基于社会网络分析的旅游地乡村社会空间重构研究

doi:10.13249/j.cnki.sgs.2020.09.014

摘要/Abstract

摘要：

在商品经济影响下，乡村社会关系正发生多途径、多层次重构，由于社会关系与空间形态辩证统一，社会关系的异化将引起空间形态的变化。以南京市世凹美丽乡村示范村为案例，从传统社会结构观念与市场经济之间的冲突出发，建立研究假设，通过2014年、2016年和2018持续跟踪调查，运用社会网络分析方法揭示乡村经济社会空间交互过程。结果表明：① 所选乡村社会网络发展符合社会资本与市场制度相互作用的发展规律，具有替代效应、挤出效应与互补效应3个明显阶段，符合研究假设；② 网络模式由轮轴模式演化到“结构洞”模式再到合作与分派模式，且分别对应扩散型、分支型与簇群型网络结构，伴随行动者的淘汰与迁出与市场经济规则的增强；③ 空间重构主要表现为土地利用格局重构与乡村空间衰退现象，形成优势经营者区域、原住民的边缘集聚区、外来经营者区域与空间衰退区域。

关键词: 南京世凹美丽乡村, 社会网络分析, 社会关系, 空间重构

Abstract:

Today, affected by the transformation of China’s rural development mode, rural social relations are being reconstructed from many aspects, which includes not only rational improvement but also problems such as ‘constructive destruction’ and ‘disintegration of rural social structure’. Due to the dialectical unity of social relations and spatial forms, the alienation of social relations will cause changes in spatial forms, which contributes to the two main research purposes of this paper.The first is to comb the development process of rural tourism and explore the interactive relationship between economic development and social transformation by means of social networks. The second is to explore whether there is a correlation between social relations and spatial changes by investigating and recording the process of spatial change in the countryside, so as to reveal the spatial effects brought about by the evolution of social relations.To this end, following the continuous follow-up investigations of the beautiful countryside of Nanjing Shiwataoyuan village (Hereinafter referred to as Shiwa Village) in 2014, 2016, and 2018, this paper calculates each social network parameter index via social network analysis methods and analyzes the interactive process of rural economic and social space from 2012 to 2018 in detail. The results indicate: 1) The development of the selected rural social network conforms to the development law of the interaction between social capital and the market system, and has three distinct stages: substitution effect stage, crowding-out effect stage and complementary effect stage; 2) The network model evolves from the wheel and axis model to the ‘structure hole’ model and then to the cooperation and faction model, which corresponds to the diffusion, branch and cluster network structures respectively, accompanied by the elimination of actors and the enhancement of market economic rules; 3) Spatial reconstruction is mainly manifested in the reconstruction of land use pattern and the decline of rural space, during which process a dominant operator area, a marginal agglomeration area of aborigines, a foreign operator area and a spatial recession area are accordingly formed.

Key words: Shiwa Beautiful Village in Nanjing, social network analysis, social relationship, spatial reconstruction

中图分类号:

C912.3

陆天华, 于涛. 基于社会网络分析的旅游地乡村社会空间重构研究[J]. 地理科学, 2020, 40(9): 1522-1531.

Lu Tianhua, Yu Tao. Reconstruction of Rural Social Space in Tourist Destinations Based on Social Network Analysis: A Case Study of Shiwa Beautiful Village, Nanjing City[J]. SCIENTIA GEOGRAPHICA SINICA, 2020, 40(9): 1522-1531.

