南通海岸带滩涂开发类型选择与空间功能配置研究

doi:10.13249/j.cnki.sgs.2017.01.017

摘要/Abstract

摘要：

海岸带滩涂开发类型选择与空间布局是海岸带综合管理研究的重要内容,对于促进海岸带可持续发展具有重要意义。以海岸带资源环境-社会经济条件与滩涂开发类型对应关系透视为基础,结合南通海岸带滩涂条件、开发类型演变和区域发展背景分析,提出该地区生态旅游、农业和港口–工业–城镇多元化的滩涂综合利用模式,集成适宜性评价与分区、多部门规划冲突与协调等方法,探讨了南通海岸带滩涂地区生态与旅游、农业和港工城等功能区的空间配置路径。南通海岸带地区三类空间适宜比例分别23.5%,32.7%和43.8%,可以作为海岸带综合管理政策制定的参考。

关键词: 海岸带滩涂, 开发类型, 空间功能配置, 南通市

Abstract:

To coordinate the relationships between resource and environmental capacities of coastal zone and sustainable social economic development is the hotspots concerned by the government agencies and societies. Tidal flat is one of the most important resources in the coastal zone. How to identify tidal flat resources development mode and spatial function arrangement is an important scientific problem which needed to be solved in the integrated coastal zone management, it plays an important role in promoting sustainable development in the coastal area. Based on literature review of the integrated coastal zone management, the relationship between resources and social-economic conditions and evolution laws of the tidal flat development mode in coastal area is explored. Integrated with resources conditions, tidal flat developing history and regional development background analysis in Nantong coastal zone, this article proposes that comprehensive tidal flat developing mode which includes ecological protection and tourism, agricultural production and industrial-town development should be carried out in the future. Later, the logical route and the method of spatial arrangement of different economic and social activities are discussed integrated with the management of key ecological area, coordination and cooperation among multi-sectors and suitability assessment support. Empirical analysis of coastal zone in Nantong City shows that except for allocating space for tidal flat tourism, agriculture, harbor-industrial and town, we should also reserve large tidal flat area for the next generation. After coordinated with different planning covering the coastal zone area, the area proportion of different economic activities were identified, they were 23.5%, 32.7% and 43.8%.The spatial configuration results is obtained as follows, tidal flat for ecological protection and tourism are mainly distributed in eastern part of the Mafeng River and the eastern part of the Yaowanggang River, tidal flat for agriculture are concentrated in eastern part of Rutai river and the southern part of the Yaowanggang River, tidal flat for harbor-industrial and town are mainly distributed in northern part of Juekan river and southern part of radial sand ridges of Yao. Finally, this article explores spatial management rules to enhance the dominant function of different areas, and optimize the configuration of production factors, including economic activities agglomeration scale control, the use of pesticides and chemical fertilizers restrict, and waste disposal central control, which can provide an scientific guidance for tidal flat resources sustainable development. This study also indicates that the coordination regimes among different sectors should be explored deeply in the further.

Key words: tidal flat resources in the coastal zone, tidal flat resources development types, configuration of different functional space, Nantong City

中图分类号:

P967/K902

陈诚. 南通海岸带滩涂开发类型选择与空间功能配置研究[J]. 地理科学, 2017, 37(1): 138-147.

Cheng Chen. Coastal Tidal Flat Development Mode Choice and Spatial Configuration of Different Functional Areas in Nantong Coastal Zones[J]. SCIENTIA GEOGRAPHICA SINICA, 2017, 37(1): 138-147.

