基于RUSLE的卧虎山水库流域土壤侵蚀特征分析

doi:10.13249/j.cnki.sgs.2018.04.015

地理科学 ›› 2018, Vol. 38 ›› Issue (4): 610-617.doi: 10.13249/j.cnki.sgs.2018.04.015

基于RUSLE的卧虎山水库流域土壤侵蚀特征分析

胡刚^1,²(), 宋慧¹, 石星军³, 张明礼⁴, 刘修军¹, 张绪良¹

1.青岛大学旅游与地理科学学院,山东青岛 266071
2.山东省水土保持与环境保育重点实验室,山东临沂 276000
3.青岛大学物理科学学院,山东青岛 266071
4.南京师范大学地理科学学院,江苏南京 210046

收稿日期:2017-04-27 修回日期:2017-08-22 出版日期:2018-04-20 发布日期:2018-04-20
作者简介:
作者简介：胡刚（1976-）,男,山东滨州人,博士,副教授,主要从事土壤侵蚀、环境演变、水土资源利用与3S应用研究。E-mail: geo_hug@126.com
基金资助:
国家自然科学基金面上项目（41173094）、山东省水土保持与环境保育重点实验室开放基金（STKF201602）资助

Soil Erosion Characteristics Based on RUSLE in the Wohushan Reservoir Watershed

Gang Hu^1,²(), Hui Song¹, Xingjun Shi³, Mingli Zhang⁴, Xiujun Liu¹, Xuliang Zhang¹

1. School of Tourism and Geography Sciences, Qingdao 266071, Shandong, China
2. Shandong Provincial Key Laboratory of Water and Soil Conservation and Environmental Protection, Linyi 276000, Shandong,China
3. College of Physics, Qingdao University, Qingdao 266071, Shandong, China
4. School of Geography Science, Nanjing Normal University, Nanjing 210046, Jiangsu, China

Received:2017-04-27 Revised:2017-08-22 Online:2018-04-20 Published:2018-04-20
Supported by:
[National Natural Science Foundation of China (41173094) , Open Foundation of Shandong Provincial Key Laboratory of Water and Soil Conservation and Environmental Protection(STKF201602).]

摘要/Abstract

摘要：

通过RUSLE模型对卧虎山水库流域土壤侵蚀进行全面评价验证和总结。结果表明：① 水库流域平均侵蚀模数为462 t/(km²·a),该数值与通过水库淤积等资料推算评估结果基本一致,表明本研究结果具有较高的可信度;水库流域年均侵蚀量达到2.6×10⁶t,其中高于容许土壤流失量的面积为176 km²,占到流域总面积的31.51%。从不同侵蚀级别来看,占流域面积27.77%的轻度侵蚀,对流域侵蚀总量的贡献率为54.64%; 面积占比3.74%的中度及以上侵蚀,侵蚀量贡献率达到30.94%。② 流域内土壤侵蚀空间差异较大,回归分析发现地形因子是导致各子流域土壤侵蚀模数差异的主要因素;就土地利用类型而言,旱地和农村居民点是流域内的主要侵蚀土地利用类型;流域内土壤侵蚀模数随着坡度增加呈现相应增大趋势,8°~25°坡度段面积比例不仅最大,而且侵蚀量占比最高,是水库流域的主要侵蚀坡度段。

关键词: RUSLE, 水库淤积, 土壤侵蚀, 卧虎山水库

Abstract:

Soil erosion of the Wohushan Reservoir was calculated based on RUSLE(Revised Universal Soil Loss Equation). The calculated mean soil erosion modulus is 462 t/ km²·a, which is consistent with the data estimated by the deposition from both reservoir and main watercourses. This indicated that the calculation is accurate and the result is reliable. The annual average soil erosion amount is 2.6×10⁶t. According to standards for classification and gradation of soil erosion issued by the ministry of water resources of PR China, the area above soil loss tolerance is about 176 km², which amounts to 31.51% of total area of the Wohushan Reservoir. With reference to the erosion intensity, the slight erosion area occupies 27.77% of total area in reservoir watershed, but contribute 54.64% of the total load of soil erosion in the Wohushan Reservoir Watershed. while the moderate and above intensity erosion area only occupies 3.74% of the study area and contributes 30.94% of the total load of soil erosion. It was found that there are large spatial differences for soil erosion intensity in the reservoir watershed. Based on hydrological module in arcgis platform, we got 11 sub-basins. Their soil erosion intensity were found to have a consistent change with their geomorphology factors, which indicates that slope length and slope gradient should be the main factors leading to the difference of soil erosion modulus in each sub-basins. Compared the ratio of erosion amount with that of different land uses, it’s found that dry land and rural settlements are the main land use types which suffered serious erosion. The soil erosion intensity increases with the increase of slope gradient. The main erosion slope ranges from 8° to 25°, in which the percentage of area is not only the largest, but also the erosion rate is the highest.

