轨道交通站域的城市物质空间更新轨迹与组织模式——以北京为例

doi:10.13249/j.cnki.sgs.2017.06.002

摘要/Abstract

摘要：

以居住为导向的北部回龙观区域和产业导向的南部亦庄为区域,以时间剖面遥感影像图为基础,综合运用土地利用数据、实地调查与深度访谈等多种方法,判别、回顾并解译物质空间的基本变化过程,凝练物质空间的演替规律与组织模式,以期为制定科学合理的交通基础设施建设和城市综合开发方案提供支撑。研究发现：① 居住导向的物质空间组织模式,以站域内居住空间持续扩大、居民数量不断增多为特征,伴随着城乡景观和生活方式的角逐。同时,却往往忽视了产业空间与公共服务设施空间配套建设,加之高密度的人口集聚,大大降低了居住舒适度。② 产业导向的物质空间组织模式以站域内产业空间持续扩大、企业数量不断增多、配套基础设施逐步完善为特征。但居住空间与公共服务设施空间建设的时滞性显著,造成了人气不足、土地利用效益低下。③ 建立和完善轨道交通站域的物质空间组织模式知识库,将为交通导向下的基础设施建设和城市综合开发方案提供科学依据。

关键词: 北京, 轨道交通, 物质空间, 组织模式, 区域差异

Abstract:

Based on the integrated use of the land use data, remote sensing image, field survey and in-depth interviews, this article interprets the physical space change process and organization model of the northern Huilongguan area and the southern Yizhuang area in order to formulate a scientific urban development plan. 1) Living function oriented physical space is characterized by living space expanding and the number of residents increasing, along with the competition between urban and rural landscape as well as life-style. At the same time, industrial space and public service facilities are always ignored to construct, coupled with a high density of population agglomeration, which greatly leads to reduce the living comfort. 2) Industry function oriented physical space is characterized by the industrial space expanding, number of enterprises increasing and infrastructure improving. However, there is a temporal hysteresis in the construction of residential space and public service facilities, which causes the lack of popularity and poor benefit of the land use. 3) To establish and improve the organization model of the physical space so as to provide the scientific basis for traffic infrastructure construction and urban comprehensive development plan.

Key words: Beijing, rail transportation, physical space, organization pattern, regional differences

中图分类号:

K901

邓羽. 轨道交通站域的城市物质空间更新轨迹与组织模式——以北京为例[J]. 地理科学, 2017, 37(6): 817-824.

Yu Deng. The Spatial Succession and Organization Model of the Urban Material Space Within the Rail Transit Station: A Case in Beijing[J]. SCIENTIA GEOGRAPHICA SINICA, 2017, 37(6): 817-824.

