基于景观格局的黑河中游土地利用冲突时空分析

doi:10.13249/j.cnki.sgs.2020.09.017

摘要/Abstract

摘要：

以黑河中游为研究区，在分析土地利用变化的基础上，构建了由外部压力、脆弱性和稳定性表征土地利用冲突强度的模型，分析了1980—2015年土地利用冲突的时空变化特征。结果表明：① 土地利用冲突强度的空间分布在不同时期虽有不同，但冲突强度较高的区域集中在甘州、临泽2个人类活动较为活跃的区县，且指数最高的区域呈围绕城市四周分布的特点；② 土地利用冲突在不同时期变化显著，1995—2005年是土地利用冲突强度增加较为明显的时段，中部的甘州区、南部的山丹县两地增加最为明显；2005—2015年虽然冲突强度增大区域的面积少于上一时段，但冲突增加幅度高于上一时段，尤其民乐县和高台县增加较为明显；③ 土地利用冲突与自然因素的相关性极弱，与道路和河流等用地条件的相关性较强，而与人口密度和GDP为代表的社会经济因素的相关性最强；④ 土地利用冲突与土地利用变化的阶段性特征一致，1995—2000年是土地利用变化程度最为剧烈的时期，而1995—2005年也是土地利用冲突面积增加最多的时段；耕地和建设用地的增长极为活跃，对生态用地产生侵占，反映了耕地、建设用地和生态用地三者之间的矛盾是黑河中游土地利用冲突的主要表现形式。

关键词: 土地利用变化, 景观格局, 土地利用冲突, 黑河中游

Abstract:

With the development of society and economy, the demand of land use is diversified, and the land resources are becoming more and more scarce, which makes the emergence of land use conflict inevitable. Land use conflict has aggravated the contradiction among economic, ecological and social benefit, and has become an important factor to restrict the sustainable utilization of land. Based on the analysis of land use change in the middle reaches of the Heihe River, this study used external pressure, vulnerability and stability to construct a model of land use conflict intensity, and then analyzed the temporal and spatial variation characteristics of land use conflict in the past 35 years. The results showed: 1) The spatial distributions of land use conflict intensity were different in different periods, but high conflict intensity concentrated in Ganzhou and Linze, where the human activities were active. The areas with high conflict were distributed around cities. 2) The changes of land use conflict varied significantly in different periods. From 1995 to 2005, the intensity of land use conflict increased obviously, with the most obvious increase in Ganzhou and Shandan. In 2005-2015, although the area of the increased conflict intensity was less than the previous period, the increased degree of conflict was higher than that in the previous period, especially in Minle and Gaotai. 3) Land use conflict was weakly correlated with natural factors, but it was strongly correlated with land use conditions such as roads and rivers, and had the strongest correlation with social and economic factors represented by population density and GDP. 4) The stage characteristics of land use conflict and land use change were consistent. 1995-2000 was the period of most drastic land use change, and 1995-2005 was the period during which the area of land use conflict increased the most. The growth of cultivated land and construction land was very active, resulting in the encroachment of ecological land. It reflected that the contradiction among cultivated land, construction land and ecological land was the main form of land use conflict in the middle reaches of the Heihe River. The results can be used as a reference for land spatial planning and sustainable land use management in arid areas.

Key words: land use change, landscape pattern, land use conflict, the middle reaches of the Heihe River

中图分类号:

P942

蒙吉军, 江颂, 拉巴卓玛, 张维佳. 基于景观格局的黑河中游土地利用冲突时空分析[J]. 地理科学, 2020, 40(9): 1553-1562.

Meng Jijun, Jiang Song, Laba Zhuoma, Zhang Weijia. The Spatial and Temporal Analysis of Land Use Conflict in the Middle Reaches of the Heihe River Based on Landscape Pattern[J]. SCIENTIA GEOGRAPHICA SINICA, 2020, 40(9): 1553-1562.

