城市住宅空间分布模拟研究

doi:10.13249/j.cnki.sgs.2020.01.012

地理科学 ›› 2020, Vol. 40 ›› Issue (1): 97-102.doi: 10.13249/j.cnki.sgs.2020.01.012

城市住宅空间分布模拟研究

牛方曲^1,², 王芳³()

^1. 中国科学院地理科学与资源研究所/中国科学院区域可持续发展分析与模拟重点实验室,北京 100101
^2. 中国西南地缘环境与边疆发展协同创新中心,云南昆明 650500
^3. 内蒙古大学公共管理学院,内蒙古呼和浩特 010070

收稿日期:2019-01-21 修回日期:2019-04-10 出版日期:2020-01-10 发布日期:2020-03-17
通讯作者: 王芳 E-mail:wangf741@163.com
作者简介:牛方曲（1979-）,男,安徽淮南人,博士,副研究员,主要从事区域、城市发展模拟分析研究。E-mail: niufq@lreis.ac.cn
基金资助:
中国科学院战略性先导科技专项（A类）(XDA19040402);国家自然科学基金项目(41801149);国家重点研发计划(2016YFC0503506);中国科学院区域可持续发展分析与模拟重点实验室开放基金(KF2018-05);内蒙古自治区高等学校“青年科技英才支持计划”(NJTY-20-B09)

Modelling Urban Housing Development and A Beijing Case Study

Niu Fangqu^1,², Wang Fang³()

^1. Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences/Key Laboratory of Regional Sustainable Development Modeling, Chinese Academy of Sciences, Beijing 100101, China
^2. Collaborative Innovation Center for Geopolitical Setting of Southwest China and Borderland Development, Kunming 650500, Yunnan, China
^3. School of Public Management, Inner Mongolia University, Hohhot 010070, Inner Mongolia,China

Received:2019-01-21 Revised:2019-04-10 Online:2020-01-10 Published:2020-03-17
Contact: Wang Fang E-mail:wangf741@163.com
Supported by:
Strategic Priority Research Program of the Chinese Academy of Sciences(XDA19040402);National Natural Science Foundation of China(41801149);National Key Research and Development Program(2016YFC0503506);Key Laboratory of Regional Sustainable Development Modeling, Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences(KF2018-05);Young Talents of Science and Technology in Universities of Inner Mongolia(NJTY-20-B09)

摘要/Abstract

摘要：

构建城市住宅开发模拟模型（FDM）,并以北京市为案例,模拟城市住宅规模时空演化。FDM综合考虑了政策限制和市场规律模拟开发商决策行为,分4个步骤预测城市住宅面积的空间分布格局演变过程： ①假设无政府限制条件、开发商追求最大利润的前提下,预测城市住宅开发总面积;②在政府限制条件下,对上述预测结果予以修正,预测实际住宅开发总面积;③根据各区块的利润以及政策许可对住宅开发面积进行空间配置;④确定各个区块的建筑规模总量。北京案例表明,延续近几年住宅开发模式,未来住宅规模的增长主要发生在五环外,尤其是五环到六环的区域,而中心城区的开发程度较弱。一方面是由于城市中心地带已经被高度开发,土地利用空间较小;另一方面与政府疏解中心人口、缓解交通阻塞的政策有关。FDM模型的开发为城市土地利用政策的制定提供了良好的模拟分析工具,为城市空间模拟分析研究提供方法上的参考。

关键词: 城市空间, 住宅分布, 住宅规模空间演化模型, 房租分布

Abstract:

Land use development and transportation development are important drivers of urban space policy. Land use development and management usually manifest as control over real estate development. The real estate provides a basic place for urban economic and social activities, and the scale of floorspace is an important indicator affecting urban economic activities. For this reason, floorspace development (real estate development) is arguably the most important indicator to measure the spatial distribution of activities. This study develops a four-step Floorspace Development Model (FDM) to forecast the housing floorspace distribution. Firstly, it estimates the total housing floorspace developed in a period by assuming that developers would maximize their profits under no constraints from the government. Secondly, the model estimates the constrained total housing floorspace development based on government permits. Thirdly, the model allocates the total floorspace in proportion among zones based on the profitability of alternative locations and the permits of each zone. Finally, it determines the total building size of each zone. A case study of Beijing is given subsequently. It shows that given the continuation of the past policies into the future, more and more housing floorspace would happen outside the urban area, especially between the 5th and 6th ring roads, while the degree of development in the central urban area is weak. The FDM model is able to forecast the developers’ decisions based on market rules and government policies including that where a certain type of floorspace is developed and how much is permissible. The research integrates policy restrictions with market laws, realizes simulation prediction of building development, provides scenario testing tools for related policies, and provides methodological references for urban spatial simulation analysis.

Key words: urban space, housing floorspace distribution, floorspace development model (FDM), rent distribution

中图分类号:

牛方曲, 王芳. 城市住宅空间分布模拟研究[J]. 地理科学, 2020, 40(1): 97-102.

Niu Fangqu, Wang Fang. Modelling Urban Housing Development and A Beijing Case Study[J]. SCIENTIA GEOGRAPHICA SINICA, 2020, 40(1): 97-102.

