基于InVEST模型的青海湖流域产水功能时空变化及驱动因素分析

doi:10.13249/j.cnki.sgs.2023.03.004

地理科学 ›› 2023, Vol. 43 ›› Issue (3): 411-422.doi: 10.13249/j.cnki.sgs.2023.03.004

• 青藏高原土地利用变化及其生态环境效应专栏 • 上一篇下一篇

基于InVEST模型的青海湖流域产水功能时空变化及驱动因素分析

刘美娟¹^,²(), 仲俊涛¹^,²(), 王蓓³, 米文宝⁴

1.青海师范大学地理科学学院，青海西宁 810008
2.青海省自然地理与环境过程重点实验室，青海西宁 810008
3.兰州大学资源环境学院，甘肃兰州 730000
4.宁夏大学地理科学与规划学院，宁夏银川 750021

收稿日期:2022-07-07 修回日期:2022-11-20 发布日期:2023-03-20 出版日期:2023-03-30
通讯作者: 仲俊涛。zhongjuntao88@163.com
作者简介:刘美娟（1996—），女，河南商丘人，硕士研究生，研究方向为遥感信息分析及地学应用。E-mail: l15937589665@163.com
基金资助:
国家自然科学基金项目(42001263);青海省自然科学基金项目(2022-ZJ-906)

Spatiotemporal change and driving factor analysis of the Qinghai Lake Basin based on InVEST model

Liu Meijuan¹^,²(), Zhong Juntao¹^,²(), Wang Bei³, Mi Wenbao⁴

1. School of Geography, Qinghai Normal University, Xining 810008, Qinghai, China
2. Key Laboratory of Natural Geography and Environmental Process of Qinghai Province, Xining 810008, Qinghai, China
3. School of Resources and Environment, Lanzhou University, Lanzhou 730000, Gansu, China
4. School of Geographic Science and Planning, Ningxia University, Yinchuan 750021, Ningxia, China

Received:2022-07-07 Revised:2022-11-20 Online:2023-03-20 Published:2023-03-30
Supported by:
National Natural Science Foundation of China(42001263);Natural Science Foundation of Qinghai Province(2022-ZJ-906)

摘要/Abstract

摘要：

以青海湖流域为研究区，基于1985—2020年8期土地利用图，结合地形、土壤和气象等数据，运用本地化修正后的InVEST模型及地理探测器方法，模拟流域产水服务、评估产水量空间分异特征、剖析其空间异质性归因。结果显示：青海湖流域1985—2020年产水量变化区间为11.68~81.52亿m³，变化趋势明显，表现为先下降后上升、再下降后上升的“W”型变化趋势；产水深度在空间分布上表现为东南高西北低，高值区均集中在海晏县内；垂直梯度上，产水能力随海拔增加而减弱；地理探测结果显示单因子对产水服务空间分异的解释能力存在显著差异，在不同分区中以气候类因子解释力最为显著；产水服务空间分异的影响程度由多因子共同决定，整体上以降水与实际蒸散量的交互作用解释力为主导因子。

关键词: InVEST模型, 地理探测器, 产水量, 青海湖流域

Abstract:

The function of water production is an important manifestation of ecosystem service. Water resources and ecosystem have two-way influence. Dynamic identification of spatial differentiation characteristics and driving factors of water production service is of great significance to adjusting infrastructure allocation, optimizing water resources management and protecting regional ecosystem. Taking the Qinghai Lake Basin as the research area, based on the land use of the 8th phase of 1985—2020, combined with terrain, soil and meteorological data, the localized modified InVEST model and geographical detector method were used to simulate the basin water production service, evaluate the spatial differentiation characteristics of water yield, and analyze its spatial heterogeneity attribution. The results show that the change range of water yield in the Qinghai Lake Basin from 1985 to 2020 is 1.168 to 8.152 billion m³. The change trend is obvious, it is the "W" type change trend of falling first and then rising, and then rising after falling; The spatial distribution of water production depth is high in southeast and low in northwest, High-value areas are all concentrated in Haiyan County; On a vertical gradient, Water production capacity decreases with increasing altitude; Geodetection results showed significant differences in the ability of single factorial to explain spatial differentiation of water production services, In different partitions, the explanatory force of climate factors is the most significant; the influence degree of spatial differentiation of water production service is determined by multiple factors, and the interaction explanatory force of precipitation and actual evapotranspiration is the dominant factor.

