不同流要素视角下沿海港口城市体系的网络空间联系

doi:10.13249/j.cnki.sgs.2022.11.002

摘要/Abstract

摘要：

借助GIS、Matlab和Gephi等技术手段，运用不同流要素分析2006年和2016年中国沿海港口城市体系的网络联系及空间变化特征。结果表明：①在5个流动要素网络中，城市间的要素联系总量增加且增幅较大，集中分散程度、区域分布特征均发生了显著变化。港口城市体系的网络空间结构正由“点轴”模式向“网络化”模式转化。②不同流要素的枢纽城市具有高度重合性，但网络结构具有明显差异性。物流和客流呈现“组团发展”与“轴?辐”并存的网络特征。资金流和技术流发育出显著的“核心?边缘”和层次性的空间形态。信息流呈现均衡的网络化发展模式。③不同流要素刻画出不同层面的港口城市体系，但却有着紧密联系。物流与客流相互影响、互为因果。资金流和技术流对物流具有积极的促进作用。信息流对物流的影响具有明显的滞后性；港口城市体系由单一流要素转向多元流要素综合发展，港口城市间联系更加多元化，并实现了与外部流要素的互动融合。

关键词: 多元流要素, 城市网络, 流动空间, 港口城市体系

Abstract:

With the rapid development of globalization, information and communication technology and high-speed railways, the frequency of element flow has greatly increased, and the comprehensive connection of multiple flow perspectives has become the key to the development of port cities and regions. With the help of GIS, Matlab and Gephi and other technical means, different flow elements are used to analyze the network connection and spatial variation characteristics of China’s coastal port city system in 2006 and 2016. The results show that: 1) In the 5 flow element networks, the total number of element connections between cities has increased and the increase degree has been larger, and the degree of concentration and dispersion and the characteristics of regional distribution have changed significantly. The cyberspace structure of the port city system is transforming from a ‘point axis’ model to a ‘networked’ model. 2) The hub cities with different flow elements have a high degree of overlap, but the network structure has obvious differences. Logistics and passenger flow present the network characteristics of coexistence of ‘group development’ and ‘hub-spoke’. The capital flow and technology flow have developed significant ‘core-periphery’ and hierarchical spatial patterns. Information flow presents a balanced network development model. 3) Different flow elements describe the port city system at different levels, but they are closely related. Logistics and passenger flow affect each other and are cause and effect. The flow of capital and technology has a positive effect on logistics. The impact of information flow on logistics has obvious lag; the port city system has changed from a single flow element to a comprehensive development of multiple flow elements, and the connections between port cities are more diversified, and the interaction and integration with external flow elements have been realized.

Key words: multi element flow, urban network, flow space, port city system

中图分类号:

K902

秦娅风, 郭建科. 不同流要素视角下沿海港口城市体系的网络空间联系[J]. 地理科学, 2022, 42(11): 1867-1878.

Qin Yafeng, Guo Jianke. Network Spatial Connection of Coastal Port City System from the Perspective of Multiple Flows[J]. SCIENTIA GEOGRAPHICA SINICA, 2022, 42(11): 1867-1878.

图/表 9

表1

表2

数据信息及来源

流要素	类型	信息	构建原则	来源
物流	中国各港口间、中国始发至全球其他港口的船期表	集装箱船只起讫港口、出发和抵达时间、船名和航次	从中筛选出中国沿海各港口城市间（直达及中转）的船期信息，并以此为依据构建物流网络	《中国航务周刊》（ http://csg.wuliujia2018.com/）
客流	各城市中列车时速高于120 km/h的列车，也即以K、T、Z、D、C、G开头的列车	车次、始发站、终到站、运行时间	从中筛选出中国沿海各港口城市间的列次信息，并以此为依据构建客流网络	《全国铁路列车时刻表》（ https://www.12306.cn/index/）、《中国交通统计年鉴》（ https://www.mot.gov.cn/tongjishuju/）
资金流	中国城市间城际控股型（含全资）的企业间投资联系数据	企业名称、注册时间、注册资本、注册地址、投资企业、投资资本、投资地址等	从中筛选出中国沿海各港口城市企业间的投资联系数据信息，以此为依据构建资金流网络	启信宝（ www.qixin.com/）^①(①“启信宝”是从全国企业信用信息公示系统、中国法院裁判文书网、中国执行信息公开网等100家网站提取官方数据。通过企业名称、人名、品牌、联系方式、网址、专利等企业信息关键字或者组合关键字多维度锁定目标企业。)
技术流	各城市之间关于专利、科技^{成果及科技报告的单位合作联系数据}	成果类型、发表成果时间、发^{表成果作者单位、单位地址等}	采取一定规则^②(②选取有合作关系的数据，汇总并进行加权。即参与每篇专利等的作者群，如为两两联系，则分别计为1/2；3个联系的数据，分别计为1/3，以此类推，由此得出港口城市网络联系矩阵。)对相关专利、成果和报告进行量化。从中筛选出中国沿海各港口城市间技术联系数据信息，以此为依据构建技术流网络	万方数据知识平台^{（ www.wanfangdata.com.cn）}
信息流	“两两城市之间”的信息流^{通数据（剔除了无效和干扰信息）}	时间、词条内容（积极/消极）、^地址等	从中筛选出中国沿海各港口^{城市间信息联系数据，以此为依据构建信息流网络}	百度搜索（ www.baidu.com）^③(③百度拥有目前世界上最大的中文信息库,并使用了高性能的“网络蜘蛛”程序自动在互联网中搜索信息, 能在极短的时间内收集到最大数量的互联网信息。)界面

