-speed trains on the Svealand Line[J]. Journal of Transport Geography, 2005,(13): 352-361.
[5]	Komei Sasaki,Tadahiro Ohashi, Asao Ando.High-speed rail transit impact on regional systems: does the Shinkansert contribute to dispersion[J].The Annals of Regional Science,1997,31(1):77-98.
[6]	王缉宪,林辰辉.高速铁路对城市空间演变的影响:基于中国特征的分析思路[J].国际城市规划,2011,26(1):16~23.
[7]	孟德友,陆玉麒.高速铁路对河南沿线城市可达性及经济联系的影响[J].地理科学,2011,31(5):537~543.
[8]	郑德高,杜宝东.寻求节点交通价值与城市功能价值的平衡——探讨国内外高铁车站与机场等交通枢纽地区发展的理论与实践[J].国际城市规划, 2007, 22(1): 72~76.
[9]	Hugo Priemus.HST-railway stations as dynamic nodes in urban networks[M]//3rd CPN Conference Proceeding,2006.
[10]	Pol P M J. A renaissance of stations, railways and cities. economic effects, development strategies and organizational issues of European high-speed train stations[D].Delft: Dissertation Ph.D. thesis.2002.
[11]	Sands B.The development effects of high-speed rail station and implication for California[D].Berkeley:University of California at Berkeley,1993.
[12]	Hirota R.Present situation and effects of the Shinkansen[R]. Paris: International Seminar on High-Speed Trains, 1984.
[13]	Brotchie John.Fast rail networks and socioeconomic impacts[M]//Brotchie J et al.Cities of the 21st century: new technologies and spatial systems. New York: Longman Cheshire,1991.
[14]	王昊,龙慧.试论高速铁路网建设对城镇群空间结构的影响[J].城市规划,2009,(4): 41~44.
[15]	周文竹,阳建强.交通导向的城际铁路站场地区空间发展机制[J].城市规划,2010,34(11):88~92.
[16]	陈听. 高速铁路站点周边城市建设与发展研究[D].天津:天津大学硕士论文,2009.
[17]	蒋海兵,徐建刚,祁毅.京沪高铁对区域中心城市陆路可达性影响[J].地理学报,2010,65(10):1287~1298.
[18]	中华人民共和国国家统计局 .行业分类标准[S/OL].
[19]	Okabe A, Yamada I.The K-function method on a network and its computational implementation[J]. Geographical Analysis, 2001,33(3):271-290.
[20]	Besag J.Spatial interaction and statistic alanalysis of lattice systems[J]. J. Roy. Statist. Soc. B, 1974, 36:192-236.
[21]	迟文学,王劲峰,李新虎,等.出生缺陷的空间点格局分析[J].环境与健康杂志,2007,24(4):238~241.
[22]	王远飞,何洪林.空间数据分析方法.北京:科学出版社,2007.
[23]	刘锐,胡伟平,王红亮.基于核密度估计的广佛都市区路网演变分析[J].地理科学,2011,31(1):81~86.
[24]	Gordon I R, Mccann P.Industrial clusters:complexes, agglomeration and/or social Networks?[J]. Urban Studies, 2000, 37(3): 513-532.