Key words: InVEST model, geographical detector, water yield, the Qinghai Lake Basin

中图分类号:

K901.2

刘美娟, 仲俊涛, 王蓓, 米文宝. 基于InVEST模型的青海湖流域产水功能时空变化及驱动因素分析[J]. 地理科学, 2023, 43(3): 411-422.

Liu Meijuan, Zhong Juntao, Wang Bei, Mi Wenbao. Spatiotemporal change and driving factor analysis of the Qinghai Lake Basin based on InVEST model[J]. SCIENTIA GEOGRAPHICA SINICA, 2023, 43(3): 411-422.

图/表 7

图1

表1

图2

图3

图4

图5

图6

参考文献 35

[1]	傅伯杰, 周国逸, 白永飞, 等. 中国主要陆地生态系统服务功能与生态安全[J]. 地球科学进展, 2009, 24(6): 571-576.
	Fu Bojie, Zhou Guoyi, Bai Yongfei et al. The main terrestrial ecosystem services and ecological security in China. Advances in Earth Science, 2009, 24(6): 571-576.
[2]	戴尔阜, 王亚慧. 横断山区产水服务空间异质性及归因分析[J]. 地理学报, 2020, 75(3): 607-619.
	Dai Erfu, Wang Yahui. Spatial heterogeneity and driving mechanisms of water yield service in the Hengduan Mountain region. Acta Geographica Sinica, 2020, 75(3): 607-619.
[3]	Unite Nations Environment Program. Millennium ecosystem assessment: Ecosystems and human well-being[M]. Washington, DC: Island Press, 2005.
[4]	Costanza R, D'arge R, Naeem S et al. The value of the world's ecosystem services and natural capital[J]. World Environment, 1997, 387(6630): 253-260.
[5]	郝梦雅, 任志远, 孙艺杰, 等. 关中盆地生态系统服务的权衡与协同关系动态分析. 地理研究, 2017, 36(3): 592-602.
	Hao Mengya, Ren Zhiyuan, Sun Yijie et al et al. The dynamic analysis of trade-off and synergy of ecosystem services in the Guanzhong Basin. Geographical Research, 2017, 36(3): 592-602.
[6]	李理, 赵芳, 朱连奇, 等. 淇河流域生态系统服务权衡及空间分异机制的地理探测[J]. 生态学报, 2021, 41(19): 7568-7578.
	Li Li, Zhao Fang, Zhu Lianqi et al. Geographical detection of ecosystem services trade-offs and their spatial variation mechanism in Qihe River Basin. Acta Ecologica Sinica, 2021, 41(19): 7568-7578.
[7]	张文静, 孙小银, 周俊. 南四湖流域关键生态系统服务的时空权衡关系[J]. 生态学报, 2021, 41(20): 8003-8015.
	Zhang Wenjing, Sun Xiaoyin, Zhou Jun. Spatio-temporal dynamics of tradeoffs between crucial ecosystem services in Nansihu Lake Basin. Acta Ecologica Sinica, 2021, 41(20): 8003-8015.
[8]	Ajaz Ahmed M A, Abd-Elrahman A, Escobedo F J et al. Spatially-explicit modeling of multi-scale drivers of aboveground forest biomass and water yield in watersheds of the Southeastern United States[J]. Journal of Environmental Management, 2017, 199: 158-171.
[9]	张灿强, 李文华, 张彪, 等. 基于InVEST模型的西苕溪流域产水量分析[J]. Journal of Resources and Ecology, 2012, 3(1): 50-54. doi: 10.5814/j.issn.1674-764x.2012.01.008
	Zhang Canqiang, Li Wenhua, Zhang Biao et al. Water yield of Xitiaoxi River Basin based on InVEST Modeling. Journal of Resources and Ecology, 2012, 3(1): 50-54. doi: 10.5814/j.issn.1674-764x.2012.01.008
