黄河上游内蒙古河段平滩流量对人类活动和气候变化的响应

doi:10.13249/j.cnki.sgs.2016.06.005

摘要/Abstract

摘要：

冲积河流平滩流量既反映了河道尺度上的水文-地貌耦合关系,又与流域因素密切相关。从这一概念出发,以黄河上游内蒙古河段为例,研究了平滩流量的变化,并在流域层面与河道层面上对其成因进行了研究。结果表明：上游水库调节改变了出库流量过程,使汛期流量大幅度减小,泄流过程均匀化,因而平滩流量减小。在龙羊峡水库修建后洪水流量减小导致漫滩机遇降低的情形下,泥沙淤在主槽内,也是平滩流量减小的重要原因。泥沙冲淤对于平滩流量的影响存在着某种累积或滞后效应,巴彦高勒平滩流量Q_bf,BY不仅与当年的冲淤量有关,还与以前冲淤量有关,前4 a平均淤积量对平滩流量的影响最大。建立了平滩流量与前4 a累计淤积量、年均流量、年最大日流量的多元回归方程,该方程表明平滩流量既与当年的流量特征相联系,也与一定时间尺度上河道冲淤造成的后果相联系,反映了某种水文地貌耦合关系。研究还表明,存在着以下因果关系链：龙羊峡水库修建→汛期来沙系数增大→河道淤积加强→平滩流量减小。因此,通过改变龙羊峡水库的运用方式,增大汛期下泄流量,可以减小河道淤积、增大平滩流量,从而增大下泄洪水的能力,降低凌汛期间的防洪压力。平滩流量的变化是流域因素变化的结果,所建立的多元回归方程表明,在50 a的时间尺度上,暖干化指标的增大、引水率的增大、水库总库容的增大和天然径流系数的减小,是黄河上游平滩流量减小的原因。

关键词: 平滩流量, 水文地貌耦合, 水库调节, 流域因素, 黄河上游

Abstract:

Bankfull discharge (Q_bf) of alluvial rivers reflects the hydro-geomorphic coupling at channel-scale. It is closely related with the drainage basin factors. Based on this concept, we have studied the variation in the Q_bf of the Inner Mongolia reach of the upper Huanghe River, and elucidated the causes at channel and drainage basin levels. The results show that the dams’ regulation changes the flow regime, making the downstream flows more even, greatly reducing the high-flow season discharges and therefore, Q_bf of the downstream channel decreased. The enhanced channel sedimentation (S_dep) after the Longyangxia Dam construction, especially the sedimentation within the main channel due to the decreased bankfull frequency is also an important factor. The sedimentation has some time-lag or cumulative effect on the variation in Q_bf, namely, Q_bf correlates not only with the S_dep of the same year, but also with the moving averages of S_dep of the foregoing N-years, and the correlation coefficient (r) reaches the highest at N=4. A multiple regression equation has been established between Q_bf and annual discharge, yearly maximum discharge and the foregoing 4-year average S_dep, indicating that Q_bf depends not only on the flow conditions at the same year, but also on the cumulative S_dep at a certain time-scale. The existence of a cause-effect chain has been identified, which is generalized as follows: the construction of the Longyangxia Dam→ the increased July-October C/Q (C: suspended sediment concentration; Q: water discharge)→the enhanced S_dep→the decreased Q_bf. Thus, by means of increasing the July-October flow release from the Longyangxia Reservoir, the S_dep can be reduced and the Q_bf increased. Therefore, the increased flood-risk due to the reduced Q_bf may be mitigated. As well, it has been demonstrated that the decrease in Q_bf occurs as the outcome of the changing drainage basin factors. A multiple regression equation was established, which indicates that the increased climatic warm and dry trend, the water diversion ratio and the total capacity of the reservoirs and the decreased natural runoff coefficient are the causes for the decreased Q_bf in the upper Huanghe River.

Key words: bankfull discharge, hydro-geomorphic coupling, regulation by reservoirs, drainage basin factors, the upper Huanghe River

中图分类号:

TV147

许炯心. 黄河上游内蒙古河段平滩流量对人类活动和气候变化的响应[J]. 地理科学, 2016, 36(6): 837-845.

Jiongxin Xu. Response of the Bankfull Discharge to the Human Activity and Climate Change: The Inner Mongolia Reach of the Upper Huanghe River[J]. SCIENTIA GEOGRAPHICA SINICA, 2016, 36(6): 837-845.

