东北地区“三区空间”格局演化特征及驱动机制

doi:10.13249/j.cnki.sgs.2023.02.014

摘要/Abstract

摘要：

采用空间转移矩阵、景观格局分析和最优参数地理探测器等方法，从“量变–形变”两个维度切入，研究2000—2020年东北地区“三区空间”演化特征与驱动机制。结果表明：① 近20 a东北地区城镇空间剧烈扩张的同时常住人口不断减少，中小城镇“人口–土地”失衡问题显著；农业空间、生态空间规模有所减少；② 农业空间是城镇扩张的主要来源，国家级农产品主产区中农业空间流失严重；“生态–农业”空间的相互交叉转换现象明显，集中发生在农产品主产区和重点生态功能区；③ 重点开发区、优化开发区内景观破碎化、异质化趋势明显，农产品主产区中农业空间作为优势类型的地位下降，重点生态功能区景观格局变化不明显；④ 国土开发政策是东北“三区空间”演化的关键驱动力；地理基础条件是基本动力，对形态变化的驱动作用更强；社会经济条件是重要驱动力，对交叉转换规模的作用尤为显著。

关键词: 三区空间, 东北全面振兴, 主体功能区, 最优参数地理探测器

Abstract:

Using the spatial transformation matrix, landscape pattern analysis, and Optimal Parameters-based Geographical Detector Model, this study aimed to reveal the spatial evolution characteristics and formation mechanism of the ''three-zone space'' in Northeast China in the past 20 years from the two dimensions of transformation gross scale and landscape pattern change. The results showed that: 1) In the last 20a, with the rapid expansion of urban space, the resident population in Northeast China was decreasing, and the imbalance of ''population-land'' in non-central cities was more serious. At the same time, the scale of agricultural space and ecological space had been reduced. 2) Agricultural space was the main source of urban expansion, especially in the main agricultural producing areas. In addition, the conversion between ecological space and agricultural space in non-key and optimized development zones was particularly evident. 3) The trend of landscape fragmentation and heterogeneity in key and optimized development zones was obvious, and the position of agricultural space as a dominant type in the main agricultural product producing areas declined, but no significant change in the landscape pattern of ecological function reserve. 4) Land development policy had a significant impact on both the transformation gross scale and landscape pattern change, but the geographical conditions had a stronger impact on the landscape pattern change and social-economic factors had a more influence on the transformation gross scale.

Key words: three-zone space, Northeast China comprehensive revitalization, major function oriented zone, Optimal Parameters-based Geographical Detector Model

中图分类号:

F129.9

魏伟, 尹力. 东北地区“三区空间”格局演化特征及驱动机制[J]. 地理科学, 2023, 43(2): 324-336.

Wei Wei, Yin Li. Evolution characteristics and driving mechanism of spatial pattern of ''three-zone space'' in Northeast China[J]. SCIENTIA GEOGRAPHICA SINICA, 2023, 43(2): 324-336.