表2

表3

图1

图2

图3

图4

图5

表4

参考文献 33

[1]	王海平, 刘秉镰. 现代化港口城市的内涵与特征——兼论港口经济[J]. 港口经济, 2000(1): 9-13
	Wang Haiping, Liu Binglian. Connotation and characteristics of modern port city. Port Economy, 2000(1): 9-13
[2]	Hoyle B S. The port–city interface: Trends, problems, and examples[J]. Geoforum, 1989, 20(4): 429-435 doi: 10.1016/0016-7185(89)90026-2
[3]	郭建科, 吴陆陆, 李博, 等. 多功能视角的沿海港口城市体系位序规模结构及耦合类型[J]. 地理科学, 2020, 40(7): 1050-1061
	Guo Jianke, Wu Lulu, Li Bo et al. Rank-size structure and coupling type of coastal port city system based on multifunctional perspective. Scientia Geographica Sinica, 2020, 40(7): 1050-1061
[4]	郭建科, 韩增林. 中国海港城市“港–城空间系统”演化理论与实证[J]. 地理科学, 2013, 33(11): 1285-1292
	Guo Jianke, Han Zenglin. The port-city spatial system evolution theory and empirical study of Chinese seaport city. Scientia Geographica Sinica, 2013, 33(11): 1285-1292
[5]	Zhen Feng, Qin Xiao, Ye Xinyue et al. Analyzing urban development patterns based on the flow analysis method[J]. Cities, 2019, 86: 178-197 doi: 10.1016/j.cities.2018.09.015
[6]	Bird J. The major seaports of the United Kingdom[J]. London:Hutchinson, 1963: 21-22
[7]	Notteboom T, Rodrigue J. Port regionalization: Towards a new phase in port development[J]. Maritime Policy and Management, 2005, 32(3): 297-313 doi: 10.1080/03088830500139885
[8]	Mina Akhavan. Development dynamics of port-cities interface in the Arab Middle Eastern world—The case of Dubai global hub port-city[J]. Cities, 2017, 60(3): 343-352
[9]	王成金. 中国港口分布格局的演化与发展机理[J]. 地理学报, 2007, 62(8): 809-820 doi: 10.3321/j.issn:0375-5444.2007.08.003
	Wang Chengjin. Evolution and developing mechanism of port distribution system in China. Acta Geographica Sinica, 2007, 62(8): 809-820 doi: 10.3321/j.issn:0375-5444.2007.08.003
[10]	王缉宪. 中国港口城市互动与发展[J]. 南京: 东南大学出版社, 2010.
	Wang Jixian. Interaction and development of port cities in China. Nanjing: Southeast University Press, 2010.
[11]	曹有挥, 蒋自然, 陈欢, 等. 长江沿岸港口体系的形成过程与机制[J]. 地理科学进展, 2015, 34(11): 1430-1440 doi: 10.18306/dlkxjz.2015.11.010
	Cao Youhui, Jiang Ziran, Chen Huan et al. The evolution course and mechanism of the port system along the Yangtze River. Progress in Geography, 2015, 34(11): 1430-1440 doi: 10.18306/dlkxjz.2015.11.010
[12]	Guo Jianke, Qin Yafeng, Du Xiaofei et al. Dynamic measurements and mechanisms of coastal port-city relationships based on the DCI model: Empirical evidence from China[J]. Cities, 2020, 96: 102440 doi: 10.1016/j.cities.2019.102440
[13]	梁双波, 曹有挥, 曹卫东, 等. 长三角集装箱港口体系的偏移增长与演化模式[J]. 地理科学进展, 2008, 27(5): 95-102 doi: 10.11820/dlkxjz.2008.05.013
	Liang Shuangbo, Cao Youhui, Cao Weidong et al. The total shift and evolution of the Yangtze River Delta container port system. Progress in Geography, 2008, 27(5): 95-102 doi: 10.11820/dlkxjz.2008.05.013
[14]	王成金, 金凤君. 中国海上集装箱运输的组织网络研究[J]. 地理科学, 2006, 26(4): 4392-4401
	Wang Chengjin, Jin Fengjun. Organization networks of Chinese marine container transportation. Scientia Geographica Sinica, 2006, 26(4): 4392-4401
[15]	王列辉, 林羽珊, Cesar Ducruet. 1895—2016年全球海运网络中的海峡两岸港口运输联系变化[J]. 地理学报, 2018, 73(12): 2282-2296
	Wang Liehui, Lin Yushan, Cesar Ducruet. Changes of ports’ connection across the Taiwan Straits in the global maritime network (1895-2016). Acta Geographica Sinica, 2018, 73(12): 2282-2296
[16]	杜超, 王姣娥, 莫辉辉. 中国集装箱航运网络空间格局及复杂性研究[J]. 长江流域资源与环境, 2016, 25(2): 90-198
	Du Chao, Wang Jiao'e, Mo Huihui. Spatial pattern analysis of China container shipping network on complex theory. Resources and Environment in the Yangtze Basin, 2016, 25(2): 90-198
[17]	赵新正, 李秋平, 芮旸, 等. 基于财富500强中国企业网络的城市网络空间联系特征[J]. 地理学报, 2019, 74(4): 694-709
	Zhao Xinzheng, Li Qiuping, Rui Yang et al. The characteristics of urban network of China: A study based on the Chinese companies in the Fortune Global 500 list. Acta Geographica Sinica, 2019, 74(4): 694-709
[18]	Peter Nijkamp, Aura Reggiani, Wai Fai Tsang. Comparative modelling of interregional transport flows: Applications to multimodal European freight transport[J]. European Journal of Operational Research, 2004(155): 584-602