图/表 9

图1

图2

表1

表2

图3

图4

图5

图6

表3

参考文献 29

[1]	钱宁, 张仁, 周志德. 河床演变学[M] . 北京: 科学出版社, 1987 .
	[Qian Ning, Zhang Ren, Zhou Zhide. River Channel Processes .Beijing: Science Press, 1987.
[2]	Knighton D.Fluvial Forms and Processes:A New Perspective[M] . London: Arnold, 1998: 1-376.
[3]	Dury G H, Hails J R, Robbie M B.Bankfull Discharge and the Magnitude-frequency Series[J]. Australian Journal of Science, 1963, 26: 123-124.
[4]	Pickup G, Warner R F.Effects of Hydrologic Regime on Magnitude and Frequency of Dominant Discharge[J]. Journal of Hydrology, 1976, 29(1/2): 51-75. doi: 10.1016/0022-1694(76)90005-6
[5]	Crowder D W, Knapp H V.Effective Discharge Recurrence Intervals of Illinois Streams[J]. Geomorphology, 2005, 64(3/4): 167-184. doi: 10.1016/j.geomorph.2004.06.006
[6]	Williams, P G.1978.Bankfull Discharge of Rivers[J]. Water Resources Research , 23(8): 1471-1480. doi: 10.1029/WR014i006p01141
[7]	Andrews E D.Effective and Bankfull Discharges of Streams in the Yampa River Basin, Colorado and Wyoming[J]. Journal of Hydrology, 1980, 46(3/4): 311-330. doi: 10.1016/0022-1694(80)90084-0
[8]	Navratil O, Albert M B, Herouin E et al. Determination of Bankfull Discharge Magnitude and Frequency:Comparison of Methods on 16 Gravel Bed River Reaches[J]. Earth Surface Processes and Landforms, 2006, 31: 1345-1363. doi: 10.1002/esp.1337
[9]	Castro J M, Jackson P L.Bankfull Discharge Recurrence Intervals and Regional Hydraulic Geometry Relationships:Patterns in the Pacific Northwest[J]. Journal of the American Water Resources Association, 2001, 37(5): 1249-1262.
[10]	Simon A D W, Heins A. Suspended-sediment Transport Rates at the 1.5-year Recurrence Interval for Ecoregions of the United States:Transport Conditions at the Bankfull and Effective Discharge?[J]. Geomorphology, 2004, 58: 243-262. doi: 10.1016/j.geomorph.2003.07.003
[11]	Comez B, Coleman S E, Sy V W K et al. Channel change, bankfull and effective discharges on a vertically accreting, meandering, gravel-bed river[J]. Earth Surface Processes and Landforms, 2007, 32, doi:10.1002/esp.1424. doi: 10.1002/esp.1424
[12]	许炯心. 黄河河流地貌过程[M] . 北京: 科学出版社, 2012: 1-525.
	[Xu Jiongxin.The Geomorphic Processes of the Yellow River . Beijing: Science Press, 2012: 1-525.]
[13]	Xu J X.Bankfull frequency of the middle and lower Hanjiang River and its implications in river channel processes[J]. Transactions,Japanese Geomorphological Union,1994,15A: 95-107.
[14]	陈建国, 胡春宏, 董占地, 等. 黄河下游河道平滩流量与造床流量的变化过程研究[J]. 泥沙研究, 2006, (5): 10-16.
	[Chen Jianguo, Hu Chunhong, Dong Zhande et al. Change of Bankfull and Bed-forming Discharges in the Lower Yellow River. Journal of Sediment Research, 2006,(5): 10-16.]
[15]	吴保生, 夏军强, 张原锋. 黄河下游平滩流量对来水来沙变化的响应[J]. 水利学报, 2007, 38(7): 886-892. doi: 10.3321/j.issn:0559-9350.2007.07.019
	[Wu Baosheng, Xia Junqiang, Zhang Yuanfeng.Response of bankfull discharge to variation of flow discharge and sediment load in lower reaches of Yellow River. Journal of Hydraulic Engineering, 2007, 38(7): 886-892.] doi: 10.3321/j.issn:0559-9350.2007.07.019
[16]	Wu B S, Xia J Q, Fu X D et al. Effect of altered flow regime on bankfull area of the Lower Yellow River, China[J]. Earth Surface Processes and Landforms, 2008, 33(10): 1585-1601. doi: 10.1002/esp.1679
[17]	Wu Baosheng, Wang Guangqian, Xia Junqiang et al. Response of Bankfull Discharge to Discharge and Sediment Load in the Lower Yellow River[J]. Geomorphology, 2008, 100(3/4): 366-376. doi: 10.1016/j.geomorph.2008.01.007
[18]	Xia J Q, Wu B S, Wang G Q et al. Estimation of Bankfull Discharge in the Lower Yellow River Using Different Approaches[J]. Geomorphology, 2010, 117: 66-77. doi: 10.1016/j.geomorph.2009.11.007
[19]	吴保生. 冲积河流平滩流量的滞后响应模型[J]. 水利学报, 2008, 39(6): 680-687. doi: 10.3321/j.issn:0559-9350.2008.06.007
	[Wu Baosheng.Delayed Response Model for Bankfull Discharge of Alluvial Rivers. Journal of Hydraulic Engineering, 2008, 39(6): 680-687.] doi: 10.3321/j.issn:0559-9350.2008.06.007
[20]	吴保生. 冲积河流河床演变的滞后响应模型——Ⅰ模型建立[J]. 泥沙研究, 2008, (6): 1-7.
	[Wu Baosheng.Delayed response model for fluvial processes of alluvial rivers-Imodel development. Journal of Sediment Research, 2008,(6): 1-7.]
[21]	吴保生. 冲积河流河床演变的滞后响应模型——II 模型应用[J]. 泥沙研究,2008,(6) :30-37.
	[Wu Baosleng.Delayed response model for fluvial processes of alluvial rivers -II model applications. Journal of Sediment Research,2008,(6) : 30-37. ]
[22]	侯素珍, 常温花, 王平, 等. 黄河内蒙古段河道萎缩特征及成因[J]. 人民黄河, 2007, 29(1): 25-26, 29. doi: 10.3969/j.issn.1000-1379.2007.01.012
	[Hou Suzhen, Chang Wenhua, Wang Ping et al. Characteristics and Cause of Formation of Channel Atrophy at Inner Mongolia Section of the Yellow River. Yellow River, 2007, 29(1): 25-26, 29.] doi: 10.3969/j.issn.1000-1379.2007.01.012
[23]	李凌云, 吴保生, 侯素珍. 滞后响应模型在黄河内蒙古河段的应用[J]. 水力发电学报, 2011, 30(1): 70-77.
	[Li Lingyun, Wu Baosheng, Hou Suzhen.Application of Delayed Response Model to Bankfull Discharge in the Inner Mongolia Reach of Yellow River. Journal of Hydroelectric Engineering, 2011, 30(1): 70-77.]
[24]	潘威, 闫芳芳, 郑景云, 等. 1766年以来黄河上中游汛期径流量变化的同步性[J]. 地理科学, 2013, 33(9): 1145-1149.
	[Pan Wei, Yan Fangfang, Zheng Jingyun et al. The Synchronization of natural runoff chang in flood-season of upper and middle reaches of the Huanghe River in 1766-2004. Scientia Geographica Sinica, 2013, 33(9): 1145-1149.]
[25]	邴龙飞, 邵全琴, 刘纪远, 等. 基于小波分析的长江和黄河源区汛期、枯水期径流特征[J]. 地理科学, 2011, 31(2): 232-238
	. [Bing Longfei, Shao Quanqin, Liu Jiyuan et al. Runoff Characteristic in Flood and Dry Seasons in Source Regions of Changjiang River and Huanghe River Based on Wavelet Analysis. Scientia Geographica Sinica, 2011, 31(2): 232-238.]
[26]	许炯心. 异源水沙对黄河上游兰州至头道拐河段悬移质泥沙冲淤的影响[J].泥沙研究,2014,(5), 1-10. doi: 10.3969/j.issn.0468-155X.2014.05.001
	[Xu Jiongxin.Channel sedimentation in the Lanzhou - Toudaoguai reach of the upper Yellow River influenced by runoff and sediment from different source areas. Journal of Sediment Research, 2014,(5): 1-10.] doi: 10.3969/j.issn.0468-155X.2014.05.001
[27]	钱宁, 周文浩. 黄河下游河床演变[M] . 北京: 科学出版社, 1965: 1-160.
	[Qian Ning, Zhou Wenhao.Channel Process of the Lower Yellow River . Beijing: Science Press, 1965: 1-160.]
[28]	Moraes J M, Pellegrino H Q, Ballester M V et al. Trends in Hydrological Parameters of a Southern Brazilian Watershed and Its Relation to Human Induced Changes[J]. Water Resources Management , 1998,(12): 295-311. doi: 10.1023/A:1008048212420
[29]	Xu J X.Complex response of channel fill-scour behavior to reservoir Construction: an example of the upper Yellow River, China[J]. River Research and Applications, 2013, 29: 593-607. doi: 10.1002/rra.2558