图/表 7

图 1

图 2

图 3

图 4

图 5

图 6

表 1

参考文献 29

[1]	于伯华, 吕昌河土地利用冲突分析:概念与方法[J]. 地理科学进展, 2006. 25 (3): 106- 115.
	Yu Bohua, Lv Changhe The progress and prospect of land use conflicts[J]. Progress in Geography, 2006. 25 (3): 106- 115.
[2]	杨永芳, 朱连奇土地利用冲突的理论与诊断方法[J]. 资源科学, 2012. 34 (6): 1134- 1141.
	Yang Yongfang, Zhu Lianqi The theory and diagnostic methods of land use conflicts[J]. Resources Science, 2012. 34 (6): 1134- 1141.
[3]	Hui E C M, Bao H J The logic behind conflicts in land acquisitions in contemporary China: A framework based upon game theory[J]. Land Use Policy, 2013. 30 (1): 373- 380. doi: 10.1016/j.landusepol.2012.04.001
[4]	许学工, 彭慧芳, 徐勤政海岸带快速城市化的土地资源冲突与协调——以山东半岛为例[J]. 北京大学学报(自然科学版), 2006. 42 (4): 527- 533.
	Xu Xuegong, Peng Huifang, Xu Qinzheng Land resource conflicts and coordination in fast urbanized coastal zone: A case study of the Shandong Peninsula[J]. Acta Scientiarum Naturalium Universitatis Pekinensis, 2006. 42 (4): 527- 533.
[5]	Peters P E Bewitching land: The role of land disputes in converting kin to strangers and in class formation in Malawi[J]. Journal of Southern African Studies, 2002. 28 (1): 155- 178. doi: 10.1080/03057070120117024
[6]	冉娜, 金晓斌, 范业婷, 等基于土地利用冲突识别与协调的“三线”划定方法研究——以常州市金坛区为例[J]. 资源科学, 2018. 40 (2): 284- 298.
	Ran Na, Jin Xiaobin, Fan Yeting, et al ‘Three Lines’ delineation based on land use conflict identification and coordination in Jintan District, Changzhou[J]. Resources Science, 2018. 40 (2): 284- 298.
[7]	彭佳捷, 周国华, 唐承丽, 等基于生态安全的快速城市化地区空间冲突测度——以长株潭城市群为例[J]. 自然资源学报, 2012. 27 (9): 1507- 1519.
	Peng Jiajie, Zhou Guohua, Tang Chengli, et al The analysis of spatial conflict measurement in fast urbanization region based on ecological security: A case study of Changsha-Zhuzhou-Xiangtan urban agglomeration[J]. Journal of Natural Resources, 2012. 27 (9): 1507- 1519.
[8]	Garciaruiz J M, Lasantamartinez T Land-use conflicts as a result of land-use change in the central Spanish Pyrenees: A review[J]. Mountain Research and Development, 1993. 13 (3): 295- 304. doi: 10.2307/3673658
[9]	王秋兵, 郑刘平, 边振兴, 等沈北新区潜在土地利用冲突识别及其应用[J]. 农业工程学报, 2012. 28 (15): 185- 192.
	Wang Qiubing, Zheng Liuping, Bian Zhenxing, et al Potential land use conflict identification and its application in Shenbei New District[J]. Transactions of the Chinese Society of Agricultural Engineering, 2012. 28 (15): 185- 192.
[10]	Hilson G An overview of land use conflicts in mining communities[J]. Land Use Policy, 2002. 19 (1): 65- 73. doi: 10.1016/S0264-8377(01)00043-6
[11]	Pacheco F A L, Varandas S G P, Sanches Fernandes L F, et al Soil losses in rural watersheds with environmental land use conflicts[J]. Science of the Total Environment, 2014. 485, 110- 120.
[12]	阮松涛, 吴克宁城镇化进程中土地利用冲突及其缓解机制研究——基于非合作博弈的视角[J]. 中国人口·资源与环境, 2013. 23 (11): 388- 392.
	Ruan Songtao, Wu Kening Research of the land use conflict and mitigation mechanism during the urbanization in China[J]. China Population, Resources and Environment, 2013. 23 (11): 388- 392.
[13]	杨永芳, 安乾, 朱连奇基于PSR模型的农区土地利用冲突强度的诊断[J]. 地理科学进展, 2012. 31 (11): 1552- 1560.
	Yang Yongfang, An Qian, Zhu Lianqi Diagnosis based on the PSR model of rural land-use conflicts intensity[J]. Progress in Geography, 2012. 31 (11): 1552- 1560.
[14]	冯宇, 毕如田, 王瑾, 等流域矿业开采引发的土地利用空间冲突及优化配置[J]. 中国土地科学, 2016. 30 (11): 32- 40.
	Feng Yu, Bi Rutian, Wang Jin, et al Spatial conflict of land use caused by mining exploitation and optimal allocation scheme of land resources in river basin[J]. China Land Sciences, 2016. 30 (11): 32- 40.
[15]	Ioja C I, Nita M R, Vanau G O, et al Using multi-criteria analysis for the identification of spatial land-use conflicts in the Bucharest Metropolitan Area[J]. Ecological Indicators, 2014. 42, 112- 121. doi: 10.1016/j.ecolind.2013.09.029
[16]	陈群弟, 董玉祥. 广州市土地利用冲突强度测度与分析[A]// 2013全国土地资源开发利用与生态文明建设学术研讨会论文集. 2013: 9.