图/表 9

图1

表1

图2

图3

表2

图4

表3

图5

图6

参考文献 31

[1]	樊杰, 刘汉初, 王亚飞, 等. 东北现象再解析和东北振兴预判研究——对影响国土空间开发保护格局变化稳定因素的初探[J]. 地理科学, 2016, 36(10): 1445-1456.
	Fan Jie, Liu Hanchu, Wang Yafei et al. ''The Northeast China Phenomenon'' and prejudgment on economic revitalization in Northeast China: A primary research on stable factors to impact national spatial development and protection pattern[J]. Scientia Geographica Sinica, 2016, 36(10): 1445-1456.
[2]	刘涛, 彭荣熙, 卓云霞, 等. 2000—2020年中国人口分布格局演变及影响因素[J]. 地理学报, 2022, 77(2): 381-394.
	Liu Tao, Peng Rongxi, Zhuo Yunxia et al. China's changing population distribution and influencing factors: Insights from the 2020 census data. Acta Geographica Sinica, 2022, 77(2): 381-394.
[3]	田俊峰, 王彬燕, 王士君. 东北地区土地利用转型特征测度与机制探索[J]. 经济地理, 2020, 40(9): 184-195.
	Tian Junfeng, Wang Binyan, Wang Shijun. Land use transition in Northeast China: Features measurement and mechanism exploration. Economic Geography, 2020, 40(9): 184-195.
[4]	刘艳军, 于会胜, 刘德刚, 等. 东北地区建设用地开发强度格局演变的空间分异机制[J]. 地理学报, 2018, 73(5): 818-831.
	Liu Yanjun, Yu Huisheng, Liu Degang et al. Spatial differentiation mechanisms of the pattern evolution of construction land development intensity in Northeast China. Acta Geographica Sinica, 2018, 73(5): 818-831.
[5]	杨瑞珍, 陈印军. 东北地区耕地质量状况及变化态势分析[J]. 中国农业资源与区划, 2014, 35(6): 19-24.
	Yang Ruizhen, Chen Yinjun. Analysis of quality of cultivated and land change trend in northeast area. Chinese Journal of Agricultural Resources and Regional Planning, 2014, 35(6): 19-24.
[6]	唐呈瑞, 逯承鹏, 杨青, 等. 东北老工业区生态安全动态演变过程及驱动力[J]. 生态学报, 2017, 37(22): 7474-7482.
	Tang Chengrui, Lu Chengpeng, Yang Qing et al. Dynamic evolution and driving forces of ecological security in the traditional industrial area of northeastern China. Acta Ecologica Sinica, 2017, 37(22): 7474-7482.
[7]	周侃, 樊杰, 盛科荣. 国土空间管控的方法与途径[J]. 地理研究, 2019, 38(10): 2527-2540.
	Zhou Kan, Fan Jie, Sheng Kerong. Research on methods and approaches of spatial governances. Geographical Research, 2019, 38(10): 2527-2540.
[8]	樊杰. 地域功能−结构的空间组织途径——对国土空间规划实施主体功能区战略的讨论[J]. 地理研究, 2019, 38(10): 2373-2387.
	Fan Jie. Spatial organization pathway for territorial function-structure: Discussion on implementation of major function zoning strategy in territorial spatial planning. Geographical Research, 2019, 38(10): 2373-2387.
[9]	郭锐, 陈东, 樊杰. 国土空间规划体系与不同层级规划间的衔接[J]. 地理研究, 2019, 38(10): 2518-2526.
	Guo Rui, Chen Dong, Fan Jie. Territory spatial planning system and the convergence between different levels. Geographical Research, 2019, 38(10): 2518-2526.
[10]	孔江伟, 曾坚, 高梦溪. 生态文明视角下国土空间分类体系探讨[J]. 规划师, 2019, 35(23): 60-68. doi: 10.3969/j.issn.1006-0022.2019.23.009
	Kong Jiangwei, Zeng Jian, Gao Mengxi. Categorization of national space from the perspective of ecological civilization. Planners, 2019, 35(23): 60-68. doi: 10.3969/j.issn.1006-0022.2019.23.009
[11]	王亚飞, 樊杰, 周侃. 基于“双评价”集成的国土空间地域功能优化分区[J]. 地理研究, 2019, 38(10): 2415-2429.
	Wang Yafei, Fan Jie, Zhou Kan. Territorial function optimization regionalization based on the integration of ''Double Evaluation''. Geographical Research, 2019, 38(10): 2415-2429.
[12]	魏伟, 缪江波, 夏俊楠, 等. 湖北省长江经济带沿岸地区“三区空间”演化特征及机制分析(2010—2017)[J]. 经济地理, 2020, 40(2): 132-142.
	Wei Wei, Miao Jiangbo, Xia Junnan et al. Spatial-temporal evolution characteristics and mechanism of ''Three-Zone Space'' along the Yangtze River Economic Belt in Hubei Province from 2010 to 2017. Economic Geography, 2020, 40(2): 132-142.
[13]	魏伟, 尹力, 谢波, 等. 国土空间规划背景下黄河流域“三区空间”演化特征及机制[J]. 经济地理, 2022, 42(3): 44-55.
	Wei Wei, Yin Li, Xie Bo et al. Spatial-temporal evolution characteristics and mechanism of ''Three-function Space'' in the Yellow River Basin under the background of territorial spatial planning. Economic Geography, 2022, 42(3): 44-55.
[14]	张轲, 魏伟, 周婕, 等. 三江源地区“三区空间”时空演化及驱动机制分析(1992―2020年)[J]. 地球信息科学学报, 2022, 24(9): 1755-1770.
	Zhang Ke, Wei Wei, Zhou Jie et al. Spatial-temporal evolution characteristics and mechanism of ''Three-Function Space'' in the Three-Rivers Headwaters' Region from 1992 to 2020. Journal of Geo-information Science, 2022, 24(9): 1755-1770.
[15]	杨绪红, 金晓斌, 杨永可, 等. 1950—2020年东北地区林地时空变化特征分析[J]. 地理科学, 2022, 42(11): 1996-2005.
	Yang Xuhong, Jin Xiaobin, Yang Yongke et al. Spatial and temporal explicit analysis of forestland of Northeast China in 1950-2020. Scientia Geographica Sinica, 2022, 42(11): 1996-2005.
[16]	杜国明, 孙晓兵, 王介勇. 东北地区土地利用多功能性演化的时空格局[J]. 地理科学进展, 2016, 35(2): 232-244. doi: 10.18306/dlkxjz.2016.02.010