	C_re	C_re/Q_wH,Tang	SD_mr	C_v,mr	Q_wm,max/Q_wm,min	Q_wH,L	Q_w,L	Q_wH,L/Q_w,L	Q_bf,BY
C_re	1.00	0.92	-0.71	-0.76	-0.65	-0.69	-0.57	-0.78	-0.68
C_re/Q_wH,Tang	0.92	1.00	-0.72	-0.75	-0.67	-0.72	-0.63	-0.80	-0.71
SD_mr	-0.71	-0.72	1.00	0.93	0.83	0.97	0.90	0.92	0.61
C_v,mr	-0.76	-0.75	0.93	1.00	0.92	0.85	0.71	0.94	0.60
Q_wm,max/Q_wm,min	-0.65	-0.67	0.83	0.92	1.00	0.71	0.61	0.79	0.59
Q_wH,L	-0.69	-0.72	0.97	0.85	0.71	1.00	0.95	0.91	0.58
Q_w,L	-0.57	-0.63	0.90	0.71	0.61	0.95	1.00	0.75	0.57
Q_wH,L/Q_w,L	-0.78	-0.80	0.92	0.94	0.79	0.91	0.75	1.00	0.55
Q_bf,BY	-0.68	-0.71	0.61	0.60	0.59	0.58	0.57	0.55	1.00

	I_wd	C_nr	R_div	ΣC_re	Q_bf,BY
I_wd	1.00	-0.55	0.50	0.55	-0.56
C_nr	-0.55	1.00	-0.61	-0.54	0.69
R_div	0.50	-0.61	1.00	0.71	-0.64
ΣC_re	0.55	-0.54	0.71	1.00	-0.77
Q_bf,BY	-0.56	0.69	-0.64	-0.77	1.00