Key words: RUSLE, reservoir sedimentation, soil erosion, the Wohushan Reservoir

中图分类号:

S157/TP306

胡刚, 宋慧, 石星军, 张明礼, 刘修军, 张绪良. 基于RUSLE的卧虎山水库流域土壤侵蚀特征分析[J]. 地理科学, 2018, 38(4): 610-617.

Gang Hu, Hui Song, Xingjun Shi, Mingli Zhang, Xiujun Liu, Xuliang Zhang. Soil Erosion Characteristics Based on RUSLE in the Wohushan Reservoir Watershed[J]. SCIENTIA GEOGRAPHICA SINICA, 2018, 38(4): 610-617.

图/表 7

表1

表2

图1

表3

图2

图3

图4

参考文献 30

[21]	Renard K G, Foster G R, Weesies G A et al. Predicting soil erosion by water: a guide to conservation planning with the revised universal soil loss equation (RUSLE)[M]. Agricultural Handbook 703. Washington, D.C.: US Department of Agriculture, 1997.
[22]	冯强,赵文武. USLE/RUSLE中植被覆盖与管理因子研究进展[J]. 生态学报,2014,34(16):4461-4472. doi: 10.5846/stxb201306151710
	[Feng Qiang, Zhao Wenwu. Study on cover-management factor in USLE and RUSLE: a review.Acta Ecologica Sinica, 2014,34(16):4461-4472.] doi: 10.5846/stxb201306151710
[23]	傅世锋,查轩. 基于GIS和USLE的东圳库区土壤侵蚀量预测研究[J]. 地球信息科学, 2008,10(3): 390-395.
	[Fu Shifeng, Zha Xuan. Study on predicting soil erosion in Dongzhen watersed based on GIS and USLE. Geo-information Science,2008,10(3): 390-395.]
[24]	王文娟,张树文,李颖,等. 基于GIS和USLE的三江平原土壤侵蚀定量评价[J]. 干旱区资源与环境, 2008, 22(9): 112-117. doi: 10.3969/j.issn.1003-7578.2008.09.022
	[Wang Wenjuan, Zhang Shuwen, Li Ying et al. Quantitative assessment of soil erosion in Sanjiang Plain based on GIS and USLE.Journal of Arid Land Resources and Environment, 2008, 22(9): 112-117.] doi: 10.3969/j.issn.1003-7578.2008.09.022
[25]	黄金良,洪华生,张珞平,等. 基于GIS和USLE的九龙江流域土壤侵蚀量预测研究[J]. 水土保持学报, 2004, 18(5): 75-79. doi: 10.3321/j.issn:1009-2242.2004.05.019
	[Huang Jinliang, Hong Huasheng, Zhang Luoping et al. Study on predicting soil erosion in Jiulong River watershed based on GIS and USLE.Journal of Soil and Water Conservation,2004, 18(5): 75-79.] doi: 10.3321/j.issn:1009-2242.2004.05.019
[26]	张雪花,侯文志,王宁. 东北黑土区土壤侵蚀模型中植被因子C值的研究[J]. 农业环境科学学报, 2006,25(3): 797-801.
	[Zhang Xuehua, Hou Wenzhi, Wang Ning. C-value in the model of soil erosion in black earth area in the Northeastern China. Journal of Agro-Environment Science,2006,25(3): 797-801.]
[27]	齐述华,蒋梅鑫,于秀波. 基于遥感和ULSE模型评价1995-2005年江西土壤侵蚀[J]. 中国环境科学,2011,31(7): 1197-1203.
	[Qi Shuhua, Jiang Meixin, Yu Xiubo. Evaluating soil erosion in Jiangxi Province with USLE model and remote sensing technology during 1995-2005. China Environment Science, 2011,31(7): 1197-1203.]
[28]	王绍江,张桂茹,胡济生,等. 济南市南部山丘区土壤侵蚀模数测算与分析[J]. 山东水利科技,1997(3):33-36.
	[Wang Shaojiang, Zhang Guiru, Hu Jisheng et al. Estimation and analysis of soil erosion modulus in the hilly area of Southern Jinan. Shandong. Water Conservancy Science and Technology,1997(3): 33-36.]
[29]	中华人民共和国水利部. 土壤侵蚀分类分级标准(SL 190-2007)[S]. 北京:中国水利水电出版社,2008.
[1]	Wischmeier W H, Smith D D. Predicting rainfall-erosion losses from cropland east of the Rocky Mountains-guide for selection of practices for soil and water conservation[M].Washington, D C: Agricultural Research Service, U.S. Dept of Agriculture in cooperation with Purdue Agricultural Experiment Station 1965.