	Du Guoming, Sun Xiaobing, Wang Jieyong. Spatiotemporal patterns of multi-functionality of land use in Northeast China. Progress in Geography, 2016, 35(2): 232-244. doi: 10.18306/dlkxjz.2016.02.010
[17]	刘贺贺, 杨青山, 陈长瑶. 东北地区城市效率与开发程度的时空耦合[J]. 经济地理, 2015, 35(10): 64-72.
	Liu Hehe, Yang Qingshan, Chen Changyao. Spatio-temporal coupling research on urban efficiency and urban development degree in Northeast China. Economic Geography, 2015, 35(10): 64-72.
[18]	Xu J, Zhao J, Zhang H et al. Evolution of the process of urban spatial and temporal patterns and its influencing factors in Northeast China[J]. Journal of Urban Planning and Development, 2020, 146(4): 05020017. doi: 10.1061/(ASCE)UP.1943-5444.0000606
[19]	张士秀, 贾淑霞, 常亮, 等. 保护性耕作改善东北农田黑土土壤生物多样性及其生态功能[J]. 地理科学, 2022, 42(8): 1360-1369. doi: 10.13249/j.cnki.sgs.2022.08.004
	Zhang Shixiu, Jia Shuxia, Chang Liang et al. Conservation tillage improves soil biodiversity and its ecological function in the black soil region of Northeast China. Scientia Geographica Sinica, 2022, 42(8): 1360-1369. doi: 10.13249/j.cnki.sgs.2022.08.004
[20]	Mao D, He X, Wang Z et al. Diverse policies leading to contrasting impacts on land cover and ecosystem services in Northeast China[J]. Journal of Cleaner Production, 2019, 240: 117961. doi: 10.1016/j.jclepro.2019.117961
[21]	韩晓增, 李娜. 中国东北黑土地研究进展与展望[J]. 地理科学, 2018, 38(7): 1032-1041.
	Han Xiaozeng, Li Na. Research progress of black soil in Northeast China. Scientia Geographica Sinica, 2018, 38(7): 1032-1041.
[22]	梁爱珍, 张延, 陈学文, 等. 东北黑土区保护性耕作的发展现状与成效研究[J]. 地理科学, 2022, 42(8): 1325-1335. doi: 10.13249/j.cnki.sgs.2022.08.001
	Liang Aizhen, Zhang Yan, Chen Xuewen et al. Development and effects of conservation tillage in the black soil region of Northeast China. Scientia Geographica Sinica, 2022, 42(8): 1325-1335. doi: 10.13249/j.cnki.sgs.2022.08.001
[23]	刘大千, 刘世薇, 温鑫. 东北地区粮食生产结构时空演变[J]. 经济地理, 2019, 39(5): 163-170. doi: 10.15957/j.cnki.jjdl.2019.05.019
	Liu Daqian, Liu Shiwei, Wen Xin. Spatial-temporal evolution of grain production structure in Northeast China. Economic Geography, 2019, 39(5): 163-170. doi: 10.15957/j.cnki.jjdl.2019.05.019
[24]	李洁, 张远东, 顾峰雪, 等. 中国东北地区近50年净生态系统生产力的时空动态[J]. 生态学报, 2014, 34(6): 1490-1502.
	Li Jie, Zhang Yuandong, Gu Fengxue et al. Temporospatial variations in net ecosystem productivity in Northeast China since 1961. Acta Ecologica Sinica, 2014, 34(6): 1490-1502.
[25]	Hu L, Fan W, Yuan W et al. Spatiotemporal variation of vegetation productivity and its feedback to climate change in Northeast China over the last 30 Years[J]. Remote Sensing, 2021, 13(5): 951. doi: 10.3390/rs13050951
[26]	樊杰, 周侃, 孙威, 等. 人文–经济地理学在生态文明建设中的学科价值与学术创新[J]. 地理科学进展, 2013, 32(2): 147-160. doi: 10.11820/dlkxjz.2013.02.001
	Fan Jie, Zhou Kan, Sun Wei et al. Scientific values and research innovations of Human-economic Geography in construction of ecological civilization. Progress in Geography, 2013, 32(2): 147-160. doi: 10.11820/dlkxjz.2013.02.001
[27]	宋小青. 论土地利用转型的研究框架[J]. 地理学报, 2017, 72(3): 471-487. doi: 10.11821/dlxb201703009
	Song Xiaoqing. Discussion on land use transition research framework. Acta Geographica Sinica, 2017, 72(3): 471-487. doi: 10.11821/dlxb201703009
[28]	赵璐, 赵作权. 基于特征椭圆的中国经济空间分异研究[J]. 地理科学, 2014, 34(8): 979-986. doi: 10.13249/j.cnki.sgs.2014.08.015
	Zhao Lu, Zhao zuoquan. Projecting the spatial variation of economic based on the specific ellipses in China. Scientia Geographica Sinica, 2014, 34(8): 979-986. doi: 10.13249/j.cnki.sgs.2014.08.015
[29]	彭建, 王仰麟, 张源, 等. 土地利用分类对景观格局指数的影响[J]. 地理学报, 2006, 51(2): 157-168. doi: 10.3321/j.issn:0375-5444.2006.02.005
	Peng Jian, Wang Yanglin, Zhang Yuan et al. Research on the influence of land use classification on landscape metrics. Acta Geographica Sinica, 2006, 51(2): 157-168. doi: 10.3321/j.issn:0375-5444.2006.02.005
[30]	田俊峰, 王彬燕, 程利莎, 等. 政策主导下的区域土地利用转型过程与机制——以中国东北地区为例[J]. 地理研究, 2020, 39(4): 805-821. doi: 10.11821/dlyj020190257
	Tian Junfeng, Wang Binyan, Cheng Lisha et al. The process and mechanism of regional land use transition guided by policy: A case study of Northeast China. Geographical Research, 2020, 39(4): 805-821. doi: 10.11821/dlyj020190257
[31]	Song Y, Wang J, Ge Y et al. An optimal parameters-based geographical detector model enhances geographic characteristics of explanatory variables for spatial heterogeneity analysis: Cases with different types of spatial data[J]. GIScience&Remote Sensing, 2020, 57(5): 593-610.