图/表 5

图1

表1

图2

图3

图4

参考文献 23

[1]	柴彦威,刘志林,李峥嵘,等. 中国城市的时空间结构[M]. 北京: 北京大学出版社, 2002.
	[Chai Yanwei, Liu Zhilin, Li zhengrong et al. Time-space Structure of Chinese Cities. Beijing: Peking University Press, 2002.]
[2]	马学广,王爱民,闫小培. 城市空间重构进程中的土地利用冲突研究——以广州市为例[J].人文地理,2010,25(3):71-77.
	[Ma Xueguang, Wang Aimin, Yan Xiaopei.A study on land use conflicts in the urban spatial reconstruction process. Human Geography,2010,25(3):71-77.]
[3]	邓羽. 北京市土地出让价格的空间格局与竞租规律探讨[J].自然资源学报,2015,30(2):218-226. doi: 10.11849/zrzyxb.2015.02.005
	[Deng Yu.Spatial pattern and bid rent of land price in Beijing. Journal of Natural Resources, 2015, 30(2):218-226.] doi: 10.11849/zrzyxb.2015.02.005
[4]	罗彦,周春山.中国城市的商业郊区化及研究迟缓发展探讨[J].人文地理,2004,19(6): 40-45. doi: 10.3969/j.issn.1003-2398.2004.06.009
	[Luo Yan, Zhou Chunshan.The analysis on the commerce suburbanization and research tardy development in Chinese. Human Geography,2004,19(6):40-45.] doi: 10.3969/j.issn.1003-2398.2004.06.009
[5]	周春山,陈素素,罗彦.广州市建成区住房空间结构及其成因[J].地理研究,2005,24(1):78-90. doi: 10.3321/j.issn:1000-0585.2005.01.009
	[Zhou Chunshan, Chen Susu, Luo Yan.The housing spatial structures in Guangzhou urban built-up area and their causes’analysis. Geographical Research, 2005, 24(1):78-90.] doi: 10.3321/j.issn:1000-0585.2005.01.009
[6]	冯健, 刘玉. 转型期中国城市内部空间重构:特征、模式与机制[J]. 地理科学进展, 2007, 26(4): 93-106. doi: 10.3969/j.issn.1007-6301.2007.04.010
	[Feng Jian, Liu Yu.Restructuring of urban internal space in China in the transition period: Characteristics, models and mechanisms. Progress in Geography, 2007, 26(4): 93-106.] doi: 10.3969/j.issn.1007-6301.2007.04.010
[7]	张晓平, 孙磊. 北京市制造业空间格局演化及影响因子分析[J]. 地理学报, 2012, 67(10): 1308-1316. doi: 10.11821/xb201210002
	[Zhang Xiaoping, Sun Lei.Manufacture restructuring and main determinants in Beijing Metropolitan Area. Acta Geographica Sinica, 2012, 67(10): 1308-1316.] doi: 10.11821/xb201210002
[8]	杨浩,张京祥. 城市开发区空间转型背景下的更新规划探索[J].规划师,2013,29(1):29-34. doi: 10.3969/j.issn.1006-0022.2013.01.006
	[Yang hao, Zhang Jingxiang. Development Zone Regeneration Planning With Spatial Transition. Planners,2013,29(1):29-34.] doi: 10.3969/j.issn.1006-0022.2013.01.006
[9]	周一星. 北京的郊区化及引发的思考[J].地理科学,1996,16(3):198-206.
	[Zhou Yixing.On the suburbanization of Beijing. Scientia Geographica Sinica, 1996, 16(3):198-206.]
[10]	李志刚, 刘晔, 陈宏胜. 中国城市新移民的“乡缘社区”: 特征、机制与空间性: 以广州“湖北村”为例[J]. 地理研究, 2011, 30(10): 1910-1920. doi: 10.11821/yj2011100017
	[Li Zhigang, Liu Ye, Chen Hongsheng.Characteristics, mechanism, and spatiality of neo-migrants' homeplace-based communities in China: A case study of Hubei village, Gruangzhou. Geographical Research, 2011, 30(10): 1910-1920.] doi: 10.11821/yj2011100017
[11]	周素红, 程璐萍, 吴志东, 等. 广州市保障性住房社区居民的居住——就业选择与空间匹配性[J]. 地理研究, 2010, 29(10): 1735-1743. doi: 10.11821/yj2010100002
	[Zhou Suhong, Chen Luping, Wu Zhidong et al. The job-housing relocation and spatial matching of residents in alleviatory housing neighborhoods in Guangzhou. Geographical Research, 2010, 29(10): 1735-1743.] doi: 10.11821/yj2010100002
[12]	张京祥,胡毅,孙东琪. 空间生产视角下的城中村物质空间与社会变迁——南京市江东村的实证研究[J].人文地理,2014,12(2):1-6.
	[Zhang Jingxiang, Hu Yi, Sun Dongqi.The physical space change and social variation on urban village from the perspective of production: A case study of Jiangdong village in Nanjing. Human Geography, 2014, 29(2):1-6.]
