近35年三北防护林体系建设工程的防风固沙效应

doi:10.13249/j.cnki.sgs.2018.04.014

地理科学 ›› 2018, Vol. 38 ›› Issue (4): 600-609.doi: 10.13249/j.cnki.sgs.2018.04.014

近35年三北防护林体系建设工程的防风固沙效应

黄麟¹(), 祝萍^1,², 肖桐³, 曹巍¹, 巩国丽⁴

1. 中国科学院地理科学与资源研究所/陆地表层格局与模拟重点实验室,北京 100101
2. 中国科学院大学,北京100049
3.环境保护部卫星环境应用中心,北京 100094
4.山西省环境规划院,山西太原 030024

收稿日期:2017-03-23 修回日期:2017-05-21 出版日期:2018-04-20 发布日期:2018-04-20
作者简介:
作者简介：黄麟(1981-),女,四川宜宾人,副研究员,博士,主要从事土地利用变化及其生态效应研究。E-mail: huanglin@igsnrr.ac.cn
基金资助:
国家重点研发计划项目(2017YFC0506500)、中国科学院前沿科学重点研究项目(QYZDB-SSW-DQC005)资助

The Sand Fixation Effects of Three-North Shelter Forest Program in Recent 35 Years

Lin Huang¹(), Ping Zhu^1,², Tong Xiao³, Wei Cao¹, Guoli Gong⁴

1. Key Laboratory of Land Surface Pattern and Simulation, Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. Satellite Environment Center, Ministry of Environmental Protection, Beijing 100094, China
4. Shanxi Academy of Environmental Planning, Taiyuan 030024, Shanxi, China

Received:2017-03-23 Revised:2017-05-21 Online:2018-04-20 Published:2018-04-20
Supported by:
[National Key Research and Development Program of China (2017YFC0506500), Key Research Program of Frontier Sciences of CAS (QYZDB-SSW-DQC005).]

摘要/Abstract

摘要：

通过分析三北工程区生态系统防风固沙服务量变化,进而评价工程的防风固沙效应。结果表明：① 近35 a,三北工程区林地面积持续增加、草地面积持续减少,特别是半干旱风沙区和黄土高原区。植被覆盖度在前20 a持续增加,近15 a则呈现先下降而后略微增加趋势。②土壤风蚀模数持续减少,近15 a减幅远高于前20 a,沙地、草地、其它类型转林地或转草地区域的减幅尤为明显。生态系统防风固沙服务保有率呈上升态势,干旱荒漠区增幅显著。草地和沙地为工程区生态系统防风固沙服务总量贡献了71%,且转草地区域的贡献高于转林地区域。③ 考虑到植被好转同时受气候变化和人类活动的影响,以风场减弱为主的气候变化导致土壤风蚀力减弱与三北防护林等生态工程对生态系统防风固沙服务变化的贡献率分别介于85%~89%和11%~15%之间。

关键词: 三北防护林体系建设工程, 林地、草地面积变化, 植被覆盖度, 防风固沙

Abstract:

In order to understand the windbreak and sand fixation effects of the Three-North Shelter Forest Program (TNSFP) in recent 35 years, this paper analyzes the amount change of ecosystem sand fixation caused by climate change and vegetation degradation or restoration in the project region, and then assesses the sand fixation effects of the Program. Based on Landsat MSS, TM/ETM+, and environmental satellite (HJ) images, the spatial-temporal datasets of land cover changes in the project region of TNSFP were analyzed in the periods of mid 1970s, 1990, 2000, 2010, 2015, especially the forest and grassland. Combining the NDVI data of AVHRR and MODIS, the vegetation coverage was estimated, and then the change of vegetation coverage in the 1982-2015 was analyzed. The soil erosion modulus were estimated at the regional scale by applying the soil erosion equation (RWEQ), and then the ecosystem services of windbreak and sand fixation were assessed using indicators of amount and retention rate of windbreak and sand fixation. Then the contribution rate of ecological program and climate change to regional ecosystem change was determined by comparing the indexes under the conditions of average climate and real climate. The results showed that: 1) In the past 35 years, the area of forest was continuously increased and grassland was decreased, especially in the semi-arid sandy area and Loess Plateau. The vegetation coverage increased continuously in the before 20 years, and then decreased in recent 15 years. 2) The soil wind erosion modulus is decreased continuously, and the decreasing rate in recent 15 years is much higher than that in the before 20 years. The decreasing rates were especially obvious in sandy land, grassland, and regions planting trees and grassland. The retention ratio of ecosystem windbreak and sand fixation service also increased continuously, especially in arid desert area. Grassland and sandy land contributed 71% of the total amount of windbreak and sand fixation. However, just 6.6% of forest land, and the contribution of conversion grassland was higher than that of conversion forest. 3) In the TNSFP, the weakening of wind erosion force due to reducing wind, and the vegetation restoration in local areas due to TNSFP and other ecological programs, both resulted in a decrease of soil wind erosion, and accounted for 85%-89% and 11%-15% of the decrease. Winter monsoon in mid-latitude Asian is weakened due to global warming. In the project region of TNSFP, the grassland played the most important role in ecosystem service of windbreak and sand fixation, which accounts for more than 63% of the total area. Therefore, the conservation of grassland and sandy land were significant in project region of TNSFP. Project planning and implementation should focus on the transfer of funds from afforestation to grassland conservation and restoration.