图/表 11

图 1

表 1

表 2

表 3

图 2

图 3

图 4

表 4

图 5

图 6

图 7

参考文献 33

[1]	王新歌, 席建超, 孔钦钦 “实心”与“空心”: 旅游地乡村聚落土地利用空间“极化”研究——以河北野三坡旅游区两个村庄为例[J]. 自然资源学报, 2016. 31 (1): 92- 103.
	Wang Xinge, Xi Jianchao, KongQinqin Solid and hollowed villages: Study on the spatial polarization of tourist villages' land use pattern——A case study of two villages in Yesanpo tourism area, Hebei Province[J]. Journal of Natural Resources, 2016. 31 (1): 92- 103.
[2]	孙白露, 朱启臻农业文化的价值及继承和保护探讨[J]. 农业现代化研究, 2011. 32 (1): 56- 60.
	Sun Bailu, Zhu Qizhen Exploration on value, inheritance and conservation of agricultural culture[J]. Research of Agricultural Modernization, 2011. 32 (1): 56- 60.
[3]	龙花楼, 刘彦随, 邹健中国东部沿海地区乡村发展类型及其乡村性评价[J]. 地理学报, 2009. 64 (4): 426- 434.
	Long Hualou, Liu Yansui, Zou Jian Assessment of rural development types and their rurality in eastern coastal China[J]. Acta Geographica Sinica, 2009. 64 (4): 426- 434.
[4]	张荣天, 张小林, 李传武基于县域尺度的江苏省乡村性空间格局演变及其机理研究[J]. 人文地理, 2013. 28 (2): 91- 97.
	Zhang Rongtian, Zhang Xiaolin, Li Chuanwu Evolvement and mechanism of spatial pattern of rurality in Jiangsu Province on county scale[J]. Human Geography, 2013. 28 (2): 91- 97.
[5]	刘润, 杨永春, 李巍基于社会关系网络视角下宗教旅游地社会空间演化研究——以甘肃郎木寺镇区为例[J]. 人文地理, 2014. 29 (2): 47- 53.
	Liu Run, Yang Yongchun, Li Wei Research on the social space evolution of religious tourist resorts based on social relation network: A Case of Langmusi Township[J]. Human Geography, 2014. 29 (2): 47- 53.
[6]	杨忍广州市城郊典型乡村空间分化过程及机制[J]. 地理学报, 2019. 74 (8): 1622- 1636.
	Yang Ren Spatial differentiation and mechanisms of typical rural areas in the suburbs of a metropolis: A case study of Beicun Village, Baiyun District, Guangzhou[J]. Acta Geographica Sinica, 2019. 74 (8): 1622- 1636.
[7]	席建超, 王新歌, 孔钦钦过去25年旅游村落社会空间的微尺度重构——河北野三坡苟各庄村案例实证[J]. 地理研究, 2014. 33 (10): 140- 153.
	Xi Jianchao, Wang Xinge, Kong Qinqin Micro-scale social spatial reconstruction of the tourist villagein the past 25 years: A case study of Gouge Village in Yesanpo, Hebei Province[J]. Geographical Research, 2014. 33 (10): 140- 153.
[8]	谷玉良, 江立华空间视角下农村社会关系变迁研究——以山东省枣庄市L村“村改居”为例[J]. 人文地理, 2015. 30 (4): 51- 57.
	Gu Yuliang, Jiang Lihua Changes of the rural social relations under spatial perspective: A case of L Village in Zaozhuang of Shandong Province[J]. Human Geography, 2015. 30 (4): 51- 57.
[9]	Castells M. Rise of the network society[M]. United Station of America: Blackwell, 1996: 20.
[10]	Soja E W. Thirdspace: Journeys to Los Angeles and other real-and-imagined places[M]. Malden/Oxford: Blackwell, 1996.
[11]	刘法建, 张捷, 章锦河, 等旅游地网络的演化与时空特征研究——以黄山风景区及汤口社区为例[J]. 地理科学, 2014. 34 (12): 1428- 1437.
	Liu Fajian, Zhang Jie, Zhang Jinhe et al The process and spatial-temporal feature of tourism destination network evolution: A case study of MT. Huangshan scenic area and Tangkou[J]. Scientia Geographica Sinica, 2014. 34 (12): 1428- 1437.
[12]	Sarkar D, Sieber R, Sengupta R. GIScience Considerations in Spatial Social Networks[C]. The annual international conference on geographic information science. Cham: Springer, 2016: 85-98.
[13]	Ye X Y, Liu X J Integrating social networks and spatial analyses of the built environment[J]. Environment and Planning B-Urban Analytics and City Science, 2018. 45 (3): 395- 399.
[14]	Boessen A, Hipp J R, Butts C T et al The built environment, spatial scale, and social networks: Do land uses matter for personal network structure[J]. Environment and Planning B-Planning & Design, 2018. (3): 400- 416.
[15]	Kim C, Parent O, VomHofe R The role of peer effects and the built environment on individual travel behavior[J]. Environment and Planning B: Urban Analytics and City Science, 2017. 45 (3): 452- 469.
[16]	Zhao M X, Wang Y M Measuring Segregation between rural migrants and local residents in urban China: An integrated spatio-social network analysis of Kecun in Guangzhou[J]. Environment and Planning B-Urban Analytics and City Science, 2018. 45 (3): 417- 433.
[17]	S. M. R, C. F, G. E. T. Spatializing social networks using social network analysis to investigate geographies of Gang rivalry territoriality and violence in Los Angeles[J]. Annals of the Association of American Geographers, 2010, (2): 307-326.