“三区空间” 分类	GlobeLand30土地利用分类体系		地域主导功能类型
“三区空间” 分类	一级地类	二级地类	地域主导功能类型
资料来源：GlobeLand30产品说明书（ http://www.globallandcover.com/），经整理。
城镇空间	人造地表	由人工建造活动形成的地表，包括城镇等各类居民地、工矿、交通设施等，不包括建设用地内部大规模且连片分布的绿地和水体	城镇发展
农业空间	耕地	用于种植农作物的土地，包括水田、灌溉旱地、雨养旱地、菜地、牧草种植地、大棚用地、以种植农作物为主间有果树及其他经济乔木的土地，以及茶园、咖啡园等灌木类经济作物种植地	粮食安全
生态空间	森林	落叶阔叶林、常绿阔叶林、落叶针叶林、常绿针叶林、混交林以及疏林地等	生态安全
	草地	草原、林甸、稀树草原、荒漠草原以及城市人工草地等
	灌木地	山地灌丛、落叶和常绿灌丛以及荒漠地区覆盖度高于10%的荒漠灌丛
	湿地	内陆、湖泊沼泽、河流泛洪湿地、森林/灌木湿地、泥炭沼泽、盐沼
	水体	陆地范围液态水覆盖的区域，包括江河、湖泊、水库、坑塘、近海等
	裸地	荒漠、沙地、砾石地、裸岩、盐碱地等