图/表 9

图1

图2

图3

图4

表1

图 5

图6

图7

图8

参考文献 31

[1]	侯西勇,徐新良.21世纪初中国海岸带土地利用空间格局特征[J]. 地理研究,2011,30(8):1370-1379.
	[Hou Xiyong, Xu Xinliang.Spatial patterns of landuse in coastal zones of China in the early 21st century. Geographical Research, 2011, 30(8):1370-1379.]
[2]	李博. 辽宁沿海地区人海经济系统脆弱性评价[J].地理科学,2014,34(6):711-716.
	[Li Bo.Vulnerability in human-sea economic system of Liaoning coastal area in china. Scientia Geographic Sinica, 2014, 34(6): 711-716.]
[3]	王琪琪, 濮励杰, 朱明, 等. 沿海滩涂围垦区土壤质量演变研究——以江苏省如东县为例[J]. 地理科学,2016,36(2):256-264. doi: 10.13249/j.cnki.sgs.2016.02.012
	[Wang Qiqi, Pu Lijie,Zhu Ming et al. Soil quality evolution in coastal reclamation zones: A case study of rudong county of jiangsu province. Scientia Geographic Sinica, 2016, 36(2): 256-264. doi: 10.13249/j.cnki.sgs.2016.02.012
[4]	范学忠,袁琳,戴晓燕,等.海岸带综合管理及其研究进展[J]. 生态学报,2010,30(6):2756-2765.
	[Fan Xuezhong, Yuan Lin,Dai Xiaoyan et al. The integrated coastal zone management(ICZM) and its progress. Acta Ecologica Sinica, 2010,30(6):2756-2765.]
[5]	张长宽,陈欣迪.海岸带滩涂资源的开发利用与保护研究进展[J].河海大学学报( 自然科学版) ,2016,44(1): 25-33. doi: 10.3876/j.issn.1000-1980.2016.01.005
	[Zhang Changkuan,Chen Xindi.Advances in development, utilization, and protection of coastal tidal flats.Journal of Hehai University(Natural Sciences), 2016,44(1): 25-33.] doi: 10.3876/j.issn.1000-1980.2016.01.005
[6]	王颖,季小梅.中国海陆过渡带——海岸海洋环境特征与变化研究[J].地理科学,2011,31(2):129-135.
	[Wang Ying,Ji Xiaomei.Environmental Characteristics and Changes of CoastalOcean as Land-ocean Transitional Zone of China.Scientia Geographic Sinica, 2011,31(2):129-135.]
[7]	裘江海,蒋鹏.国外滩涂开发与研究进展[J]. 浙江水利科技,2005,(3):12-14.
	[Qiu Jianghai, Jiang Peng.Discussion on the new development mode of the new Beach. Zhejiang Hydrotechnics, 2005,(3):12-14.]
[8]	袁汝华,王震.江苏沿海滩涂开发模式选择[J]. 开放导报,2011,3(156):93-96. doi: 10.3969/j.issn.1004-6623.2011.03.023
	[Yuan Ruhua,Wang Zhen.On Model Selection of Coastal Jiangsu Mud Beaches. China Opening Journal, 2011,3(156):93-96.] doi: 10.3969/j.issn.1004-6623.2011.03.023
[9]	陈君,张长宽,林康. 江苏沿海滩涂资源围垦开发利用研究[J]. 河海大学学报(自然科学版),2011,39(2):213-219. doi: 10.3876/j.issn.1000-1980.2011.02.018
	[Chen Jun, Zhang Changkuan,Lin Kang et al. Spatial layout of reclamation of coastal tidal flats in Jiangsu Province. Journal of HehaiUniversity(Natural Sciences), 2011,39(2):213-219.] doi: 10.3876/j.issn.1000-1980.2011.02.018
[10]	翟金波,田伟君. 滨海滩涂资源的开发历程及主要利用模式分析[J]. 安徽农业科学,2010,38(19):10186-10188. doi: 10.3969/j.issn.0517-6611.2010.19.094
	[Zhai Jinbo, Tian Weijun.Analysis on Development Process and Utilization Patterns of Coastal Beach Resource. Journal of Anhui Agriculture Science, 2010,38(19):10186-10188.] doi: 10.3969/j.issn.0517-6611.2010.19.094
[11]	王芳,朱跃华.江苏省沿海滩涂资源开发模式及其适宜性评价[J].资源科学,2009,11(4):619-628. doi: 10.3321/j.issn:1007-7588.2009.04.013