图/表 4

参考文献 30

[1]	顾朝林, 庞海峰 . 建国以来国家城市化空间过程研究[J]. 地理科学, 2009,29(1):10-14.
	[ Gu Chaolin, Pang Haifeng . Evolution of Chinese urbanization spaces: Kernel spatial approach. Scientia Geographical Sinica, 2009,29(1):10-14.]
[2]	Liu Z, He C, Zhang Q et al. Extracting they dynamics of urban expansion in China using DMSP-OLS nighttime light data from 1992 to 2008[J]. Landscape and Urban Planning, 2012,106(1):62-72.
[3]	Li J, Deng X Z, Karen C Seto . Multi-level modeling of urban expansion and cultivated land conversion for urban hotspot counties in China[J]. Land Scape and Urban Planning, 2012,108:131-139.
[4]	Wegener M . Overview of land-use transport models[M]// Hensher D A et al. Transport Geography and spatial systems.Oxford: Elsevier, 2004.
[5]	Simmonds D C . The design of the DELTA land-use modelling package[J]. Environment and Planning B: Planning and Design, 1999,26(5):665-684.
[6]	Peiser R . Real estate development[J]. International Encyclopedia of the Social & Behavioral Sciences, 2015: 12-19.
[7]	牛方曲, 王志强, 胡月 , 等. 基于经济社会活动视角的城市空间演化过程模型[J]. 地理科学进展, 2015,34(1):30-37.
	[ Niu Fangqu, Wang Zhiqiang, Hu Yue et al. A model of urban spatial evolution process based on economic and social activities. Progress in Geography, 2015,34(1):30-37.]
[8]	Alonso W. Location and land use: Toward a general theory of land rent[M]. Cambridge, MA: Harvard University Press, 1964.
[9]	Wingo L. Transportation and urban land[M]. Washington: The John Hopkins University Press, 1967.
[10]	Kain J F . The journey-to-work as a determinant of residential location[J]. Papers of the Regional Science Association, 1962,9(1), 137-160.
[11]	CLark C. Population growth and land use[M]. New York: St Martin’s Press, 1967.
[12]	Eechnique M, Crowther D, Lindsay W . A spatial model of urban stock and activity[J]. Regional Studies, 1969,3(3):281-312.
[13]	Echenique M . Land use/transport models and economic assessment[J]. Research in Transportation Economics, 2011,31(1):45-54.
[14]	Echenique M, Hargreaves A, Mitchell G et al. Growing cities sustainably[J]. Journal of the American Planning Association, 2012,78(2):121-137.
[15]	Justin S C, Roger L M . A bi-level model of the relationship between transport and residential location[J]. Transportation Research Part B: Methodological, 2006,40(2):123-146.
[16]	Gao J L, Wei Y D, Chen W et al. Economic transition and urban land expansion in provincial China[J]. Habitat International, 2014,44:461-473.
[17]	Liao H F, Wei Y H D . Modeling determinants of urban growth in Dongguan, China: A spatial logistic approach[J]. Stochastic Environmental Research and Risk Assessment, 2014,28(4):801-816.
[18]	Long Y, Han H Y, Lai S K et al. Urban growth boundaries of the Beijing Metropolitan Area: Comparison of simulation and artwork[J]. Cities, 2013,31(2):337-348.
[19]	王芳, 高晓路, 颜秉秋 . 基于住宅价格的北京城市空间结构研究[J]. 地理科学进展, 2014,33(10):1322-1331.
	[ Wang Fang, Gao Xiaolu, Yan Bingqiu . Research on urban spatial structure in Beijing based on housing prices. Progress in Geography, 2014,33(10):1322-1331.]
[20]	董冠鹏, 张文忠, 武文杰 , 等. 北京城市住宅土地市场空间异质性模拟与预测[J]. 地理学报, 2011,66(6):750-760.
	[ Dong Guanpeng, Zhang Wenzhong, Wu Wenjie et al. Spatial heterogeneity in determinants of residential land price: Simulation and prediction. Acta Geographica Sinica, 2011,66(6):750-760.]
[21]	李少英, 黎夏, 刘小平 , 等. 基于多智能体的就业与居住空间演化多情景模拟——快速工业化区域研究[J]. 地理学报, 2013,68(10):1389-1400.
	[ Li Shaoying, Li Xia, Liu Xiaoping et al. Multi-scenario simulations on the interactions of jobs-housing based on agent-based model. Acta Geographica Sinica, 2013,68(10):1389-1400.]
[22]	湛东升, 孟斌 . 基于社会属性的北京市居民居住与就业空间集聚特征[J]. 地理学报, 2013,68(12):1607-1618.
	[ Zhan Dongsheng, Meng Bin . Spatial clustering analysis of residential and employment distribution in Beijing based on their social characteristics. Journal of geographical sciences, 2013,68(12):1607-1618.]
[23]	Yue W Z, Liu Y, Fan P L . Polycentric urban development: The case of Hangzhou[J]. Environment and Planning A, 2010,42(3):563-577.
[24]	牛方曲, 刘卫东, 冯建喜 . 基于家庭区位需求的城市住房价格模拟分析[J]. 地理学报, 2016,71(10):1731-1740.
	[ Niu Fangqu, Liu Weidong, Feng Jianxi . Modeling urban housing price: The perspective of household activity demand. Acta Geographica Sinica, 2016,71(10):1731-1740.]
[25]	Lowry I S . A model of metropolis RM-4035-RC[M]. Santa Monica CA: Rand Corp, 1964.
[26]	Simmonds D, Feldman O . Alternative approaches to spatial modelling[J]. Research in Transportation Economics, 2011,31:2-11.
[27]	牛方曲, 王芳 . 城市土地利用-交通集成模型的构建与应用[J]. 地理学报, 2018,73(2):380-392.
	[ Niu Fangqu, Wang Fang . Modelling urban spatial impacts of land-use/transport policies. Acta Geographica Sinica, 2018,73(2):380-392.]
[28]	北京国土资源局. 土地出让公告[N/OL]. http://bjtd.bjgtj.gov.cn/default.aspxBjgtj.gov.cn. 2014-10-15.
	[ Beijing Land Resources Bureau. Land transaction bulletin. 2014-10-15. http://bjtd.bjgtj.gov.cn/default.aspxBjgtj.gov.cn.]
[29]	北京统计局. 北京人口和就业统计年鉴[M]. 北京: 中国统计出版社, 2013.
	[ Beijing Statistical Bureau. Beijing population and employment statistical yearbook. Beijing: China Statistics Press, 2013.]
[30]	国家统计局. 第六次全国人口普查数据[M]. 北京: 中国统计出版社, 2010.
	[ National Bureau of Statistics of China. China sixth census data. Beijing: China Statistics Press, 2010.]