Key words: the Three-North Shelter Forest Program, forest and grassland area change, vegetation coverage, windbreak and sand fixation effects

中图分类号:

K903

黄麟, 祝萍, 肖桐, 曹巍, 巩国丽. 近35年三北防护林体系建设工程的防风固沙效应[J]. 地理科学, 2018, 38(4): 600-609.

Lin Huang, Ping Zhu, Tong Xiao, Wei Cao, Guoli Gong. The Sand Fixation Effects of Three-North Shelter Forest Program in Recent 35 Years[J]. SCIENTIA GEOGRAPHICA SINICA, 2018, 38(4): 600-609.

图/表 7

图1

图2

图3

表1

图4

图5

表2

参考文献 35

[1]	王涛. 我国沙漠化研究的若干问题——3.沙漠化研究和防治的重点区域[J].中国沙漠,2004,24(1):1-9. doi: 10.3321/j.issn:1000-694X.2004.01.001
	[Wang Tao. Study on sandy desertification in China—3. Key regions for studying and combating sandy desertification. Journal of Desert Research, 2004, 24(1):1-9.] doi: 10.3321/j.issn:1000-694X.2004.01.001
[2]	马柱国. 我国北方干湿演变规律及其与区域增暖的可能联系[J]. 地球物理学报,2005,48(5):1011-1018. doi: 10.3321/j.issn:0001-5733.2005.05.006
	[Ma Zhuguo. Dry/wet variation and its relationship with regional warming in arid-regions of northern China. Chinese Journal of Geophysics, 2005, 48(5):1011-1018.] doi: 10.3321/j.issn:0001-5733.2005.05.006
[3]	董光荣, 靳鹤龄, 陈惠忠,等. 中国北方半干旱和半湿润地区沙漠化的成因[J].第四纪研究,1998,18(2):136-144.
	[Dong Guangrong, Jin Heling, Chen Huizhong et al. Geneses of desertification in semiarid and subhumid regions of Northern China. Quaternary Sciences, 1998, 18(2): 136-144.]
[4]	王训明, 李吉均, 董光荣, 等. 近50a来中国北方沙区风沙气候演变与沙漠化响应[J]. 科学通报, 2007, 52(24): 2882-2888.
	[Wang Xunming, Li Jijun, Dong Guangrong et al. Climatic evolution and desertification response of sandstorm in the sandy area of Northern China in recent 50 years. Chinese Science Bulletin, 2007, 52(24): 2882-2888.]
[5]	叶笃正, 丑纪范, 刘纪远, 等. 关于我国华北沙尘天气的成因与治理对策[J]. 地球科学进展, 2000, 15(4): 513-521. doi: 10.3321/j.issn:1001-8166.2000.04.001
	[Ye Duzheng, Chou Jifan, Liu Jiyuan et al. Causes and countermeasures of dust weather in North China. Advances in Earth Science, 2000, 15(4): 513-521.] doi: 10.3321/j.issn:1001-8166.2000.04.001
[6]	全林生, 时少英, 朱亚芬, 等. 中国沙尘天气变化的时空特征及其气候原因[J]. 地理学报, 2001, 56(4): 477-485. doi: 10.1142/S0252959901000401
	[Quan Linsheng, Shi Shaoying, Zhu Yafen et al. Temporal-Spatial Distribution Characteristics and Causes of Dust-day in China. Acta Geographica Sinica, 2001, 56(4): 477-485.] doi: 10.1142/S0252959901000401
[7]	邱新法, 曾燕. 我国沙尘暴的时空分布规律及其源地和移动路径[J]. 地理学报, 2001, 56(3): 316-322. doi: 10.3321/j.issn:0375-5444.2001.03.008
	[Qiu Xinfa, Zeng Yan. Temporal-spatial distribution as well as tracks and source areas of sand-dust storms in China. Acta Geographica Sinica, 2001, 56(3): 316-322.] doi: 10.3321/j.issn:0375-5444.2001.03.008
[8]	国家林业局西北华北东北防护林建设局. 中国三北防护林体系建设总体规划方案[M]. 银川:宁夏人民出版社, 1993.
	[Shelterbelt Construction Bureau in Northwest, North and Northeast China. Main Plan for the Construction of the Three-North Shelterbelt System in China. Yinchuan: Ningxia People’s Publishing House. 1993]
[9]	国家林业局. 三北防护林体系建设30年发展报告(1978-2008)[M]. 北京:中国林业出版社, 2008.
	[State Forestry Administration of the People’s Republic of China. Development report of the Three-North Shelter Forest System in the Past 30 Years (1978-2008). Beijing: China Forestry Publishing House, 2008.]
[10]	江滢, 罗勇, 赵宗慈等. 近50年中国风速变化及原因分析[C]. 广州:中国气象学会2007年年会气候变化分会场论文集, 2007: 80-89.
	[Jiang Ying, Luo Yong, Zhao Zongci et al. Analysis on the change of wind speed in China in recent 50 years. Guangzhou: 2007 Annual Meeting Climate Change Session of Chinese Meteorological Society 2007: 80-89.]