	[Wang Fang, Zhu Yuehua.Development Patterns and Suitability Assessment of Tidal Flat Resources in Jiangsu Province. Resources Science, 2009,11(4):619-628.] doi: 10.3321/j.issn:1007-7588.2009.04.013
[12]	彭建,王仰麟,景娟,等.中国东部沿海滩涂资源不同空间尺度下的生态开发模式[J].地理科学进展,2003,22(5):515-523. doi: 10.11820/dlkxjz.2003.05.010
	[Peng Jian, Wang Yanglin,Jing Juan et al.The Research on Ecological Development of Shoaly Land in the East of China in Different Spatial Scales. Progress in Geography, 2003,22(5):515-523.] doi: 10.11820/dlkxjz.2003.05.010
[13]	何书金, 李秀彬, 刘盛和,等.环渤海地区滩涂资源特点与开发利用模式[J]. 地理科学进展,2005,21(1):25-34.
	[He Shujin, Li Xiubin,Liu Shenghe et al.Beach Resource Characteristics and Development Model in Bohai Rim. Progress in Geography, 2005,21(1):25-34.]
[14]	Campbell M L, Hewitt C L.A hierarchical framework to aid biodiversity assessment for coastal zone management and marine protected area selection[J]. Ocean＆Coastal Management, 2006, 49:133-146. doi: 10.1016/j.ocecoaman.2006.02.010
[15]	Bertollo P.Assessing ecosystem health in governed landscapes: A framework for developing core indicators[J]. Ecosystem Health, 1998, 4:33-51.
[16]	Martinez M L,Gallego-Fernandez J B, Garcia-Franco J G et al. Assessment of coastal dune vulnerability to natural and anthropogenic disturbances along the Gulf of Mexico[J]. Environmental Conservation, 2006, 33:109-117. doi: 10.1017/S0376892906002876
[17]	Stojanovic T A, Ballinger R C.Integrated coastal management: A comparative analysis of four UK initiatives[J]. Applied Geography, 2009, 29:49-62. doi: 10.1016/j.apgeog.2008.07.005
[18]	Arheimer B, Torstensson G, Wittgren H B.Landscape planning to reduce coastal eutrophication: agricultural practices and constructed wetlands[J]. Landscape and Urban Planning, 2004, 67: 205-215. doi: 10.1016/S0169-2046(03)00040-9
[19]	Christensen S M, Tarp P, Hjortso C N.Mangrove forest management planning in coastal buffer and conservation zones, Vietnam: A multi-method logical approach incorporating multiple stakeholders[J]. Ocean＆ Coastal Management, 2008, 51: 712-726. doi: 10.1016/j.ocecoaman.2008.06.014
[20]	Ma Z J, Li B,Li W J et al. Conflicts between biodiversity conservation and development in a biosphere reserve[J]. Journal of Applied Ecology, 2009, 46:527-535.
[21]	王颖. 充分利用天然潮流通道建设江苏洋口深水港临海工业基地[J].水资源保护,2003,19(6):1-4. doi: 10.3969/j.issn.1004-6933.2003.06.001
	[Wang Ying.Full use of natural tidal channel for construction of Yangkou deep-water port and industrial base along Jiangsu coast. Water Resources Protection, 2003,19(6): 1-4.] doi: 10.3969/j.issn.1004-6933.2003.06.001
[22]	郭焕成,孙艺惠,任国柱,等. 北京休闲农业与乡村旅游发展研究[J]. 地球信息科学, 2008,10(4):453-461. doi: 10.3969/j.issn.1560-8999.2008.04.008
	[Guo Huancheng, Sun Yihui,Ren Guozhu et al.Study on the Development of Leisure Agriculture and Rural Tourism in Beijing. Geo-information Science, 2008,10(4):453-461.] doi: 10.3969/j.issn.1560-8999.2008.04.008