[18]	Faust K, Entwisle B, Rindfuss R R Spatial arrangement of social and economic networks among villages in Nang Rong District, Thailand[J]. Social Networks, 2000. 21 (4): 311- 337. doi: 10.1016/S0378-8733(99)00014-3
[19]	Sailer K, Mcculloh I Social networks and spatial configuration—How office layouts drive social interaction[J]. Social Networks, 2012. (1): 47- 58.
[20]	黄勇, 刘杰, 史靖塬城镇商业街道空间网络模型构建及方法研究——以重庆磁器口为例[J]. 城市规划, 2016. 40 (6): 67- 73.
	Huang Yong, Liu Jie, Shi Jingyuan Construction of the social network model and method study of urban commercial street space: A case study of Chongqing Ciqikou business street[J]. City Planning Review, 2016. 40 (6): 67- 73.
[21]	吴嘉慧, 李佩玲, 赵渺希城市混居地段外来人口社会隔离的空间测度——以广州客村为例[J]. 人文地理, 2016. 31 (6): 79- 87.
	Wu Jiahui, Li Peiling, Zhao Miaoxi Spatial measurementof social segregation between migrants and locals in urban mixed-neighbourhoods: A case study of Kecun, Guangzhou[J]. Human Geography, 2016. 31 (6): 79- 87.
[22]	何深静, 于涛方, 方澜城市更新中社会网络的保存和发展[J]. 人文地理, 2001. (6): 36- 39.
	He Shenjing, Yu Taofang, Fang Lan Protection and development of social networks in urban renewal[J]. Human Geography, 2001. (6): 36- 39.
[23]	赵万民, 彭薇颖, 黄勇基于社会网络重建的历史街区保护与更新研究——以重庆市长寿区三倒拐历史街区为例[J]. 规划师, 2008. (2): 9- 13.
	Zhao Wanmin, Peng Weiying, Huang Yong Research on the conservation and regeneration of historical city quarter based on social network reestablishment: A case study of Sandaoguai Historical Quarter in Changshou District, Chongqing[J]. Planners, 2008. (2): 9- 13.
[24]	古倩华, 郭璞若, 赵渺希乡镇治理的正式制度——非正式制度耦合分析——以广东省河源市林寨古村为例[J]. 小城镇建设, 2019. 37 (4): 60- 66.
	Gu Qianhua, Guo Puruo, Zhao Miaoxi Analysis of the coupling of formal and informal institutions in the township governance: A case study of Linzhai Village, Heyuan City, Guandong Province[J]. Development of Small Cities & Towns, 2019. 37 (4): 60- 66.
[25]	边燕杰, 张文宏, 程诚求职过程的社会网络模型: 检验关系效应假设[J]. 社会, 2012. 32 (3): 31- 44.
	Bian Yanjie, ZhangWenhong, Cheng Cheng A social network model of the job-search process: Testing a relation effect hypothesis[J]. Society, 2012. 32 (3): 31- 44.
[26]	Tsai L L Solidary groups, informal accountability, and local public goods provision in rural China[J]. American Political Science Review, 2007. 101 (2): 355- 372. doi: 10.1017/S0003055407070153
[27]	蒋剑勇, 钱文荣, 郭红东社会网络、社会技能与农民创业资源获取[J]. 浙江大学学报(人文社会科学版), 2013. 43 (1): 85- 100.
	Jiang Jianyong, Qian Wenrong, Guo Hongdong Social networks, social skills and peasant entrepreneurs' resources acquisition[J]. Journal of Zhejiang University (Humanities and Social Scienses), 2013. 43 (1): 85- 100.
[28]	彭红松, 陆林, 路幸福, 等基于社会网络方法的跨界旅游客流网络结构研究——以泸沽湖为例[J]. 地理科学, 2014. 34 (9): 1041- 1050.
	Peng Hongsong, Lu Lin, Lu Xingfu et al The network structure of cross-border tourism flow based on the social network method: A case of Lugu Lake Region[J]. Scientia Geographica Sinica, 2014. 34 (9): 1041- 1050.
[29]	李志刚, 刘晔中国城市“新移民”社会网络与空间分异[J]. 地理学报, 2011. 66 (6): 785- 795.
	Li Zhigang, Liu Ye Beyond spatial segregation: Neo-migrants and their social networks in Chinese cities[J]. Acta Geographica Sinica, 2011. 66 (6): 785- 795.
[30]	Van Der Poel M G M Delineating personal support networks[J]. Social Networks, 1993. 15 (1): 49- 70. doi: 10.1016/0378-8733(93)90021-C
[31]	陈培培, 张敏从美丽乡村到都市居民消费空间——行动者网络理论与大世凹村的社会空间重构[J]. 地理研究, 2015. 34 (8): 1435- 1446.
	Chen Peipei, Zhang Min From beautiful village to urban residents' consumption space: Actor-network theory and the social space reconstruction of Dashiao Village[J]. Human Geography, 2015. 34 (8): 1435- 1446.
[32]	Burt R S Structural holes and good odeas[J]. American Journal of Sociology, 2004. 110 (2): 349- 399. doi: 10.1086/421787
[33]	吴吉林, 周春山, 谢文海传统村落农户乡村旅游适应性评价与影响因素研究——基于湘西州6个村落的调查[J]. 地理科学, 2018. 38 (5): 755- 763.
	Wu Jilin, Zhou Chunshan, Xie Wenhai The influencing factors and evaluation of farmer’s adaptability towards rural tourism in traditional village: Based on the survey of 6 villagesin Xiangxi prefecture, Hunan[J]. Scientia Geographica Sinica, 2018. 38 (5): 755- 763.