[10]	文一惠, 刘桂环, 吴瑞. 基于官厅水库流域产水和水质净化服务时空变化的生态补偿机制研究[J]. Journal of Resources and Ecology, 2018, 9(4): 416-425. doi: 10.5814/j.issn.1674-764x.2018.04.009
	Wen Yihui, Liu Guihuan, Wu Rui. Eco-compensation in Guanting Reservoir watershed based on spatiotemporal variations of water yield and purification services. Journal of Resources and Ecology, 2018, 9(4): 416-425. doi: 10.5814/j.issn.1674-764x.2018.04.009
[11]	杨洁, 谢保鹏, 张德罡. 基于InVEST模型的黄河流域产水量时空变化及其对降水和土地利用变化的响应[J]. 应用生态学报, 2020, 31(8): 2731-2739.
	Yang Jie, Xie Baopeng, Zhang Degang. Spatio-temporal variation of water yield and its response to precipitation and land use change in the Yellow River Basin based on InVEST model. Chinese Journal of Applied Ecology, 2020, 31(8): 2731-2739.
[12]	林峰, 陈兴伟, 姚文艺, 等. 基于SWAT模型的森林分布不连续流域水源涵养量多时间尺度分析[J]. 地理学报, 2020, 75(5): 1065-1078. doi: 10.11821/dlxb202005013
	Lin Feng, Chen Xingwei, Yao Wenyi et al. Multi-time scale analysis of water conservation in a discontinuous forest watershed based on SWAT model. Acta Geographica Sinica, 2020, 75(5): 1065-1078. doi: 10.11821/dlxb202005013
[13]	夏瑞, 张永勇, 张远, 等. 基于分布式水文模型的流域水源涵养功能计算[C]//. 2018中国环境科学学会科学技术年会论文集(第二卷). 2018: 1087-1094.
	Xia Rui, Zhang Wenyong, Zhang Yuan et al. Calculation of the watershed water conservation function based on the distributed TerrainLab model. Proceedings of 2018 Annual Meeting of Chinese Society for Environmental Sciences (Volume 2), 2018: 1087-1094.
[14]	刘娅, 朱文博, 韩雅, 等. 基于SOFM神经网络的京津冀地区水源涵养功能分区[J]. 环境科学研究, 2015, 28(3): 369-376.
	Liu Ya, Zhu Wenbo, Han Ya et al. Regionalization of water conservation function of Beijing-Tianjin-Hebei Area based on SOFM neural network. Research of Environmental Sciences, 2015, 28(3): 369-376.
[15]	孙小银, 郭洪伟, 廉丽姝, 等. 南四湖流域产水量空间格局与驱动因素分析[J]. 自然资源学报, 2017, 32(4): 669-679.
	Sun Xiaoyin, Guo Hongwei, Lian Lishu et al. The spatial pattern of wateryield and its driving factors in Nansi Lake Basin. Journal of Natural Resources, 2017, 32(4): 669-679.
[16]	殷格兰, 邵景安, 郭跃, 等. 林地资源变化对森林生态系统服务功能的影响——以南水北调核心水源地淅川县为例[J]. 生态学报, 2017, 37(20): 6973-6985.
	Yin Gelan, Shao Jing'an, Guo Yue et al. Effects of forest resource changes on ecosystem function: A case study of Xichuan County, the main source of water for south-to-north water transfer in China. Acta Ecologica Sinica, 2017, 37(20): 6973-6985.
[17]	高月明, 吴文俊, 蒋洪强, 等. 基于全球陆地生态系统的水源涵养服务价值时空变化分析[J]. 环境科学研究, 2021, 34(11): 2696-2705.
	Gao Yueming, Wu Wenjun, Jiang Hongqiang et al. Spatiotemporal changes of water conservation services value based on global terrestrial ecosystem. Research of Environmental Sciences, 2021, 34(11): 2696-2705.