[11]	布和朝鲁. 东亚季风气候未来变化的情景分析——基于IPCC SRES A2和B2方案的模拟结果[J]. 科学通报, 2003, 48(7): 737-742.
	[Buhe Chaolu. Scenario analysis of future changes of east Asian monsoon climate——Simulation results based on IPCC SRES A2 and B2 schemes. Chinese Science Bulletin, 2003, 48(7): 737-742.]
[12]	吴云, 曾源, 吴炳方, 等. 基于MODIS数据的三北防护林工程区植被覆盖度提取与分析[J]. 生态学杂志, 2009, 28(9): 1712-1718.
	[Wu Yun, Zeng Yuan, Wu Bingfang et al. Retrieval and analysis of vegetation cover in the Three-North Regions of China based on MODIS data. Chinese Journal of Ecology, 2009, 28(9): 1712-1718.]
[13]	黄麟, 曹巍, 巩国丽,等. 2000-2010年中国三北地区生态系统时空变化特征[J]. 生态学报, 2016, 36(1): 107-117.
	[Huang Lin, Cao Wei, Gong Guoli et al. Spatial and temporal variations in ecosystems in the three northern regions of China, 2000-2010. Acta Ecologica Sinica, 2016, 36(1): 107-117.]
[14]	Torita H, Satou H. Relationship between shelterbelt structure and mean wind reduction[J]. Agricultural & Forest Meteorology, 2007, 145(3-4): 186-194. doi: 10.1016/j.agrformet.2007.04.018
[15]	Ryszkowski L, Kędziora A. Modification of water flows and nitrogen fluxes by shelterbelts[J]. Ecological Engineering, 2007, 29(4): 388-400. doi: 10.1016/j.ecoleng.2006.09.023
[16]	代力民, 王宪礼, 王金锡. 三北防护林生态效益评价要素分析[J]. 世界林业研究, 2000, 2: 47-51. doi: 10.3969/j.issn.1001-4241.2000.02.013
	[Dai Limin, Wang Xianli, Wang Jinxi. Indicators to assess the ecological effect of the 3-north windbread system. World Forestry Research, 2000, 2: 47-51.] doi: 10.3969/j.issn.1001-4241.2000.02.013
[17]	姜凤岐, 于占源, 曾德慧. 气候变化对三北防护林的影响与应对策略[J]. 生态学杂志,2009, 9: 1702-1705.
	[Jiang Fengqi, Yu Zhanyuan, Zeng Dehui. Effects of climate change on the Three-north Shelter Forest Program and corresponding strategies. Chinese Journal of Ecology, 2009, 9: 1702-1705.]
[18]	朱金兆, 周心澄, 胡建忠. 对“三北”防护林体系工程的思考与展望[J]. 自然资源学报, 2004, 1: 79-85. doi: 10.11849/zrzyxb.2004.01.010
	[Zhu Jinzhao, Zhou Xincheng, Hu Jianzhong. Thoughts and views about the three north shelterbelt program. Journal of Natural Resources, 2004, 1: 79-85.] doi: 10.11849/zrzyxb.2004.01.010
[19]	龚维, 李俊, 何宇, 等. 发展林业碳汇推动三北防护林体系建设[J]. 生态学杂志, 2009, 28(9): 1691-1695.
	[Gong Wei, Li Jun, He Yu et al. Developing forestry carbon sinks to promote the construction of the Three-North Shelter Forest Program. Chinese Journal of Ecology, 2009, 28(9): 1691-1695.]
[20]	张林, 王礼茂. 三北防护林体系森林碳密度及碳贮量动态[J]. 干旱区资源与环境, 2010, 24(8): 136-140.
	[Zhang Lin, Wang Limao. Dynamic forest carbon density and storage in the "Three North" protective forest system. Journal of Arid Land Resources and Environment, 2010, 24(8): 136-140.]
[21]	陈云明, 梁一民, 程积民. 黄土高原林草植被建设的地带性特征[J]. 植物生态学报, 2002, 26(3): 339-345.
	[Chen Yunming, Liang Yimin, Cheng Jimin. The zonal character of vegetation construction on Loess Plateau. Acta Phytoecologica Sinica, 2002, 26(3): 339-345.]
[22]	侯庆春, 黄旭. 黄土高原地区小老树成因及其改造途径的研究—Ⅱ土壤水分和养分状况及其与小老树生长的关系[J]. 水土保持学报, 1991, 4: 64-72.
	[Hou Qingchun, Huang Xu. Study on the genesis and transformation path of the small old tree in the Loess Plateau—Ⅱ Soil moisture and nutrient status and its relationship with the growth of the old tree. Journal of Soil and Water Conservation, 1991, 4: 64-72.
[23]	宋立宁, 朱教君, 闫巧玲. 防护林衰退研究进展[J]. 生态学杂志, 2009, 28(9): 1684-1690.