[23]	张结魁. 区域旅游资源评价体系构想与实证研究[J]. 资源科学,2003,25(3):90-97.
	[Zhang Jiekui.Assessment System of Regional Tourism Resources: A case of Xi pan City. Resources Science, 2003,25(3):90-97.]
[24]	曾涛,邸雪颖,杨光,等. 湖泊湿地生态旅游资源评价——以兴凯湖国家级自然保护区为例[J]. 东北林业大学学报,2010,38(5) :110-113. doi: 10.3969/j.issn.1000-5382.2010.05.033
	[Zeng Tao, Di Xueying,Yang Guang et al.Evaluation on Eco-tourism Resources in Lake Wetlands: A Case Study in Xingkai Lake National Nature Reserve.Journal of Northeast Forestry University, 2010,38(5) :110-113.] doi: 10.3969/j.issn.1000-5382.2010.05.033
[25]	王进欣,黄巧华,李超, 等. 苏北海岸带盐沼生态系统对二氯苯的自然吸收通量特征[J].地理科学,2014,34(4):491-497.
	[Wang Jinxin, Huang Qiaohua,Li Chao et al.The characteristics of fluxes of natural removal of dichlorobenzene from atmosphere in a coastal salt marsh of northern Jiangsu.Scientia Geographic Sinica, 2014, 34(4): 491-497.]
[26]	李蓉蓉,王学雷. 基于GIS的江汉平原湖区农业用地适宜性评价[J]. 华中师范大学学报(自然科学版), 2000,34(2):237-240. doi: 10.3321/j.issn:1000-1190.2000.02.031
	[Li Rongrong, Wang Xuelei.Study on the GIS-based agricultural land suitability evaluation in Jianghan plain-lake district.Journal of Central China Normal University, 2000,34(2):237-240.] doi: 10.3321/j.issn:1000-1190.2000.02.031
[27]	唐秀美,陈百明,路庆斌. 栅格数据支持下的耕地适宜性评价研究——以山东省章丘市为例[J]. 资源科学,2009,31(12):2164-2171.
	[Tang Xiumei,Chen Baiming,Lu Qingbin et al.Cultivated Land Suitability Evaluation Based on Raster Data:A Case Study on Zhang qiu City of Shandong Province.Resources Science,2009,31(12):2164-2171.]
[28]	陈诚. 沿海岸线综合适宜性评价[J]. 资源科学,2013,35(5):950-957.
	[Chen Cheng.Coastline Resources Evaluation of Coastal Ningbo City.Resources Science,2013,35(5):950-957.]
[29]	孙伟,陈诚. 海岸带的空间功能分区与管制方法——以宁波市为例[J]. 地理研究,2013,32(10):1878-1889. doi: 10.11821/dlyj201310011
	[Sun Wei, Chen Cheng.Spatial function regionalization and spatial governance of the coastal zone: A case study in Ningbo City.Geographical Research, 2013,32(10):1878-1889.] doi: 10.11821/dlyj201310011
[30]	王静静,刘敏,权瑞松, 等. 沿海港口自然灾害风险评价[J].地理科学,2012,32(4):516-520.
	[Wang Jingjing, Liu Min,Quan Ruisong et al. Natural disaster risk assessment of coastal ports in China. Scientia Geographic Sinica, 2012, 32(4): 516-520.]
[31]	中国国家标准化管理委员会.农用地质量分等规程:GB/T28407-2012[S]. 北京:中国标准出版社, 2012.
	[Standardization Administration of the People’s Republic of China. Regulation for gradation on agriculture land quality: GB/T28407-2012. Beijing: Standards Press of China, 2012.]

类型	指标	因子	农业生产	（权重）	旅游与生态保护	（权重）	港-工-城开发	（权重）
资源条件	土地质量	pH值	√	（0.1804）
	土地质量	有机质含量	√	（0.1823）
	淡水保障	清水通道邻近性	√	（0.2867）			√	（0.1875）
	岸线条件	岸前水深					√	（0.2245）
		掩护条件					√
		潮差					√
	景观资源条件	景观邻近性			√	（0.3852）
生态环境	生态重要性	生态重要性	√	（0.3506）	√	（0.4045）	√	（0.1457）
生态环境	环境容量	水质目标			√	（0.2103）	√	（0.1967）
区位	交通优势度	交通可达性					√	（0.2456）