[2]	Wischmeier W H, Smith D D. Predicting rainfall erosion losses —A guide to conservation planning. Agriculture Handbook No. 537[M]. Washington, District of Columbia USA: U.S. Department of Agriculture Science and Education Administration, 1978.
[29]	[The Ministry of Water Resources of the People 's Republic of China. Classification of soil erosion classification (SL 190-2007). Beijing: China Water Resources and Hydropower Press, 2008.]
[30]	中华人民共和国水利部. 中华人民共和国行业标准(SL575-2012).水利水电工程水土保持技术规范[S]. 北京:中国水利水电出版社. 2012.
[3]	Renard K, Foster G, Weesies G et al. Predicting soil erosion by water: a guide to conservation planning with the revised universal soil loss equation (RUSLE)[M]. Agricultural Handbook 703. Washington, D.C.: US Department of Agriculture, 1997.
[4]	Liu B, Zhang K, Xie Y. An empirical soil loss equation. Vol II Process of soil erosion and its environment effects[C]. The proceedings of 12th ISCO Conference, 2002: 21-25.
[5]	文雅,刘晓南,程炯. 基于USLE的广东省山区土壤侵蚀量估算及特征分析[J]. 水土保持通报, 2013, 33(4): 112-118.
	[Wen Ya, Liu Xiaonan, Cheng Jiong. Assessment and feature analysis of sil erosion in mountainous area of Guangdong Province based on USLE. Bulletin of Soil and Water Conservation, 2013, 33(4): 112-118.]
[6]	潘美慧,伍永秋,任斐鹏,等. 基于USLE的东江流域土壤侵蚀量估算[J]. 自然资源学报, 2010, 25(12): 2154-2164. doi: 10.11849/zrzyxb.2010.12.016
	[Pan Meihui, Wu Yongqiu, Ren Feipeng et al. Estimating soil erosion in the Dongjiang River basin based on USLE. Journal of Natural Resources, 2010, 25(12): 2154-2164.] doi: 10.11849/zrzyxb.2010.12.016
[7]	刘江,李波,杨增元,等. 卧虎山水库对济南泉水影响的定量分析[J]. 水资源保护, 2012, 28(1): 67-70. doi: 10.3969/j.issn.1004-6933.2012.01.016
	[Liu Jiang, Li Bo, Yang Zengyuan et al. Quantitative analysis of influence of Wohushan Reservoir on Jinan karst spring basin. Water Resources Protection, 2012, 28(1): 67-70.] doi: 10.3969/j.issn.1004-6933.2012.01.016
[8]	刘宝元,谢云,张科利. 土壤侵蚀预报模型[M]. 北京: 中国科学技术出版社, 2001.
	[Liu Baoyuan, Xie Yun, Zhang Keli.Prediction model of soil erosion. Beijing: China Science and Technology Press, 2001.]
[9]	伍育鹏, 谢云, 章文波. 国内外降雨侵蚀力简易计算方法的比较[J]. 水土保持学报, 2001, 15(3):31-34. doi: 10.3321/j.issn:1009-2242.2001.03.009
	[Wu Yupeng, Xie Yun, Zhang Wenbo. Comparison of different methods for estimating average annual rainfall erosivity. Journal of Soil and Water Conservation, 2001,15(3):31-34.] doi: 10.3321/j.issn:1009-2242.2001.03.009
[10]	马良,左长清,孙勐,等. 山东省降雨侵蚀力空间分布特征及简易方程的研究[J]. 水土保持研究, 2010,17(2):28-31.
	[Ma Liang, Zuo Changqing, Sun Meng et al. Spatial characteristics and simplified empirical models of annual rainfall erosivity in Shandong Province. Research of Soil and Water Conservation, 2010,17(2):28-31.]
[11]	张金池,李海东,林杰,等. 基于小流域尺度的土壤可蚀性K值空间变异[J]. 生态学报,2008, 28(5): 2199-2206. doi: 10.3321/j.issn:1000-0933.2008.05.036
	[Zhang Jinchi, Li Haidong, Lin Jie et al. Spatial variability of soil erodibility at a catchment scale in China. Acta Ecologica Sinica, 2008, 28(5): 2199-2206.] doi: 10.3321/j.issn:1000-0933.2008.05.036