[13]	Huu P H, Wakely P.Status, quality and the other trade-off: Towards a new theory of urban residential location. Urban Studies, 2000, 37(1): 7-35. doi: 10.1080/0042098002276
[14]	沈体雁, 冯等田, 李迅,等. 北京地区交通对城市空间扩展的影响研究. 城市发展研究, 2009, (6):29-32. doi: 10.3969/j.issn.1006-3862.2008.06.006
	[Shen Tiyan, Feng Dengtian, Li Xun et al. The influence of transportation on the urban spatial expansion in Beijing. Urban Studies, 2009, (6):29-32.] doi: 10.3969/j.issn.1006-3862.2008.06.006
[15]	邓羽,司月芳. 北京市城区扩展的空间格局与影响因素[J].地理研究,2015,34(12): 2247-2256. doi: 10.11821/dlyj201512004
	[Deng Yu, Si Yuefang.The spatial pattern and influence factors of urban expansion: A case study of Beijing. Geographical Research, 2015, 34(12): 2247-2256.] doi: 10.11821/dlyj201512004
[16]	Knight R L.Land use impacts of rapid transit systems: implications of recent experience[M]. Washington DC: The US Department of Transportation, 1977.
[17]	Nelson A C, Sanchez T L.The influence of MARTA on population and employment location[M]//Presented at the 76th Annual Meeting of The Transportation Research Board. Washington DC: National Research Council, 1997.
[18]	刘保奎,冯长春. 城市轨道交通对站点周边土地利用结构的影响[J]. 城市发展研究,2009,16(4): 149-155. doi: 10.3969/j.issn.1006-3862.2009.04.023
	[ Liu Baokui, Feng Changchun.Research of Impact of Urban Railway Transportation on Land Use Structure Based on GIS and Information Entropy. Urban Studies , 2009, 16(4): 149-155.] doi: 10.3969/j.issn.1006-3862.2009.04.023
[19]	周素红, 闫小培. 城市居住-就业空间特征及组织模式: 以广州市为例[J]. 地理科学, 2005, 25(6): 664-670. doi: 10.3969/j.issn.1000-0690.2005.06.003
	[Zhou Suhong, Yan Xiaopei.Characteristics of Jobs-housing and organization in Guangzhou. Scientia Geographica Sinica, 2005, 25(6): 664-670.] doi: 10.3969/j.issn.1000-0690.2005.06.003
[20]	邓羽. 综合交通可达性视角下的城市空间结构化研究[M].北京:中国建筑工业出版社,2016.
	[Dengyu.Optimization of Urban Spatial Organization from the Perspective of Comprehensive Dengyu.Transportation Accessibility——A Case Study of Beijing.Beijing:China Architecture & Building Press,2016.]
[21]	柯文前,陆玉麒,朱宇,等.交通流网络的时空特征解析——基于张量分解方法视角[J]. 地理科学,2016,36(11): 1679-1687.
	[Ke Wenqian, Lu Yuqi, Zhu Yu et al. Traffic Flow Network Spatio-temporal Characteristics Analysis: Basis on the Tensor Decomposition Method Perspective. Scientia Geographica Sinica, 2016,36(11): 1679-1687.]
[22]	王丽,曹有挥,仇方道.高铁开通前后站区产业空间格局变动及驱动机制——以沪宁城际南京站为例[J]. 地理科学,2017,37(1): 19-27.
	[Wang Li, Cao Youhui, Qiu Fangdao.Spatial Change and Driving Mechanism of the Industry in Regions of HSR Stations Before and After the Opening: A Case Study of Nanjing HSR Station. Scientia Geographica Sinica, ,2017,37(1): 19-27.]
[23]	陈忠暖,刘松,王帅.城市常规公交空间演化过程研究——以广州市为例[J]. 地理科学,2017,37(1): 55-63.
	[Chen Zhongnuan, Liu Song, Wang Shuai.Spatial Evolution Features of Transit Bus: An Empirical Study of Guangzhou. Scientia Geographica Sinica,2017,37(1): 55-63.]

物质空间类型	亦庄万源街站					回龙观龙泽站
物质空间类型	2002年		2004年	2006年	2010年	2003年	2006年	2008年	2010年
农用地	-	-	-	-		0.03	0	0	0
农村居民点	-	-	-	-		0.31	0.31	0.31	0
公共服务设施	-	-	-	-		0.05	0.05	0.04	0.02
空闲地	0.38	0.31	0.26	0.04		0.09	0.13	0	0.42
绿地	0.2	0.22	0.25	0.31		0.09	0.09	0.09	0.09
城市住宅	0.1	0.13	0.14	0.16		0.19	0.20	0.32	0.32
道路	0.26	0.26	0.26	0.26		0.39	0.39	0.39	0.37
临时性住宅	-	-	-	-		-	-	-	-
产业用地	0.58	0.58	0.6	0.74		0.17	0.16	0.16	0.11
特殊用地	-	-	-	-		-	-	-	-