主体功能区	转换阶段	交叉转换规模/km²
主体功能区	转换阶段	农业→城镇	农业→生态	生态→城镇	生态→农业	城镇→农业	城镇→生态
国家级重点开发区	2000—2010年	313.28	413.82	282.98	505.65	194.78	64.52
国家级重点开发区	2010—2020年	1 587.34	1 361.70	339.23	1 517.52	270.70	75.28
省级重点开发区	2000—2010年	626.55	1 616.54	176.95	1 011.88	447.83	121.01
省级重点开发区	2010—2020年	1 908.13	2 285.01	468.04	2 163.87	361.37	69.92
国家级农产品主产区	2000—2010年	925.17	3 077.70	225.22	2 522.41	864.69	168.97
国家级农产品主产区	2010—2020年	3 076.85	5 226.18	393.23	7 346.70	1 203.56	128.67
省级农产品主产区	2000—2010年	171.28	776.43	17.25	583.58	169.86	17.39
省级农产品主产区	2010—2020年	343.79	1 453.95	41.51	850.36	153.93	14.07
国家级重点生态功能区	2000—2010年	370.17	3 039.91	254.08	3 126.98	261.59	215.00
国家级重点生态功能区	2010—2020年	1 028.12	6 309.27	388.09	7 222.38	437.43	155.91
省级重点生态功能区	2000—2010年	62.95	607.28	25.58	620.88	50.35	7.49
省级重点生态功能区	2010—2020年	192.14	1 763.31	27.76	595.64	40.25	9.26
国家级优化开发区	2000—2010年	457.62	243.73	185.27	279.57	83.73	25.84
国家级优化开发区	2010—2020年	514.52	285.93	244.70	272.86	119.15	44.62
合计	2000—2010年	2 927.02	9 775.43	1 167.34	8 650.95	2 072.84	620.23
合计	2010—2020年	8 650.88	18 685.36	1 902.56	19 969.32	2 586.39	497.72

景观格局指数	转换类型规模
景观格局指数	农业→城镇	农业→生态	生态→城镇	生态→农业	城镇→农业	城镇→生态
注：：在10%置信水平下显著；：在5%置信水平下显著；**：在1%置信水平下显著；其他无显著相关性。
斑块数量	0.25^***	0.21^***	0.08	0.04	−0.08^**	0.10^**
最大斑块指数	−0.01^***	0.11*	−0.01^***	0.15^**	0.06	0.10
面积周长分维数	0.18^***	0.12^***	0.13^***	0.07^***	0.17^***	0.12^**
蔓延度	−0.12^***	0.07	−0.04^***	0.21^***	0.08	0.18^***
景观分离度	0.25^***	−0.01^**	0.36^***	−0.00^***	0.03	−0.03^*
分散指数	0.17^***	0.04	0.25^***	0.01^***	0.02	0.07^**
香农多样性指数	0.38^***	0.05	0.41^***	−0.03^***	0.03	−0.03^***
聚集度	−0.02^***	0.19^***	0.18^***	0.25^***	0.11^*	0.27^***