[18]	崔旺来, 奚恒辉, 蔡莉, 等. 基于NDVI的中国海岛县生态系统服务价值时空变化[J]. 经济地理, 2021, 41(9): 184-192+224.
	Cui Wanglai, Xi Henghui, Cai Li et al. Spatial and temporal change of ecosystem service value in China's island counties base on NDVI. Economic Geocraphy, 2021, 41(9): 184-192+224.
[19]	陈姗姗, 刘康, 包玉斌, 等. 商洛市水源涵养服务功能空间格局与影响因素[J]. 地理科学, 2016, 36(10): 1546-1554.
	Chen Shanshan, Liu Kang, Bao Yubin et al. Spatial pattern and influencing factors of water conservation service function in Shangluo City. Scientia Geographica Sinica, 2016, 36(10): 1546-1554.
[20]	吕乐婷, 任甜甜, 孙才志, 等. 1980—2016年三江源国家公园水源供给及水源涵养功能时空变化研究[J]. 生态学报, 2020, 40(3): 993-1003.
	Lyu Leting, Ren Tiantia, Sun Caizhi et al. Spatial and temporal changes of water supply and water conservation function in Sanjiangyuan National Park from 1980 to 2016. Acta Ecologica Sinica, 2020, 40(3): 993-1003.
[21]	王玉纯, 赵军, 付杰文, 等. 石羊河流域水源涵养功能定量评估及空间差异[J]. 生态学报, 2018, 38(13): 4637-4648.
	Wang Yuchun, Zhao Jun, Fu Jiewen et al. Quantitative assessment of water conservation function and spatial pattern in Shiyang River basin. Acta Ecologica Sinica, 2018, 38(13): 4637-4648.
[22]	王鹏, 刘小鹏, 王亚娟, 等. 黄土丘陵沟壑区生态移民过程及其生态系统服务价值评价——以宁夏海原县为例[J]. 干旱区地理, 2019, 42(2): 433-443.
	Wang Peng, Liu Xiaopeng, Wang Yajuan et al. Ecological migration process and the evaluation of its ecosystem service value in loess hilly and gully region: A case study of Haiyuan County, Ningxia. Arid Land Geography, 2019, 42(2): 433-443.
[23]	苏常红, 王亚璐. 汾河上游流域生态系统服务变化及驱动因素[J]. 生态学报, 2018, 38(22): 7886-7898.
	Su Changhong, Wang Yalu. Evolution of ecosystem services and its driving factors in the upper reaches of the Fenhe River watershed, China. Acta Ecologica Sinica, 2018, 38(22): 7886-7898.
[24]	张琨, 吕一河, 傅伯杰, 等. 黄土高原植被覆盖变化对生态系统服务影响及其阈值[J]. 地理学报, 2020, 75(5): 949-960. doi: 10.11821/dlxb202005005
	Zhang Kun, Lyu Yihe, Fu Bojie et al. The effects of vegetation coverage changes on ecosystem service and their threshold in the Loess Plateau. Acta Geographica Sinica, 2020, 75(5): 949-960. doi: 10.11821/dlxb202005005
[25]	李小雁, 许何也, 马育军, 等. 青海湖流域土地利用/覆被变化研究[J]. 自然资源学报, 2008(2): 285-296. doi: 10.3321/j.issn:1000-3037.2008.02.013
	Li Xiaoyan, Xu Heye, Ma Yujun et al. Land use/cover change in the Qinghai Lake Watershed. Journal of Natural Resources, 2008(2): 285-296. doi: 10.3321/j.issn:1000-3037.2008.02.013
[26]	崔步礼, 李小雁, 姜广辉, 等. 基于DEM的山地丘陵区土地利用/覆被研究——以青海湖流域为例[J]. 自然资源学报, 2011, 26(5): 871-880.
	Cui Buli, Li Xiaoyan, Jiang Guanghui et al. Study on land use/cover in mountain area based on the DEM—Taking the Qinghai Lake Basin as an example. Journal of Natural Resources, 2011, 26(5): 871-880.