	Chen Qundi, Dong Yuxiang. The analysis of land use conflicts measurement in Guangzhou. The symposium proceedings of research on land resource utilization and ecological civilization construction in China in 2013. 2013: 9.
[17]	周德, 徐建春, 王莉环杭州湾城市群土地利用的空间冲突与复杂性[J]. 地理研究, 2015. 34 (9): 1630- 1642.
	Zhou De, Xu Jianchun, Wang Li Land use spatial conflicts and complexity: A case study of the urban agglomeration around Hangzhou Bay, China[J]. Geographical Research, 2015. 34 (9): 1630- 1642.
[18]	陈威. 云南省红河县土地利用冲突研究[D]. 兰州: 甘肃农业大学, 2015.
	Chen Wei. Study on land use conflict in Honghe country of Yunnan province. Lanzhou: Gansu Agricultural University, 2015.
[19]	蒙吉军, 赵春红, 刘明达基于土地利用变化的区域生态安全评价研究——以鄂尔多斯为例[J]. 自然资源学报, 2011. 26 (4): 578- 590.
	Meng Jijun, Zhao Chunhong, Liu Mingda Regional ecological security assessment based on land use change-A case study in Ordos City[J]. Journal of Natural Resources, 2011. 26 (4): 578- 590.
[20]	Xiang Y Y, Meng J J Research into ecological suitability zoning and expansion patterns in agricultural oases based on the landscape process: a case study in the middle reaches of the Heihe River[J]. Environmental Earth Sciences, 2016. 75 (20): 1355- 1367. doi: 10.1007/s12665-016-6165-5
[21]	张掖市统计局. 张掖市统计年鉴(2017年)[M]. 兰州: 甘肃文化出版社, 2018.
	Zhangye Bureau of Statistics. Zhangye City Statistical Yearbook (2017) . Lanzhou: Gansu Culture Publishing House, 2018.
[22]	谢花林基于景观结构和空间统计学的区域生态风险分析[J]. 生态学报, 2008. 28 (10): 5020- 5026.
	Xie Hualin Regional eco-risk analysis based on landscape structure and spatial statistics[J]. Acta Ecologica Sinica, 2008. 28 (10): 5020- 5026.
[23]	赵旭, 汤峰, 张蓬涛, 等基于CLUE-S模型的县域生产-生活-生态空间冲突动态模拟及特征分析[J]. 生态学报, 2019. 39 (16): 5897- 5908.
	Zhao Xu, Tang Feng, Zhang Pengtao, et al Dynamic simulation and characteristic analysis of county production-living-ecological spatial conflicts based on CLUE-S model[J]. Acta Ecologica Sinica, 2019. 39 (16): 5897- 5908.
[24]	Zhou D, Lin Z, Lim S H Spatial characteristics and risk factor identification for land use spatial conflicts in a rapid urbanization region in China[J]. Environmental Monitoring and Assessment, 2019. 191 (11)
[25]	张玲玲, 赵永华, 殷沙, 等基于移动窗口法的岷江干旱河谷景观格局梯度分析[J]. 生态学报, 2014. 34 (12): 3276- 3284.
	Zhang Lingling, Zhao Yonghua, Yin Sha, et al Gradient analysis of dry valley of Minjiang River landscape pattern, based on moving window method[J]. Acta Ecologica Sinica, 2014. 34 (12): 3276- 3284.
[26]	孙云华, 郭涛, 崔希民昆明市土地利用变化的强度分析与稳定性研究[J]. 地理科学进展, 2016. 35 (2): 245- 254. doi: 10.18306/dlkxjz.2016.02.011
	Sun Yunhua, Guo Tao, Cui Ximin Intensity analysis and stationarity of land use change in Kunming City[J]. Progress in Geography, 2016. 35 (2): 245- 254. doi: 10.18306/dlkxjz.2016.02.011
[27]	潘竟虎, 李真干旱内陆河流域生态系统服务空间权衡与协同作用分析[J]. 农业工程学报, 2017. 33 (17): 280- 289.
	Pan Jinghu, Li Zhen Analysis on trade-offs and synergies of ecosystem services in arid inland river basin[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2017. 33 (17): 280- 289.
[28]	Meyer B, Degorski M. Integration of multifunctional goals into land use: The planning perspective[M]// Mander U et al. Multifunctional land use. Berlin, Heidelberg: Springer, 2007: 153-166.
[29]	De Groot R Function-analysis and valuation as a tool to assess land use conflicts in planning for sustainable, multi-functional landscapes[J]. Landscape and Urban Planning, 2006. 75 (3-4): 175- 186. doi: 10.1016/j.landurbplan.2005.02.016

土地利用冲突指数	年降水量	高程	坡度	与主道路的距离	与主河流的距离	人口密度	生产总值
1995年冲突指数	?0.215^*	?0.351^**	?0.1754	?0.395^**	?0.403^**	0.399^**	0.439^**
2005年冲突指数	?0.1686	?0.304^*	?0.1644	?0.385^**	?0.368^**	0.385^**	0.470^**
2010年冲突指数	?0.1688	?0.278^**	?0.1430	?0.388^**	?0.347^**	0.445^**	0.459^**
2015年冲突指数	?0.0739	?0.298^**	?0.1502	?0.351^**	?0.388^**	0.449^**	0.467^**