	[Song Lining, Zhu Jiaojun, Yan Qiaoling. Review on the shelter forest decline. Chinese Journal of Ecology, 2009, 28(9): 1684-1690.]
[24]	刘纪远, 匡文慧, 张增祥, 等. 20世纪80年代末以来中国土地利用变化的基本特征与空间格局[J]. 地理学报, 2014, 69(1): 3-14. doi: 10.1007/s11442-014-1082-6
	[Liu Jiyuan, Kuang Wenhui, Zhang Zengxiang et al. Spatiotemporal characteristics, patterns and causes of land use changes in China since the late 1980s. Acta Geographica Sinica, 2014, 69(1): 3-14.] doi: 10.1007/s11442-014-1082-6
[25]	Fryrear D W, Saleh A, Bilbro J D et al. Revised Wind Erosion Equation (RWEQ) [R]. Wind Erosion and water conservation research unit, USDA-ARS. Southern Plains Area Cropping Systems Research Laboratory, Technical Bulletin 1,1998.
[26]	巩国丽. 中国北方土壤风力侵蚀研究[D]. 北京:中国科学院地理科学与资源研究所,2014.
	[Gong Guoli. Study on soil wind erosion in Northern China. Beijing: Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences,2014.]
[27]	郭中领. RWEQ模型参数修订及其在中国北方应用研究[D]. 北京:北京师范大学,2012.
	[Guo Zhongling. Revision on model parameters of RWEQ and its application in Northern China. Beijing: Beijing Normal University, 2012.]
[28]	刘纪远, 齐永青, 师华定, 等. 蒙古高原塔里亚特-锡林郭勒样带土壤风蚀速率的137Cs示踪分析[J]. 科学通报, 2007, 52(23): 2785-2791. doi: 10.1360/csb2007-52-23-2785
	[Liu Jiyuan, Qi Yongqing, Shi Huading et al. Estimation of wind erosion rates by using 137Cs tracing technique: A case study in Tariat-Xilin Gol transect, Mongolian Plateau. Chinese Science Bulletin, 2007, 52(23): 2785-2791.] doi: 10.1360/csb2007-52-23-2785
[29]	王云超, 张立峰, 侯大山, 等. 河北坝上农牧交错区不同下垫面土壤风蚀特征研究[J]. 中国农学通报, 2006, 22(8): 565-568. doi: 10.3969/j.issn.1000-6850.2006.08.138
	[Wang Yunchao, Zhang Lifeng, Hou Dashan et al. Study on soil wind erosion of different underlying in ecotone between agriculture and animal husbandry in Bashang of Hebei. Chinese Agricultural Science Bulletin, 2006, 22(8): 565-568.] doi: 10.3969/j.issn.1000-6850.2006.08.138
[30]	严平, 董光荣, 张信宝, 等. 137Cs法测定青藏高原土壤风蚀的初步结果[J]. 科学通报, 2000, 45(2): 199-204. doi: 10.3321/j.issn:0023-074X.2000.02.018
	[Yan Ping, Dong Guangrong, Zhang Xinbao et al. Preliminary results of the study on wind erosion in the Qinghai-Tibetan Plateau using 137Cs technique. Chinese Science Bulletin, 2000, 45(2): 199-204.] doi: 10.3321/j.issn:0023-074X.2000.02.018
[31]	郑兵, 吕伟, 姚洪林,等. 浑善达克沙地南缘风蚀量的研究[J]. 干旱区资源与环境, 2010, 24(6): 112-117.
	[Zheng Bing, Lv Wei, Yao Honglin et al. The wind erosion characteristics of south region of Hunshandake sandland. Journal of Arid Land Resources and Environment, 2010, 24(6): 112-117.]
[32]	Fu G B, Yu J J, Zhang Y C et al. Temporal variation of wind speed in China for 1961-2007[J]. Theoretical and Applied Climatology, 2011, 104: 313-324. doi: 10.1007/s00704-010-0348-x
[33]	Jiang Y, Luo Y, Zhao Z C et al. Changes in wind speed over China during 1956-2004[J]. Theoretical and Applied Climatology, 2010, 99: 421-430.
[34]	赵宗慈, 罗勇, 江滢. 全球大风在减少吗?[J]. 气候变化研究进展, 2011, 7(2): 149-151. doi: 10.3969/j.issn.1673-1719.2011.02.012
	[Zhao Zongci, Luo Yong, Jiang Ying. Is global Strong Wind Declining? Advances in Climate Change Research, 2011, 7(2): 149-151.] doi: 10.3969/j.issn.1673-1719.2011.02.012
[35]	陈练. 气候变暧背景下中国风速(能)变化及其影响因子研究[D]. 南京:南京信息工程大学, 2013:49-80.
	[Chen Lian. Study on the change of wind speed and its influencing factors in China under the background of climate warming. Nanjing: Nanjing University of Information Science & Technology, 2013:49-80.]