[27]	江波, 张路, 欧阳志云. 青海湖湿地生态系统服务价值评估[J]. 应用生态学报, 2015, 26(10): 3137-3144.
	Jiang Bo, Zhang Lu, Ouyang Zhiyun. Ecosystem services valuation of Qinghai Lake. Chinese Journal of Applied Ecology, 2015, 26(10): 3137-3144.
[28]	高黎明, 张乐乐. 青海湖流域植被盖度时空变化研究[J]. 地球信息科学报, 2019, 21(9): 1318-1329.
	Gao Liming, Zhang Lele. Spatialtemporal dynamics of the vegetation coverage in Qinghai Lake basin. Journal of Geo-information Science, 2019, 21(9): 1318-1329.
[29]	李小雁. 青海湖流域湿地修复与生物多样性保护[M]. 北京: 科学出版社, 2016.
	Li Xiaoyan. Wetland restoration and biodiversity conservation in the Qinghai Lake Basin. Beijing: Science Press, 2016.
[30]	王劲峰, 徐成东. 地理探测器: 原理与展望[J]. 地理学报, 2017, 72(1): 116-134. doi: 10.11821/dlxb201701010
	Wang Jinfeng, Xu Chengdong. Geodetector: Principle and prospective. Acta Geographica Sinica, 2017, 72(1): 116-134. doi: 10.11821/dlxb201701010
[31]	杨显明, 张鸽, 加壮壮, 等. 全球气候变化背景下青海湖岸线变化及其对社会经济影响[J]. 高原科学研究, 2021, 5(4): 1-9+15. doi: 10.16249/j.cnki.2096-4617.2021.04.001
	Yang Xianming, Zhang Ge, Jia Zhuangzhuang et al. Study on the shoreline evolution of Qinghai Lake and its socio-economic impact under the background of global climate change. Plateau Science Research, 2021, 5(4): 1-9+15. doi: 10.16249/j.cnki.2096-4617.2021.04.001
[32]	李林, 朱西德, 王振宇, 等. 近42 a来青海湖水位变化的影响因子及其趋势预测[J]. 中国沙漠, 2005(5): 689-696. doi: 10.3321/j.issn:1000-694X.2005.05.012
	Li Lin, Zhu Xide, Wang Zhenyu et al. Impacting factors and changing tendency of water level in Qinghai Lake in recent 42 years. Journal of Desert Research, 2005(5): 689-696. doi: 10.3321/j.issn:1000-694X.2005.05.012
[33]	李林, 张国胜, 汪青春, 等. 青海地表水资源的变化及影响因子[J]. 气象, 1999(8): 11-15. doi: 10.3969/j.issn.1000-0526.1999.08.003
	Li Lin, Zhang Guosheng, Wang Qingchun et al. Variation of surface water resource in Qinghai Province and its influent factors. Meteorological Monthly, 1999(8): 11-15. doi: 10.3969/j.issn.1000-0526.1999.08.003
[34]	Delphin S, Escobedo F J, Abd-Elrahman A et al. Urbanization as a land use change driver of forest ecosystem services[J]. Land Use Policy, 2016, 54: 188-199. doi: 10.1016/j.landusepol.2016.02.006
[35]	Su S, Xiao R, Jiang Z L et al. Characterizing landscape pattern and ecosystem service value changes for urbanization impacts at an eco-regional scale[J]. Applied Geography, 2012, 34: 295-305. doi: 10.1016/j.apgeog.2011.12.001

类型	指标	数据类型	类型	指标	数据类型
气候	年均温	连续	土地利用	土地利用类型	离散
	年总降水量	连续		香农多样性指数	连续
	年实际蒸散量	连续		蔓延度指数	连续
地形地貌	高程	连续		有效粒度尺寸	连续
地形地貌	坡度	连续		耕地	连续
土壤	土壤类型	离散		林草地	连续
植被	归一化植被指数	连续		水体及湿地	连续
				冰雪地	连续