[12]	Wischmeier W H, Johnson C B, Cross B V. Soil erodibility nomograph for farmland and construction sites[J]. Journal of Soil & Water Conservation, 1971, 26(5):189-193. doi: 10.2307/3896643
[13]	Sharpley A N,Williams J R. EPIC-erosion/productivity impact calculator: 2. User manual[M]. Technical Bulletin-United States Department of Agriculture, 1990.
[14]	Shirazi M A, Hart J W, Boersma L. A unifying quantitative analysis of soil texture: Improvement of precision and extension of scale[J]. Soil Science Society of America Journal,1988, 52(1):181.
[15]	门明新,赵同科,彭正萍,等. 基于土壤粒径分布模型的河北省土壤可蚀性研究[J]. 中国农业科学, 2004,37(11): 1647-1653. doi: 10.3321/j.issn:0578-1752.2004.11.011
	[Men Mingxin, Zhao Tongke, Peng Zhengping et al. Study on the soil erodibility based on the soil particle-size distribution in Hebei Province. Scientia Agricultura Sinica,2004,37(11): 1647-1653.] doi: 10.3321/j.issn:0578-1752.2004.11.011
[16]	McCool D K, Foster G R, Weesies G A. Slope Length and Steepness Factors (LS),Chapter[M]//Renard et al.Predicting soil erosion by water:a guide to conservation planning with the Revised Universal Soil Loss Equation (RUSLE), Agriculture Handbook No. 703. Washington D C, USA: United States Department of Agriculture,1997:101-141.
[17]	胡刚,宋慧,石星军,等. 卧虎山水库不同算法LS因子值适用性分析[J]. 地理科学,2015,35(11): 1482-1488. doi: 10.3724/SP.J.1084.2010.00199
	[Hu Gang, Song Hui, Shi Xingjun et al. The applicability of LS factor value from different algorithms in Wohushan Reservior Basin.Scientia Geographica Sinica,2015,35(11): 1482-1488.] doi: 10.3724/SP.J.1084.2010.00199
[18]	Liu B Y, Nearing M A, Risse L M. Slope gradient effects on soil loss for steep slopes[J]. Transactions of the ASAE,1994, 37(5):1835-1840. doi: 10.2136/sssaj2000.6451759x
[19]	Foster G, Meyer L, Onstad C. A runoff erosivity factor and variable slope length exponents for soil loss estimates[J]. Transactions of the American Society of Agricultural Engineers,1977, 20(4):683-687. doi: 10.13031/2013.35628
[20]	McCool D K, Foster G R, Mutchler C Ket al. Revised slope length factor for the universal soil loss equation[J]. Transactions of the ASAE,1989, 30(5): 1387-1396. doi: 10.13031/2013.30576
[30]	[The Ministry of Water Resources of the People 's Republic of China. People's Republic of China industry standard (SL575-2012). technical specification for soil and water conservation of water conservancy and hydropower project. Beijing: China Water Power Press, 2012.]

土壤类别	棕壤	棕壤性土	褐土	石灰性褐土	褐土性土	中性粗骨土	钙质粗骨土	潮土
面积(km²)	30.70	22.24	96.97	60.20	32.26	105.72	186.02	20.72
K	0.2402	0.2157	0.3221	0.3496	0.2363	0.1976	0.2293	0.3401

土地利用类型	旱地	有林地	灌木林	疏林地	高覆盖度草地	中覆盖度草地	低覆盖度草地	水库坑塘	城镇用地	农村居民点	其它建设用地
C	0.31	0.006	0.015	0.017	0.04	0.08	0.2	0	0.2	0.2	0.22
P	0.3	1	0.2	0.2	0.2	0.2	0.2	0	1	1	1

级别*[t/ (km²·a)]	面积（km²）	面积百分比（%）	侵蚀量（t）	侵蚀量百分比（%）
微度（<200）	383.47	68.49	37528	14.42
轻度（200~2500）	155.45	27.77	142174	54.64
中度（2500~5000）	18.26	3.26	62885	24.17
强烈（5000~8000）	2.32	0.42	14112	5.42
极强烈（8000~15000）	0.35	0.06	3426	1.32
剧烈（>15000）	0.0036	0.00	71	0.03