[19]	Murat H Celika, Jean-Michel Guldmann. Spatial interaction modeling of interregional commodity flows[J]. Socio-economic Planning Sciences, 2007, 41(2): 147-162 doi: 10.1016/j.seps.2005.10.003
[20]	焦敬娟, 王姣娥, 金凤君, 等. 高速铁路对城市网络结构的影响研究——基于铁路客运班列分析[J]. 地理学报, 2016, 71(2): 265-280
	Jiao Jingjuan, Wang Jiao'e, Jin Fengjun et al. Impact of high-speed rail on inter-city network based on the passenger train network in China, 2003-2013. Acta Geographica Sinica, 2016, 71(2): 265-280
[21]	魏冶, 修春亮, 刘志敏, 等. 春运人口流动透视的转型期中国城市网络结[J]. 地理科学, 2016, 36(11): 1654-1660
	Wei Ye, Xiu Chunliang, Liu Zhimin et al. Spatial pattern of city network in transitional China based on the population flows in “Chunyun” period. Scientia Geographica Sinica, 2016, 36(11): 1654-1660
[22]	沈丽珍, 罗震, 陈浩. 区域流动空间的关系测度与整合——以湖北省为例[J]. 城市问题, 2011(12): 30-35
	Shen Lizhen, Luo Zhen, Chen Hao. Measurement and integration of regional flow space: A case study of Hubei Province. Urban Problems, 2011(12): 30-35
[23]	武文杰, 董正斌, 张文忠, 等. 中国城市空间关联网络结构的时空演变[J]. 地理学报, 2011, 66(4): 435-445
	Wu Wenjie, Dong Zhengbin, Zhang Wenzhong et al. Spatial and temporal evolution of urban spatial association network structure in China. Acta Geographica Sinica, 2011, 66(4): 435-445
[24]	刘承良, 桂钦昌, 段德忠, 等. 全球科研论文合作网络的结构异质性及其邻近性机理[J]. 地理学报, 2017, 72(4): 737-752.
	Liu Chengliang, Gui Qinchang, Duan Dezhong. Structural heterogeneity and proximity mechanism of global scientific collaboration network based on co-authored papers. Acta Geographica Sinica, 2017, 72(4): 737-752.
[25]	Ter Wal A L J. Cluster emergence and network evolution: A longitudinal analysis of the inventor network in Sophia Antipolis[J]. Regional Studies, 2013, 47(5): 651-668 doi: 10.1080/00343401003614258
[26]	陈艳华, 韦素琼, 陈松林. 大陆台资跨界生产网络的空间组织模式及其复杂性研究——基于大陆台商千大企业数据[J]. 地理科学, 2017, 37(10): 1517-1526
	Chen Yanhua, Wei Suqiong, Chen Songlin. The spatial organization pattern and its complexity characteristics of cross border production networks of Taiwan-funded Enterprises in Chinese mainland: Based on Top 1 000 Taiwan-funded Enterprises in Chinese mainland. Scientia Geographica Sinica, 2017, 37(10): 1517-1526
[27]	王波, 甄峰. 城市实体特征对城市网络空间影响力的作用机制——基于互联网新闻媒体的分析[J]. 地理科学, 2017, 37(8): 1127-1134
	Wang Bo, Zhen Feng. Impacts of city’s characteristics on city’s importance in the virtual world: An empirical analysis based on Internet news media. Scientia Geographica Sinica, 2017, 37(8): 1127-1134
[28]	Derudder B, Cao Z, Liu X et al. Changing connectivities of Chinese cities in the world city network 2010-2016[J]. Chinese Geographical Science, 2018, 28(2): 183-201 doi: 10.1007/s11769-018-0938-6
[29]	Liu X, Derudder B, Wu K. Measuring polycentric urban development in China: An intercity transportation network perspective[J]. Regional Studies, 2016, 50(8): 1302-1315 doi: 10.1080/00343404.2015.1004535
[30]	韩增林, 郭建科. 中国海港空间效应的识别与测度[J]. 地理学报, 2014, 69(2): 243-254 doi: 10.11821/dlxb201402008
	Han Zenglin, Guo Jianke. The identification and measurement of seaport spatial effect in China. Acta Geographica Sinica, 2014, 69(2): 243-254 doi: 10.11821/dlxb201402008
[31]	占文威, 席景科, 王志晓. 基于相似性模块度的层次聚合社区发现算法[J]. 系统仿真学报, 2017, 29(5): 1028-1032+1040
	Zhan Wenwei, Xi Jingke, Wang Zhixiao. Hierarchical agglomerative community detection algorithm based on similarity modularity. Journal of System Simulation, 2017, 29(5): 1028-1032+1040
[32]	樊欢欢, 刘荣. Eviews统计分析与应用[M]. 北京: 机械工业出版社, 2014.
	Fan Huanhuan, Liu Rong. Eviews statistical analysis and application. Beijing: China Machine Press, 2014.
[33]	高鹏, 何丹, 宁越敏, 等. 长江中游城市群社团结构演化及其邻近机制——基于生产性服务企业网络分析[J]. 地理科学, 2019, 39(4): 578-586
	Gao Peng, He Dan, Ning Yuemin et al. Evolution of community structure and its adjacent mechanism in urban agglomeration in the middle reaches of the Yangtze River. Scientia Geographica Sinica, 2019, 39(4): 578-586