阶段	关系	特性
第一阶段	替代	社会资本效率更高，正外部性大于负外部性
第二阶段	挤出	社会资本效率降低，发生零和博弈，市场制度开始排斥社会资本
第三阶段	互补	初始社会资本遭到挤出，新的社会关系与市场制度并存

发展阶段	调查时间	情景问题
第一阶段替代阶段	2014年4月	经营农家乐村里谁对你的影响最大？
		您认为村里人经营农家乐有谁是受您的直接影响吗？
第二阶段挤出阶段	2016年5月	在您家里改造时，谁对您家的帮助最大？
		您一般是从谁哪里获得经营改造政策一类的消息？
		哪些人来您家里宣传农家乐建设的事情次数最多？
第三阶段互补阶段	2018年10月	在您家里经营需要借钱时，你会最先考虑同村哪户？
		如果您家里的客源已满，您会把多出的客人介绍给谁？
		村里有没有哪户与您有重要的经营合作？

社会网络发展阶段	节点总数	网络密度	度中心度标准差	集中度
替代效应阶段（2012—2014年）	27	0.0229	6.572	35.21%
挤出效应阶段（2014—2016年）	30	0.138	5.414	25.62%
互补效应阶段（2016—2018年）	23	0.0354	3.012	8.17%

社会网络发展阶段	时间	网络类型	社会网络特征模式
第一阶段替代阶段	2012—2014年	扩散型网络	轮轴模式
第二阶段挤出阶段	2014—2016年	分支型网络	“结构洞”模式
第三阶段互补阶段	2016—2018年	簇群型网络	合作、派系模式