统计单元	土壤风蚀模数变化[t/（hm²·a）]				防风固沙服务量变化[t/（hm²·a）]			防风固沙服务保有率变化（%/a）
统计单元	Ⅰ	Ⅱ	Ⅲ	Ⅳ	Ⅱ	Ⅲ	Ⅳ	Ⅱ	Ⅲ	Ⅳ
林地	-0.52	-0.35	-0.16	1.82	-1.99	-3.08	1.95	0.32	-0.03	0.17
草地	-2.31	-0.48	-0.95	-0.96	-1.82	-2.56	-0.18	0.07	0.05	0.40
沙地	-21.46	-0.41	-4.48	-8.54	-2.02	-3.73	-4.72	-0.58	0.06	-0.28
耕地	-0.86	-0.62	-0.46	-0.35	-0.36	-2.67	-0.10	0.82	0.05	0.56
其它类型转林地		-0.42	-0.52	-2.13	-1.29	-1.64	-1.13	0.42	0.52	0.15
其它类型转草地		-0.51	-1.46	-3.61	-1.29	-3.60	-3.61	0.24	0.48	0.56
半湿润区	-0.50	-0.39	-0.20	3.19	-1.23	-2.96	3.19	0.48	-0.10	0.18
半干旱风沙区	-0.86	-0.61	-1.05	-1.58	-1.74	-4.10	-1.58	0.40	-0.01	0.48
干旱荒漠区	-7.70	-0.57	-1.75	-0.35	-1.22	-1.68	-0.35	-0.24	0.07	0.93
黄土高原区	-0.15	-0.08	-0.06	-4.32	-9.53	-0.19	-4.32	0.48	0.21	-0.04
三北工程区	-5.67	-0.52	-1.24	-2.38	-1.30	-2.40	-0.88	0.08	0.03	0.20

时段	指标	真实气候状况	平均气候状况	生态工程贡献率	气候变化贡献率(%)
1985~2000年	土壤风蚀量（×10⁸t）	117.04	104.51	10.71	89.29
	防风固沙服务量（×10⁸t）	193.28	213.53	10.48	89.52
	防风固沙服务保有率（%）	70.64	69.75	1.26	98.74
2000~2015年	土壤风蚀量（×10⁸t）	86.61	99.37	14.73	85.27
	防风固沙服务量（×10⁸t）	182.53	146.05	19.99	80.01
	防风固沙服务保有率（%）	71.23	68.48	3.86	96.14