港口城市群	港口
注：未含港澳台数据。
环渤海	天津、丹东、大连、营口、锦州、唐山、沧州、秦皇岛、烟台、威海、青岛、日照
长三角	上海、苏州、宁波、连云港、舟山、南京、南通、盐城、温州、常州、无锡、嘉兴、台州、泰州、扬州、镇江
珠三角	广州、深圳、珠海、汕头、惠州、东莞、中山、阳江、江门、茂名
东南沿海	福州、莆田、泉州、厦门
西南沿海	湛江、北海、钦州、防城、海口

	流要素类型	流要素中心	流要素副中心	排名前20%城市所占比重/%	H指数
注：1.流要素中心、流要素副中心和排名20%的城市均依据其加权度中心性界定；2.H指数是指赫希曼–赫芬达尔指数，用于测量港口城市各流要素的集中与分散程度；3.未含港澳台数据。
2006年	物流	上海	深圳、宁波	71.3	0.057
	客流	上海	南京、无锡	47.3	0.038
	资金流	深圳	上海、宁波	74.1	0.075
	技术流	上海	深圳、广州	73.5	0.113
	信息流	上海、南京、宁波	苏州、深圳	31.0	0.003
2016年	物流	上海、宁波	深圳、青岛	83.6	0.078
	客流	上海、南京	无锡、常州	60.7	0.032
	资金流	上海、深圳、广州	苏州、南京	73.8	0.081
	技术流	深圳、上海	广州、南京	77.7	0.068
	信息流	上海、南京、深圳	广州、南通	24.7	0.003
